| Recording Media |
SD Memory Card, SDHC Memory Card, SDXC Memory Card (Compatible with UHS-I standard SDHC / SDXC Memory Cards) |
| Image Sensor Size |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Lens Mount |
Micro Four Thirds mount |
| Image sensor type |
Live MOS Sensor |
| Total Pixels |
16.68 Megapixels |
| Camera Effective Pixels |
16.0 Megapixels |
| Color Filter |
Primary color filter |
| Dust Reduction System |
Supersonic wave filter |
| Recording File Format |
Still Image: JPEG (DCF, Exif 2.3), RAW MPO (When attaching 3D lens in Micro Four Thirds System standard) Motion Image: AVCHD (Audio format: Dolby Digital 2ch) / MP4 (Audio format AAC 2ch) |
| Aspect Ratio |
4:3, 3:2, 16:9, 1:1 |
| Image Quality |
RAW, RAW+Fine, RAW+Standard, Fine, Standard MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard) |
| Color Space |
sRGB, Adobe RGB |
| File Size (Pixels): Still Image 1 |
[4:3] 4,592 x 3,448 (L) [16M], 3,232x2,424 (M) [8M], 2,272x1,704 (S) [4M], 1,824x1,368 (When attaching 3D lens in Micro Four Thirds System standard) [3:2] 4,576x3,056 (L) [14M], 3,232x2,160 (M) [7M], 2,272x1,520 (S) [3.5M], 1,824x1,216 (When attaching 3D lens in Micro Four Thirds System standard) |
| File Size (Pixels): Still Image 2 |
[16:9] 4,576x2,576 (L) [11.5M], 3,232 x 1,824(M) [6M], 1,920x1,080 (S) [2M], 1,824x1,024 (When attaching 3D lens in Micro Four Thirds System standard) [1:1] 3,424x3,424 (L) [11.5M], 2,416x2,416 (M) [6M], 1,712x1,712 (S) [3M], 1,712x1,712 (When attaching 3D lens in Micro Four Thirds System standard) |
| File Size (Pixels): Motion Image-MP4 |
NTSC: [Full HD] 1,920 x 1,080, 30fps (sensor output is 30p) (Approx. 20Mbps), [HD] 1,280 x 720, 30fps (sensor output is 30p) (Approx. 10Mbps), [VGA] 640 x 480, 30fps (sensor output is 30p) (Approx. 4Mbps)
PAL: [Full HD] 1,920 x 1,080, 25fps (sensor output is 25p) (Approx. 20Mbps), [HD] 1,280 x 720, 25fps (sensor output is 25p) (Approx. 10Mbps), [VGA] 640 x 480, 25fps (sensor output is 25p) (Approx. 4Mbps) |
| File Size (Pixels): Motion Image-AVCHD |
NTSC: [Full HD] 1,920 x 1,080, 60i (sensor output is 30p) (FSH: 17 Mbps), [HD] 1,280 x 720, 60p (sensor output is 30p) (SH: 17 Mbps) PAL: [Full HD] 1,920 x 1,080, 50i (sensor output is 25p) (FSH: 17 Mbps), [HD] 1,280 x 720, 50p (sensor output is 25p) (SH: 17 Mbps) |
| Continuous Recordable Time(Motion Image) |
AVCHD with picture quality set to [FSH]: Approx. 130 min with H-FS014042 / Approx. 140 min with H-PS14042 / Approx. 150 min with H-H014 |
| Actual Recordable Time (Motion Image) |
AVCHD with picture quality set to [FSH]: Approx. 65 min with H-FS014042 / Approx. 70 min with H-PS14042 / Approx. 75 min with H-H014 |
| Focus type |
Contrast AF system |
| Focus Mode |
AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF |
| AF Mode |
Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint Touch (1-area-focusing in Face detection / AF Tracking / Multi-area-focusing / 1-area-focusing / Pinpoint) |
| AF Detective Range |
EV 0 - 18 (ISO100 equivalent) |
| AF Assist Lamp |
Yes |
| AF Lock |
Set the Fn button in custom menu to AF/AE lock or shutter button halfway pressed in AFS mode |
| Light Metering System |
144-zone multi-pattern sensing system |
| Light Metering Mode |
Intelligent Multiple / Center Weighted / Spot |
| Metering Range |
EV 0 - 18 (F2.0 lens, ISO100 equivalent) |
| Exposure Mode |
Program AE / Aperture Priority AE / Shutter Priority AE / Manual / Auto |
| ISO Sensitivity |
Auto / Intelligent ISO / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 (Changeable to 1/3 EV step) |
| Exposure Compensation |
1/3 EV Step, ±5 EV |
| AE Lock |
Set the Fn button in custom menu to AF/AE lock |
| AE Bracket |
3, 5, 7 frames, in 1/3, 2/3 or 1 EV Step, ±3 EV |
| White Balance |
Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 / Color temperature setting |
| White Balance Adjustment |
Blue/amber bias, Magenta/green bias |
| Color Temperature Setting |
2,500 K - 10,000 K in 100 K |
| White Balance Bracket |
3 exposures in blue/amber axis or in magenta/green axis |
| Shutter type |
Focal-plane shutter |
| Shutter Speed |
Still Images: 1/4,000 - 60 and Bulb (up to approx. 120 seconds) Motion Image: 1/16,000 - 1/30 (NTSC), 1/16,000 - 1/25 (PAL) |
| Self Timer |
10 sec, 3 images / 2 sec / 10 sec |
| Remote Control |
Remote control with bulb function by DMW-RSL1 (Optional) |
| Still Image SCN Mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / Night Portrait / Night Scenery / Illuminations / Baby 1, 2 / Pet / Party / Sunset |
