| Display Mode |
Normal, Histogram, Highlight and shadow, Level guide, Off |
| Monitor type |
3.0-inch tilting monitor |
| Touch control |
Shutter release, Enlargement, Live Guide, AF area selection, AF area enlargement, Frame forward/backward, Enlargement playback, Super Control Panel, Art Filter selection, Scene mode selection, Wi-Fi connection |
| Tilting angle |
Upward tilting angle: up to 80 degrees
Downward tilting angle: up to 50 degrees |
| Brightness / Color temperature control |
±7 levels / ±7 levels |
| Color tone select |
Vivid / Natural |
| AF system |
High-speed imager AF |
| Focus mode |
Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR) |
| Full-time AF |
Available |
| Magnified frame AF |
Selectable from over 800 AF points
Magnification x5, x7, x10(Default), x14 selectable
Super Spot AF: Selectable from center of enlarge view(0.02% - 0.16% in view image)
Enlarged view focus point check by magnify button |
| Face detection AF / Eye detection AF |
Available / Available
Eye Detection AF mode: Off / Nearer-eye priority / Right-eye priority / Left-eye priority |
| Focusing point / Point selection mode |
35-area multiple AF / All target, Group target area (9-area), Single target,(normal) Single target(small) |
| Peakin Function |
Available on Fn button or Manual Focus
Type: White edge, Black edge |
| AF illuminator |
Available |
| Manual focus assist |
Live View image is magnified when the focus ring is rotated. (at S-AF+MF or MF mode) |
| Metering system |
Digital ESP metering (324-area multi pattern metering), Center weighted average metering, Spot metering, Spot metering with highlight control, Spot metering with shadow control (TTL Image sensor metering) |
| Metering range |
EV 0 - 20 (at normal temperature, 17mm f2.8, ISO 100) |
| Exposure mode |
i Auto, P: Program AE (Program shift can be performed), A: Aperture priority AE
S: Shutter priority AE, M: Manual, Bulb, Time, Scene select AE, Art Filter, Underwater wide / macro |
| Scene select AE |
Portrait, e-Portrait, Landscape, Landscape + Portrait, Sport, Night, Night + Portrait, Children, High Key, Low Key, DIS mode, Macro, Nature Macro, Candle, Sunset, Documents, Panorama, Fireworks, Beach & Snow, Fisheye Conv., Wide Conv., Macro Conv., 3D |
| ISO sensitivity |
AUTO ISO: LOW(approx. 100) - 25600 (customizable, Defalut:LOW-1600)
Manual ISO: LOW(approx.100), 200 - 25600, 1/3 or 1 EV steps selectable |
| Exposure compensation |
±3 EV in 1/3, 1/2, 1 EV steps selectable |
| AE lock |
Locks at 1st release of shutter button (can be set to Fn/Rec button) |
| Shutter type |
Computerized focal-plane shutter |
| Shutter speed |
1/8000 - 60 sec. (1/3, 1/2, or 1EV steps selectable)
Bulb/Time: default setting 8min. (1/2/4/8/15/20/25/30 min. selectable) |
| Flash intensity control method |
TTL Auto, Auto, Manual, Super FP (FP-TTL AUTO, FP-MANUAL) |
| Built-in flash |
TTL Flash, GN=7 (ISO100 m) / GN=10(ISO200 m) |
| Flash mode |
Flash Auto, Redeye, Fill-in, Flash Off, Red-eye Slow sync.(1st curtain), Slow sync.(1st curtain), Slow sync.(2nd curtain), Manual (1/1 (FULL)-1/64) |
| Synchronization speed |
1/320 sec. Built-in Flash
1/250 sec. External Flash |
| Flash intensity control |
Up to ±3 EV in 0.3, 0.5, 1 EV steps selectable |
| Compatible external flash |
FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R |
| Wireless Flash Control |
(FL-50R, FL-36R, FL-300R, FL600R) Compatible external flash |
| Control method |
Triggered and controlled by built-in flash (Olympus Wireless RC Flash system compatible) |
| External Flash intensity type |
TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL |
| Wireless Flash Control Channel |
4 channels |
| Wireless Flash Control Group No. |
4 groups (External flash 3 groups + a built-in flash) |
| Sequential shooting maximum speed |
[Sequential shooting H mode] 9.0 fps in case of "I.S. Off"
Focus and exposure are fixed at the values for the first shot.
