| Display |
50.80 cm (20 inch) LCD panel display with touchscreen |
| Motherboard |
Angelino2-UB |
| Processor |
AMD A4 3400 Processor |
| Processor speed |
Up to 2.7 GHz |
| Memory Capacity |
4GB |
| Memory Speed |
PC3-10600 MB/sec |
| Memory Type |
DDR3-1333 |
| Sound/Audio |
Integrated IDT 92HD91 Audio
Speakers
Microphone |
| Networking |
802.11 Wireless b/g/n PCI-E Mini card |
| LAN |
1000-Base-T |
| Hard Drive Capacity |
1TB |
| Interface |
SATA |
| Transfer rating |
3.0GB/sec |
| Rotational Speed |
7200 RPM |
| CD/DVD disc drive |
Slim Tray 8x Supermulti DVD drive |
| Memory Card Reader |
6-in-1 multimedia card reader |
| Power Supply |
150W (100V-240V) |
| Front of the system |
20" Touch screen active area
Microphone array
Webcam and webcam activity LED
Stand
Speakers |
| Back of the system |
Optical disk drive
Kensington lock slot
Wireless dongle
Motherboard back I/Os (specific I/Os are model dependent)
Memory card reader and other I/Os on left side |
| Left side of the system |
Left side ports |
| Right side of the system |
Optical disc drive |
| Left I/O ports |
Hard drive activity indicator
Memory card reader activity indicator
6-in-1 Memory card reader
Two USB ports
Microphone jack
Headphone jack |
| Back I/O ports |
Activity indicator
Power connector
LAN (Ethernet)
Four USB 2.0 ports
Audio port |
| Input devices |
Keyboard, mouse |
| Operating System |
Microsoft Windows 7 Home Premium (64-bit); Service Pack 1 |
| Dimensions (L x W x H) |
20-2/5" x 8-1/10" x 16-3/10" (50.9 x 20.3 x 40.7 cm) |
| Weight |
20.81 lbs / 9.43 kg |
