| Color Temperature |
2500 - 9900 k with 15-step Magenta / Green compensation |
| orizontal Wide: 7152 X 1080 (7.7M) |
0 (5.3M) 16:9: 1920 X 1080 (2.1M) |
| Camera |
Lens Compatibility: Sony A-mount lens Lens Mount: Sony A-mount Camera Type: Sony A-mount interchangeable lens digital camera |
| Imaging Sensor |
Imaging Sensor: Exmor APS HD CMOS sensor (23.4 X 15.6mm) Processor: BIONZ image processor Anti Dust: Charge protection coating on Low-Pass Filter and Image Sensor-Shift mechanism Pixel Gross: Approx. 16.5 megapixels Effective Picture Resolution: Approx. 16.1 megapixels Focal Length Conversion Factor: 1.5x Color Filter System: RGB primary color filters |
| Recording - Media Type |
Memory Stick PRO Duo, Memory Stick PRO-HG Duo, SD memory card, SDHC memory card, SDXC memory card |
| Recording - Color Space |
sRGB, AdobeRGB |
| Recording - Still Image |
Mode: JPEG (Standard, Fine), RAW, RAW+JPEG Still Image Size 16:9: L: 4912 x 2760 (14M), M: 3568 x 2000 (7.1M), S: 2448 x 1376 (3.4M) Still Image Size 3:2: L: 4912 x 3264 (16M), M: 3568 x 2368 (8.4M), S: 2448 x 1624 (4M) Panorama Still Image Size: Horizontal Wide: 12,416 x 1,856 (23M) Horizontal Std.: 8,192 x 1,856 (15M) Vertical Wide: 2,160 x 5,536 (12M) Vertical Std.: 2,160 x 3,872 (8.4M) 3D Sweep Panorama: Horizontal Wide: 7152 X 1080 (7.7M) |
| Recording - Video |
Video Format: AVCHD Ver. 2.0/MP4 compliant / MPEG-4 AVC (H.264) Video Mode: AVCHD: 1920 x 1080/ 60i (60i/24Mbps/ FX, 60i/17Mbps/ FH, 24p/24Mbps/ FX, 24p/17Mbps/ FH) MP4 HD: 1440 x 1080/ 30p (29.97 Progressive) Approx. 12Mbps (Average bit-rate) MP4 VGA: 640 x 480/ 30p (29.97 Progressive) Approx. 3Mbps (Average bit-rate) Video Resolution: 1920x1080/60i (59.94i, 29.97p sensor output) Video Signal: NTSC color, EIA standards |
| Recording - Audio |
Audio Format: Dolby Digital (AC-3) / MPEG-4 AAC-LC, 2ch Microphone/Speaker: Built-in Stereo Microphone |
| Optics/Lens |
Lens Mount Type: Sony A-mount |
| Viewfinder |
Type: 0.46" SVGA Xtra Fine EVF (Electronic viewfinder) (1,440,000 pixels) Diopter Adjustment: -4.0 to +4.0m-1 Field of View: 100% Magnification: 1.09x (with 50mm lens at infinity, -1m-1 ) |
| LCD Display |
LCD Type: 2.6" TFT Clear Photo LCD (230,400 pixels) Angle Adjustment: Tilt angle: Up app1ox. 135 degrees, down 55 degrees Brightness Control: Auto/Manual (5 steps between -2 and +2)/Sunny Weather Coverage: 100% Live View: Continuous Live View (LCD/EVF Auto, selectable) Real-time image adjustment display: Reflects: exposure compensation, white balance, creative style Histogram: Yes (On/off) Grid Display: Yes (On/off) Customization: Grid, Histogram Grid Line |
| Focus Control |
Focus System: TTL phase detection AF (CCD line sensors) Focus Points: 15 points (3 points cross type) AF Modes: Single-shot AF(AF-S), Continuous AF(AF-C), Auto selectable(AF-A) Focus Area: Wide (auto, 15 points), Zone, Spot, Local (15 local areas selectable) Focus Sensitivity: -2 EV to +17 EV (at ISO100 equivalent with F1.4 lens attached) Tracking Focus, Predictive control (AF-A,AF-C), Focus lock, Eye-start AF AF Illuminator: Built-in flash, Range: approx. 3' - 15' (1m-5m) |
| Metering System |
Advanced 1200-zone evaluative metering Metering Modes: Multi-segment, Center-weighted, Spot Metering Sensitivity: -2EV to 17EV (at ISO 100 equivalent w/ f/1.4 lens) |
| Exposure Compensation |
±2.0 EV (in 0.3 EV steps) |
| Exposure Settings |