[Sequential shooting L mode]
4.5 fps in case of "I.S. Off" (in 5.0 seq. shooting L)
5.0 fps in case of "I.S. Off" (in 5.0 seq. shooting L)
When using the M.ZUIKO DIGITAL ED 12-50mm EZ f3.5-6.3. |
| Max. recordable pictures |
[RAW] Max. 20 frames (in 4 seq. shooting L), Max.15 frames (in 9 seq. shooting H)
[JPEG] Max. 70 frames (in 4 seq. shooting L), Max. 19 frames ( in 9 seq. shooting H) |
| RAW picture editing |
RAW development based on settings of the camera (including Art Filter, ART-BKT)
2 programmable settings, preview capability. |
| Dimensions |
4.81x2.71x1.46" / 12.21x6.88x3.70 cm |
| Weight |
Approx. 420 g / 14.81 oz (CIPA guideline compliant, with BLN-1 battery and Memory card)
Approx. 378 g / 13.33 oz [body only] |
| Reset & custom setting |
My set: 4 settings recordable / Available to set to mode dial. |
| Editing function |
RAW development, Gradation auto, Monochrome, Sepia, Red-eye fix, Saturation, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Image Overlay, Postrecording |
| Input/Output |
USB/AV/Remote controller connector: Dedicated multi-connector (USB: USB2.0 Hi-Speed, Video: NTSC/PAL selectable, Optional Remote cable RM-UC1 compatible.)
HDMI connector: Micro HDMI (Type-D)
Flash attachment: Hot shoe
Accessory Port 2: Dedicated multi-connector (for VF-2/VF-3/VF-4, SEMA-1, MAL-1 and PP-1.)
Wireless LAN: Built-in (IEEE 802.11b/g/n)
PC interface: USB2.0 Hi-Speed
TV interface: HDMI (HD/Stereo Sound), conventional video-out (SD/Mono Sound) |
| Information display |
Histogram (independent luminance / RGB available), Highlight/Shadow point warning, AF frame, Photographic information, OFF |
| Playback mode |
Single-frame, Information display, Index display (4/9/25/100 frames), Calendar, Enlargement (2x - 14x), Movie (with sound, FF/REW/Pause), Picture rotation (auto), Slideshow (with sound including BGM, 2 selectable slide show effects, replaceable BGM), Light Box display |
| Level Gauge |
Detection: 2-axis |
| Magnification |
2x |
| Wi-Fi Function |
GPS info. Function: Available (by using Smartphone GPS data)
Wireless Shooting: Live View, Rec view, Wireless touch AF shutter, Power off
Image Share: File Type: JPEG, MOV (Connect to up to 4 devices simultaneously. Marking function for image share)Easy Connection: QR code setting |
| Multi Exposure |
Number of picture / Function: 2 frames / Auto gain, Exposing on Recorded picture(RAW) |
| Aspect Ratio |
4:3(Default) / 3:2 / 16:9 / 1:1 / 3:4 |
| Color matrix |
sRGB, Adobe RGB |
| Picture Mode |
i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom, Art Filters |
| Gradation |
Auto, Normal, High Key, Low Key (except Art Filters) |
| Interval Mode |
Interval Time 1sec. - 24 Hours, Max 99 frames. Available on making Time-lapse movie automatically |
| Recording(Sound)Maximum Recording Time |
Picture with Sound: 30sec.
Movie: depend on Movie Recording Time |
| White balance mode |
Auto WB, 7 Preset WBs, 2 Capture WBs, Custom WB(Kelvin setting) |
| White balance compensation |
±7 steps in each A-B/G-M axis |
| Preset white balance |
7 preset WBs (3000K - 7500K)
Sunny(5300K), Shadow(7500K), Cloudy(6000K), Incandescent(3000K), Fluorescent(4000K), Underwater, WB Flash(5500K) |
| Microphone/Speaker |
Stereo/Mono |
| Microphone function |
Wind Noise Reduction, Recording Volume Audio dubbing possible for still pictures (up to 30 sec.) |
| Compression ratio |
Motion-JPEG Format: 1/12(HD), 1/8(SD) |
| Movie: File size |
MOV Format: Max 4GB
Motion-JPEG Format: Max 2GB |
| Recording format |
Wave Format (Stereo linear PCM/16-bit, Sampling frequency 48kHz) |
| Exposure control (Movie) |
P: Program AE, A: Aperture priority AE, S: Shutter speed priority AE, M: Manual, Art Filter |
| Time-lapse Movie |
Available (AVI Motion JPEG 1280x720,10fps) |
| Image Stabilization for Movie |
M-IS (Image sensor shift), Off |
| Movie Function |
Movie Effect: One-shot echo / Multi-echo / Art fade, Art Filter Movie, Aperture-prioritized Movie, Shutter Speed-Prioritized Movie, Manually Shot Movie |
