| Aspect Ratio |
16:10 |
| Formats Supported |
JPEG, TIFF (Exif Ver 2.21 compatible, BMP (1, 4, 8, 16, 24, 32 bit Windows format) and RAW (preview only: SRF, SR2, ARW) |
| Panel Type |
LCD Panel size: 10" (panel diagonal) |
| Playback |
Still Image Playback; Slideshow Playback (10 patterns);Slideshow interval setting (10 patterns); Index Playback (3 patterns); Clock & Calender Playback (14 designs). Placement supported - Landscape, Portrait, Auto orientation; Image display setting; Resume Playback; Panorama scroll playback |
| System Requirements: Processor |
Windows PC or compatible Macintosh |
| System Requirements: USB Port |
To connect to a computer, optional USB cable required. (Mini B, within 2m) |
| Remote Control |
Power, up, down, left, right, Enter, Menu, Back, Import, Delete, Single, Clock, Index, Slideshow, zoom in, zoom out, Rotate, Select Device, Marking, Sort) |
| USB Port |
USB Mini-B/USB-A (Hi-speed) |
| Max pixels available to decode and print |
48 megapixels |
| Display Resolution |
WVGA 800 x 480 |
| Screen Size |
10" |
| Media & Modes Supported 1 |
Compatible Memory Card: Memory Stick; Memory Stick Duo; Memory Stick PRO; Memory Stick PRO Duo; High Speed Memory Stick; High Speed Memory Stick Duo; Memory Stick Micro (M2) (with optional adaptor); MagicGate Memory Stick; MagicGate Memory Stick Duo; Memory Stick PRO-HG Duo(8-bit parallel transfer of "Memory Stick PRO-HG Duo" is not supported); SD card; mini SD card (with optional adaptor) |
| Media & Modes Supported 2 |
micro SD card (with optional adaptor); SDHC card; mini SDHC card (with optional adaptor); micro SDHC card (with optional adaptor); MMC; RS-MMC (with optional adaptor); MMC Plus; xD-picture card |
| System Requirements |
Microsoft Windows 7, Windows Vista SP2, Windows XP SP3, pre-installed Macintosh Mac OS X (10.4 or later) |
| Action Buttons |
Power; Up and Down arrows; Enter; Menu, View Mode; Back |
| Function |
Delete, Zoom (-), Zoom (+), Rotate image, Auto Touch Up, Image display setting(Fit to screen/Full Image), and Placement supported(Landscape, Portrait, Auto orientation) |
| Operating Temperature |
5 degrees C - 35 degrees C |
| Storage Temperature |
-20 degrees C - +60 degrees C |
| User Memory Capacity (Approx.) |
Internal Memory Capacity: 128MB; Capacity for photo image area: 80MB; Maximum number of photo stored: 200; Ability to copy from memory card to internal memory and internal memory to memory card. |
| AC Power |
AC 100-240V (50/60Hz), 0.3A (max) |
| Power Consumption (in Operation) |
Approx. 10.0W (max) including the AC adaptor |
| Power Requirements |
DC 12V, 1.5A |
| Dimensions (W x H x D) |
Photo Frame: Approx. 11.54 x 7.68 x 1.06in / 293 x 195 x 26.9mm Including Stand: Approx. 11.54 x 7.68 x 4.6in / 293 x 195 x 116.91mm |
| Weight |
22.2oz (629.3g) without AC adaptor |
