| Image sensor Type |
CMOS |
| Effective Pixel |
Approx. 14.6 Mega-pixels |
| Total Pixel |
Approx. 15.1 Mega-pixels |
| Mount |
SAMSUNG NX Mount |
| Usable Lens |
SAMSUNG Lenses for SAMSUNG NX Mount |
| Viewfinder Type |
EVF |
| Field of View |
Approx. 100% |
| Magnification |
Approx. 0.86x (APS-C, 50mm, -1m-1) |
| Focusing Type |
Contrast AF |
| Focusing Modes |
Single AF, Continuous AF, MF |
| AE Lock |
AEL Button |
| Exposure Compensation |
±3 EV (1/2EV, 1/3EV step) |
| ISO Equivalent |
Auto, 100, 200, 400, 800, 1600, 3200 (1EV step) |
| Exposure Modes |
Single, Continuous, Burst, Self-timer, Bracket (AE, WB, PW) |
| Metering System |
Metering : Multi, Center-weighted, Spot Metering range : EV0 ~ 18 (ISO100°30mm F2.0) |
| Shutter Speed |
Auto:1/4000sec. ~ 30sec. Manual:1/4000sec. ~ 30sec. (1/3EV or 1/2EV step) Bulb (Limit time : 8 min) |
| Shutter Type |
Electronically controlled vertical-run focal plane shutter |
| Flash Modes |
Smart Flash, Auto, Auto + Red-eye reduction, Fill-in, Fill-in + Red-eye reduction, 1st Curtain, 2nd Curtain, OFF |
| Flash Type |
TTL Auto Pop-up flash |
| Flash Guide Number |
11 (at ISO 100) |
| Flash Angle of View Coverage |
28mm wide-angle (Equivalent to 35mm) |
| Flash Sync. Speed |
Less than 1/180sec. |
| Flash External Flash |
SAMSUNG External Flash available (SEF-42A, SEF-20A : Optional) |
| Picture Wizard |
Yes |
| White Balance |
Auto, Daylight, Cloudy, Fluorescent (W, N, D), Tungsten, Flash, Custom, K(Manual) |
| Storage Media |
SD, SDHC |
| File Format |
RAW (SRW), JPEG (EXIF 2.21), DCF, DPOF 1.1, PictBridge 1.0 |
| Capacity(512 MB) 1 |
14M : RAW 35 14M : Super Fine 142, Fine 278, Normal 408 10M : Super Fine 197, Fine 382, Normal 724 6M : Super Fine 322, Fine 615, Normal 1128 2M : Super Fine 738, Fine 1334, Normal 2238 Burst (1.4M) : Super Fine 1201, Fine 2092, Normal 3320 12M(W) : Super Fine 168, Fine 328, Normal 630 |
| Capacity(512 MB) 2 |
8M(W) : Super Fine 234, Fine 454, Normal 860 5M(W) : Super Fine 381, Fine 727, Normal 1334 2M(W) : Super Fine 872, Fine 1573, Normal 2638 Movie : 1280x720 : High Quality 15min., Normal 22min. 640x480 : High Quality 44min., Normal 66min. 320x240 : High Quality 145min., Normal 210min |
| Image Play Editing |
Red eye fix, Back light comp., Photo Style Selector, Resize, Rotate, Face Retouch |
| Image Play Type |
Single image, Thumbnails (3/9/20 images), Slide show, Movie |
| Shooting Modes |
Smart Auto, Program, Shutter Priority AE, Aperture Priority AE, Manual, Night, Portrait, Landscape, Scene, Movie |
| Shooting Drive Modes |
Smart Auto, Program, Shutter Priority AE, Aperture Priority AE, Manual, Night, Portrait, Landscape, Scene, Movie |
| Digital Output Connector |
USB 2.0 (HI-SPEED) |
| Video Output |
NTSC, PAL (user selectable) HDMI 1.3 : (1080i, 720P, 576P / 480P) |
| DC Power Input Connector |
DC 9.0V, 1.5A (100 ~ 240V) |
| Software Application |
SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6 |
| Power Source |
Rechargeable battery : BP1310 (1300mAh) Charger: BC1310 AC Adaptor : AD9NX01 (Optional) |
| Battery Life |
200min/400shots (CIPA Standard) |
| Operating Temperature |
0 ~ 40 °C |
| Operating Humidity |
5 ~ 85% |
| Dimensions (WxHxD) |
123®87®39.8mm (excluding the projecting parts of the camera) |
| Weight |
353g (without batteries and card) |