| Movie Recording format |
MOV(MPEG-4AVC/H.264), AVI(Motion JPEG) |
| Movie Mode |
[MOV]
Full HD: 1920(H)x1080(V), 30p(29.97 fps)Recording 20Mbps (Fine) / 17Mbps (Normal): Aspect 16:9
HD: 1280(H)x720(V), 30p (29.97fps)Recording
13Mbps(Fine) / 10Mbps(Normal): Aspect 16:9
[AVI Motion JPEG]
HD: 1280(H)x720(V), 30fps Aspect 16:9
SD: 640(H)x480(V), 30fps, Aspect 4:3 |
| Movie Maximum Recording Time |
[MOV]
Full HD: Approx. 29min(Normal) / Approx. 22min(Fine)
HD: Approx. 29min(Normal) / Approx. 29min(Fine)
[AVI]
HD: Approx. 7min / SD: Approx. 14min |
| Aspect & Window Pattern |
4:3, 2 frames
4:3, 3 frames
1:1. 2 frames
1:1, 3 frames |
| Frame Effect |
White Frame
White Frame & White Edge Effect
Black Frame
White Frame & Pin Hole Effect |
| Photo story Type |
Standard (I,II,III,IV / a, b, c, d, e / A, B, C, D) (Frame effect / Aspect & Window Pattern) |
| Art Effect |
a. Soft Focus Effect
b. Pin-Hole Effect
c. White Edge Effect
d. Frame Effect
e. Star Light Effect
f. B&W Effect (Yellow, Orange, Red, Green)
g. Pict. Tone (Sepia, Blue, Purple, Green) |
| White balance bracketing |
3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis. |
| Flash bracketing |
3 frames in 0.3/0.7/1.0EV step selectable |
| Art Filter bracketing |
i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom, Art Filters selectable |
| Bracketing for HDR Post-process |
3 or 5 frames in 2.0/3.0EV steps selectable, 7 frames in 2.0EV steps selectable. |
| ISO bracketing |
3 frames in 0.3/0.7/1.0EV steps selectable |
| Mode (Variation / Effect) |
Pop Art (I, II / a.b.c.d.e.)
Soft Focus ( - / c.e.)
Pale & Light Color (I, II / a.b.c.d.)
Light Tone ( - / d.)
Grainy Film (I, II / b.c.d.f.g)
Pin Hole (I, II, III / d.)
Diorama ( - / d.)
Cross Process (I, II / b.c.d.)
Gentle Sepia ( - / a.b.c.d.)
Dramatic Tone (I / b.c.d.e) (II/ b.c.d.e.f.g)
Key Line (I, II / a.b.c.d.e.)
WaterColor (I, II / a.c.d.) |
| Exposure bracketing |
2, 3 or 5 frames in 0.3/0.7/1.0EV steps selectable, 7 frames in 0.3/0.7EV steps selectable |
| Shutter speed range |
60 - 1/8000 sec. (Not available when Bulb or Time is selected.) |
| Live View |
Approx. 100% field of view
Exposure compensation preview, WB adjustment preview
Gradation auto preview, Face detection preview (up to 8 faces)
Grid line, Histogram, Magnification display (x5/x7/x10/x14) |
| Self-timer |
Operation time: 12 sec., 2 sec.,custom (Waiting time 1-30sec.,Shooting interval 0.5/1/2/3sec.,Number of shots 1-10) |
| Focal length setting |
Available |
| Available manual focal length setting |
Input focal length: 8, 10, 12, 15, 16, 18, 24, 28, 30, 35, 40, 48, 50, 55, 65, 70, 75, 80, 85, 90, 100, 105, 120, 135, 150, 180, 200, 210, 250, 300, 350, 400, 500, 600, 800, 1000 |
| Image Stabilization System Mode |
4 modes (S-I.S.AUTO, S-I.S.1, S-I.S.2, S-I.S.3), OFF |
| IS for Live View image |
Available (by half-pressing the shutter button or enlarging operation) |
| Recording image size |
[RAW] 4608 x 3456 pixels
[JPEG] 4608 x 3456 pixels - 640 x 480 pixels |
| Recording (Still): File Size |
RAW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed) Approx. 17MB
Set1(LF): 4608(H)x3456(V) (1/4 compressed) Approx. 7.5MBSet2(LN): 4608(H)x3456(V) (1/8 compressed) Approx. 3.5MB
Set3(MN): 2560(H)x1920(V) (1/8 compressed) Approx. 1.1MB
Set4(SN): 10 |
| Recording: Recording format (Still) |
DCF, DPOF compatible / Exif, PRINT Image Matching III, MPO compatible |
| Image Stabilization System Type |
Built-in (Image sensor shift type for movie & still, 5-axis image stabilization) |
| File format |
RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO(3D still) |
| Dust reduction |
Supersonic Wave Filter (image sensor dust reduction system) |
| Number of pixels / Aspect ratio |
Number of effective pixels: Approx. 16.1 million pixels
Total number of pixels: Approx. 17.2 million pixels
Aspect ratio: 1.33 (4:3) |
| Memory |
SD Memory Card (SDHC, SDXC, UHS-I compatible, Eye-Fi Card compatible) |
| Screen size |
17.3 mm (H) x 13.0 mm (V) |
| Lens mount |
Micro Four Thirds Mount |
