| Sensor Type |
4/3 Live MOS Sensor |
| Number of pixels / Aspect ratio |
Number of effective pixels: 16.1 million pixels
Total number of pixels: Approx. 16.9 million pixels
Aspect ratio: 1.33 (4:3) |
| Dust reduction |
Supersonic Wave Filter (dust reduction system for image sensor) |
| Filter array |
Primary color filter (RGB) |
| Recording format |
DCF, DPOF compatible / Exif, PRINT Image Matching III, MPO compatible |
| File format |
RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO(3D still) |
| Recording image size |
[RAW] 4608 x 3456 pixels
[JPEG] 4608 x 3456 pixels - 640 x 480 pixels |
| File sizes |
RAW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed) Approx. 17MB
Set1(LF): 4608(H)x3456(V) (1/4 compressed) Approx. 7.5MB
Set2(LN): 4608(H)x3456(V) (1/8 compressed) Approx. 3.5MB
Set3(MN): 2560(H)x1920(V) (1/8 compressed) Approx. 1.1MB
Set4(SN): 1024(H)x768(V) (1/8 compressed) Approx. 0.3MB |
| IS Type |
Built-in (Image sensor shift type for movie & still, 5-axis image stabilization) |
| IS Modes |
3 modes (IS1, IS2, IS3), OFF |
| Focal length setting |
Yes |
| Manual Function |
Input focal length 8, 10, 12, 16, 18, 24, 28, 30, 35, 40, 48, 50, 55, 65, 70, 75, 80, 85, 90, 100, 105, 120, 135, 150, 180, 200, 210, 250, 300, 350, 400, 500, 600, 800, 1000 |
| Effective compensation range |
Maximum 5 EV steps |
| Shutter speed range |
60 - 1/4000 sec. (Not available when Bulb is selected) |
| Eye Level Finder type |
Eye-level electronic viewfinder, approx. 1.44M |
| Eye point / Finder Styles |
Approx. 100% / Approx. 0.92x - 1.15x (-1m-1, 50mm lens, Infinity) |
| Diopter adjustment range |
Approx. 18mm (-1m-1, Distance from rear lens surface) / -4 Apporx.. +2m-1 |
| Level Gauge |
2-axis level gauge; horizontal /vertical |
| Finder Style |
Selectable from 3 types |
| EyeCup |
Removable, Optional eyecup EP-11 is available. |
| Live view |
100% field of view, Exposure compensation preview, WB adjustment preview, Gradation auto preview, Face detection preview (up to 8 faces), Grid line, Histogram, Magnification display (x5/x7/x10/x14) OFF |
| Grid/ Monitor Display Types |
Normal Mode, Grid Line Mode(4 types), Histogram Mode, Magnified View Mode, OFF |
| Magnification Ratio |
x5, x7, x10 (Default), x14 |
| Display of Face Detection |
Max 8 frames of face detection can be displayed |
| Monitor |
3.0-inch tilting OLED monitor
Approx. 610k dots, Touch control in electrostatic capacitance Type |
| Touch control |
Touch shutter release, Touch enlargement, Touch Live Guide, AF area selection, AF area enlargement, Frame advance/backward, Enlargement playback, Touch Super Control Panel |
| Tilting angle |
Upward tilting angle: up to 80 degrees / Downward tilting angle: up to 50 degrees |
| Color tone select |
Vivid / Natural |
| AF Type |
High-speed imager AF |
| Focus modes |
Single AF (S-AF) / Continuous AF (C-AF)/ Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR) |
| Full-time AF |
Yes |
| Magnified frame AF |
Selectable from over 800 AF points
Enlarged view check by magnify button
Magnification x5, x7, x10(Default), x14 selectable |
| Face detection AF / Eye detection AF |
Yes/Yes
Eye Detection AF mode: OFF / Nearer-eye priority / Right-eye priority / Left-eye priority |
| Focusing point /Focusing point selection |
35-area multiple AF / All target, Group target area (9-area), Single target |
| AF illuminator |
Yes |
| Manual focus assist |
Live view image is magnified when the focus ring is rotated. (at S-AF+MF or MF mode) |
| AF tracking |
Yes |
| TTL Image sensor metering |
Digital ESP metering (324-area multi pattern metering), Center weighted average metering, Spot metering, Spot metering with highlight control, Spot metering with shadow control |
| Metering range |
EV 0 - 20 (at normal temperature, 17mm f2.8, ISO 100) |
| Exposure modes |
i Auto, P: Program AE (Program shift can be performed), A: Aperture priority AE,
S: Shutter priority AE, M: Manual, Bulb, Time, Scene select AE, Art Filter, Underwater wide / macro |
| Scene Select AE Modes |
Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport, Night, Night + Portrait, Children, High Key, Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents, Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv., Macro Conv., 3D |
| ISO sensitivity |
AUTO: ISO 200 - 25600 (customizable, Default 200-1600) / Manual ISO 200 - 25600, 1/3 or 1 EV steps selectable |
| Exposure compensation |
±3 EV in 1/3, 1/2, 1 EV steps selectable |
| AE lock |
Locked at 1st release of shutter button (can be set to Fn1/Rec button) |
| Metering standard value adjustment |
1/6 EV step, +/- 1EV range |
| Shutter Type |
Computerized focal-plane shutter |
| Shutter speed |
1/4000 - 60 sec. (1/3, 1/2, or 1EV steps selectable.)