| Video SCN Mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Flower / Food / Objects / Low-light / Party / Sunset (Activated by selecting Still Image SCN mode then pressing Video Button. Still Image SCN modes without corresponding Video SCN mode is recorded in mode suitable for the recording situation.) |
| Creative Control |
(Still image & Motion image) Expressive / Retro / High Key / Low Key / Sepia / High Dynamic / Toy Effect / Miniature Effect |
| Burst Speed |
SH: 20 frames/sec, H: 4.2 frames/sec (When AFS mode), M: 3 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Number of Recordable Images |
9 images (when there are RAW files with the particular speed) Unlimited consecutive shooting (when there are no RAW files) (depending on memory card size, battery power, picture size and compression) |
| Built-In-Flash type |
TTL Built-in-Flash, GN7.6 equivalent (ISO160 m), Built-in Pop-up |
| Flash Mode |
Auto, Auto / Red-eye Reduction, Forced On, Forced On / Red-eye Reduction, Slow Sync., Slow Sync. / Red-eye Reduction, Forced Off |
| Synchronization Speed |
Less than 1/160 second |
| Flash Output Adjustment |
1/3 EV Step, ± 2 EV |
| Flash Synchronization |
1st Curtain Sync., 2nd Curtain Sync. |
| Hot Shoe |
TTL Auto with FL220 / FL360 / FL500 (Optional) |
| LCD Monitor type |
TFT LCD with Touch panel |
| Monitor Size |
3.0 inch (7.5 cm) / 3:2 Aspect / Wide-viewing angle |
| Pixels |
460,000 dots |
| Field of View |
Approx. 100% |
| Monitor Adjustment |
Brightness (7 levels), Contrast and Saturation (7 levels), Red tint (7 levels), Blue tint (7 levels) |
| Live View Functions |
Guide Lines (3 patterns) Real-time Histogram |
| Additional Zoom Operation |
Touch Zoom (when use power zoom lenses) H-PS14042 lens and H-PS45175 lens |
| Digital Zoom |
2x, 4x |
| Extra Tele Conversion |
Still image: Max. 2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.) Motion image: Max. 4.8x (Magnification ratio depends on the recording quality and aspect ratio.) |
| Level Gauge |
Yes (Built-in 3 shaft accelerometer sensor) |
| Direction detection function |
Yes |
| Function Button (Fn1, Fn2, Fn3, Fn4) |
One Push AE / Preview / Level Gauge / Focus Area Set / Photo Style / Aspect Ratio / Picture Size / Quality / Metering Mode / Flash / Flash Adjust. / I. Resolution / I. Dynamic / EX. Tele Conv. / Digital Zoom / Stabilizer / Sensitivity / White Balance / AF Mode / Drive Mode / Motion Pic. Set / Picture Mode / Histogram / Guide Line / Rec Area |
| Custom Menu: C1, C2-1/2/3 |
Yes (Registering personal menu settings) |
| Playback Mode |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max. 16x), Slideshow (duration & effect is selectable), Playback Mode (Normal / Picture / Video / 3D Play / Category / Favorite), Title Edit, Text Stamp, Video Divide, Resize, Cropping, Aspect Conversion, Rotate, Rotate Display, Favorite, Print Set, Protect, Face Recognition Edit |
| Image Protection |
Single / Multi, Single in Burst Group / Multi in Burst Group, Cancel |
| Image Erase |
Single / Multi / All / Except Favorite |
| Direct Print |
PictBridge compatible (Print size, Layout and Date settings are selectable) |
| USB |
USB 2.0 High Speed |
| HDMI |
mini HDMI TypeC Video: Auto / 1080i / 720p / 480p (576p in PAL system) Audio: Linear PCM |
| Audio Video Output |
Monaural Type, NTSC / PAL, NTSC only for North America |
| Remote |
Remote socket |
| Microphone |
Stereo, Wind-cut: Off / Auto Microphone level adjustable: Lv1 / Lv2 / Lv3 / Lv4 |
| Speaker |
Monaural |
| OSD Language |
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek, Vietnamese |
| Battery |
Li-ion Battery Pack (7.2V, 1,010mAh) (Included) Battery Charger |
| Battery Life (CIPA Standard) |
Approx. 300 images with H-FS014042 |
| Operating Temperature |
0Deg.C to 40Deg.C (32Deg.F to 104Deg.F) |
| Operating Humidity |
10%RH to 80%RH |
| Lens Construction |
12 elements in 9 groups (1 Aspherical lens) |
| Mount |
Micro Four Thirds mount |
| Optical Image Stabilizer |
YES (MEGA O.I.S.) |
| Focal Length |
f = 14 mm to 42 mm (35 mm camera equivalent 28 mm to 84 mm) |
| Aperture Type |
7 diaphragm blades / Circular aperture diaphragm |
| Aperture Range |
F3.5 (Wide) - F5.6 (Tele) |
| Minimum Aperture |
F22 |
| Closest Focusing Distance |
0.3 m / 1 feet |
| Maximum Magnification |
Approx. 0.16x / 0.32x (35 mm camera equivalent) |
| Diagonal Angle of View |
75Deg. (W) - 29Deg. (T) |
| Filter Size |
Dia. 52 mm / 2.05 inch |
| Max. Diameter |
60.6 mm / 2.39 inch |
| Overall Length |
Approx. 63.6 mm / 2.50 inch (from the tip of the lens to the base side of the lens mount) |
| Dimensions (W x H x D) |
116.3 x 67.8 x 39.4 mm / 4.58 x 2.67 x 1.55 inch (excluding protrusions) |
| Weight |
Approx. 483g / 17.04 oz (SD card, Battery, H-FS014042 lens included) |