Bulb: default setting 8min. (1/2/4/8/15/20/25/30 min. selectable.) |
| Flash intensity control method T |
TL Auto, Auto, Manual, FP-TTL AUTO, FP-MANUAL |
| Built-in flash |
No |
| Number of picture / Function |
2 frames / Auto gain, Exposing on Recorded picture(RAW) |
| Flash mode |
Flash Auto, Redeye, Fill-in, Flash Off, Red-eye Slow sync.(1st curtain), Slow sync.(1st curtain), Slow sync.(2nd curtain), Manual (1/1(FULL)-1/64) |
| Synchronization speed |
1/250sec. or less (using the bundled flash) |
| Flash intensity control |
Up to ±3 EV in 0.3, 0.5, 1 EV steps selectable |
| Compatible external flash |
FL-50/FL-50R, FL-36/FL-36R, FL-30, FL-20, FL-14, FL-300R, FL-600R |
| Color Temperature |
5500±400deg.K |
| Control method |
Triggered and controlled by bundled flash (FL-LM2) |
| Channel No. 4 |
channels |
| Group Number |
4 groups (External flash 3 groups + a bundled flash) |
| Drive mode |
Single-frame shooting, Sequential shooting, Self-timer |
| Sequential shooting: maximum speed |
[Sequential shooting H mode]: 9.0 fps
[Sequential shooting L mode]: 3.5 fps/4.2fps in case of "I.S. OFF" |
| Recordable pictures:sequential shooting |
[RAW]: Max. 17 frames (in seq. shooting L), Max. 11 frames (in seq. shooting H)
[JPEG]: Up to full extent of data storage capacity (in seq. shooting L), Max. 17 frames ( in seq. shooting H) |
| Self-timer |
Operation time: 12 sec., 2 sec. (cancel available) |
| Exposure bracketing |
2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable, 7 frames in 0.3/0.7EV steps selectable |
| White balance bracketing |
3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis |
| Flash bracketing |
3 frames in 0.3/0.7/1.0EV step selectable |
| Art Filter bracketing |
i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom, Art Filters selectable |
| Movie Recording format |
MOV(MPEG-4AVC/H.264), AVI(Motion JPEG) |
| Movie Mode |
MOV(MPEG-4AVC/H.264 ), AVI(Motion JPEG)
[MOV]:
Full HD: 1920(H)x1080(V), 59.94i Recording
20Mbps(Fine) / 17Mbps(Normal): Aspect 16:9
HD: 1280(H)x720(V), 59.94i Recording,
13Mbps(Fine) / 10Mbps(Normal): Aspect 16:9
[AVI Motion JPEG]:
HD: 1280(H)x720(V), 30fps, Aspect 16:9
SD: 640(H)x480(V), 30fps, Aspect 4:3 |
| Maximum Recording Times |
Full HD: Approx. 29min(Fine) / Approx. 22min(Normal)
HD: Approx. 29min(Fine) / Approx. 29min(Normal) |
| Movie Effects |
Movie Effect: One shot echo / Multi echo
Art Filter Movie, Aperture priority Movie, Shutter Priority Movie, Manual Shooting Movie |
| IS for Movie |
Built in (Image sensor shift type image stabilization) |
| Exposure control (Movie) |
P: Program AE, A: Aperture priority AE, S: Shutter speed priority AE, M: Manual, Art Filter |
| Compression ratio |
Motion-JPEG Format: 1/12(HD), 1/8(SD) |
| Movie File sizes |
MOV Format: Max 4GB
Motion-JPEG Format: Max 2GB |
| Microphone/Speaker |
Stereo/Mono |
| Filter effect (B&W filter) |
Neutral, Yellow, Orange, Red, Green for Monotone |
| Picture tone |
Neutral, Sepia, Blue, Purple, Green for Monotone |
| Aspect Ratio |
4:3(Default) / 3:2 / 16:9 / 1:1 / 3:4 |
| Post Processing |
RAW: Aspect ratio is recorded as Exif data, JPEG: JPEG image is produced based on the aspect ratio |
| Noise Reduction: At High ISO setting |
Off, Low, Standard, High |
| Noise Reduction: At Slow shutter speed |
Off, On, Auto
On: effective when shutter speed is slower than 1 sec.
Auto: effective when shutter speed is slower than 4 sec. (at ISO 200 or higher) or 8 sec. (at lower than ISO200) |
| Level Gauge: Detection |
2-axis |
| Magnification |
x2 |
| Playback mode |
Single-frame, Information display, Index display (4/9/25/100 frames), Calendar, Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause), Picture rotation (auto), Slideshow (with BGM/BGM+Sound/Sound) |
| Languages |
34 languages selectable: English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croat, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai |
| USB/AV/Remote controller connector |
Dedicated multi-connector [USB: USB2.0 High Speed, Video: NTSC/PAL selectable, Optional Remote cable RM-UC1 can be used.] |
| HDMI connector |
Micro HDMI (Type-D) |
| Flash attachment |
Hot shoe |
| Accessory Port 2 |
Dedicated multi-connector [Available for VF-2/VF-3, SEMA-1, MAL-1 and PP-1.] |
| PC interface |
USB 2.0 High Speed |
| TV interface |
HDMI (HD/Stereo Sound), VIDEO-OUT(SD/Mono Sound) |
| Battery |
BLN-1 Li-ion battery (included) |
| Sleep mode |
Yes (1/3/5 min. off selectable) |
| Temperature |
32 Apporx.. +104 (operation) / -4 Apporx.. +140 (storage) Fahrenheit |
| Humidity |
30 - 90% (operation) / 10 - 90% (storage) |
| Dimensions (W x H x D) |
4.8 x 3.5 x 1.7 "/12.19 x 8.89 x 4.31 cm |
| Weight |
Approx. 15 ounces/425.24g [ with BLN-1 battery and Memory card]
Approx. 13 ounces /368.54g [body only] |