iAUTO, Flash Off, Superior Auto, Scene Selection, Sweep Panorama, 3D Sweep Panorama, Tele-zoom Continuous Advance Priority AE, Movie, Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M) |
| Scene Mode(s) |
Portrait, Landscape, Macro, Sports Action, Sunset, Night Portrait, Night View, Hand-held Twilight |
| Picture Effect(s) |
11 modes (15 effects): Posterization (Color, B/W), Pop Color,Retro Photo, Partial Color (R,G,B,Y), High Contrast Monochrome, Toy Camera, SoftHigh-key, Soft Focus, HDR Painting, Rich-tone Monochrome, Miniature |
| D-Range Optimizer |
Off, Dynamic Range Optimizer (Auto/Level), Auto High Dynamic Range (Off, Auto Exposure Difference, Exposure difference Level (1-6EV, 1.0EV step)) |
| Auto Exposure Lock |
Available with AE lock button. AE is also locked when focus is locked in multi-segment metering mode. |
| Creative Style |
Standard, Vivid, Portrait, Landscape, Sunset, B/W (Contrast, Saturation, Sharpness adjustable in +/-3 steps) |
| ISO |
Auto: 100 - 3200; Selectable: 100 - 16000; Multi Frame NR (up to ISO 25600) |
| Noise Reduction |
Long exp. NR: (On/Off, available of shutter speeds longer than 1 sec.) High ISO NR: (High/Normal/Low) Multi Frame NR: (Auto/ISO100-25600) |
| White Balance Mode |
Auto WB, Daylight, Shade, Cloudy, Incandescent, Fluorescent (Warm white/Cool white/Day white/Daylight), Flash, C. Temp 2500 to 9900K, C Filter G7 to M7, 15-step, Custom, AWB micro adjustment |
| Drive System |
Burst Buffer: JPEG Standard (16 shots) JPEG Fine (15 shots) RAW (7 shots) RAW+JPEG (6 shots) Tele-zoom High Speed Shooting (Standard: 18 shots; Fine: 17 shots) Continuous Shooting Speed: Continuous (Hi: up to 5.5 fps, Lo: up to 2.5 fps) Tele-zoom Continuous Advance Priority AF High Speed (7fps) Drive Mode: Single-shot, Continuous shooting (Hi/Lo selectable), Self-timer (10/2 sec delay selectable), Remote commander (RM-L1AM Sold Separately), Bracketing |
| Flash Sync Speed |
Flash Sync Speed: 1/160 seconds |
| Self-timer |
2-sec. or 10-sec. delay, |
| Shutter Speeds |
1/4000 to 30 seconds, bulb |
| Shutter Type |
Electronically-controlled, vertical-traverse, focal-plane shutter |
| Flash |
Flash Type: Built-in, Pop-up Auto Guide Number: 10 (in meters at ISO100) Flash Compensation: +/-2EV in 0.3EV steps Flash Coverage: 18mm (focal-length printed on the lens body) Recycling Time: Approx. 4 sec. Flash Bracketing: 3 exposures in 0.3/0.7 EV steps Flash Metering System: ADI, Pre-flash TTL |
| Flash Modes |
Auto, Fill-flash, Slow Sync., Rear Sync., Hi-speed sync., Red-eye reduction (on/off selectable for Autoflash and fill-flash mode), Wireless |
| Advanced Features |
Advanced User Interface: Easy-to-understand Graphic Display and on-screen Help Guide User-friendly function menu Anti Motion Blur: 6-image layering Auto High Dynamic Range: Yes, (Off/On, Auto Exposure Difference, Exposure difference Level (1-6 EV at 1.0 EV step) Sweep Panorama: Yes (2D/3D) Face Detection: Off, Auto, Child Priority, Adult Priority (up to 8 faces detectable) Smile Shutter technology: Yes - Off, Slight, Normal, Big SteadyShot INSIDE in-body image stabilization |
| Interface |
Microphone Input: Yes Accessory Shoe: Yes (Alpha) BRAVIA® Sync: Yes, via HDMI with compatible BRAVIA HDTV HD Output: HDMI (TypeC mini) Memory Card Slot: Dual memory card slot: Memory Stick PRO Duo/Pro-HG Duo media - SD, SDHC and SDXC memory card PhotoTV HD: Yes, with BRAVIA Sync enabled HDTV and HDMI cable USB Port(s): USB2.0 Hi-speed (mass-storage, PTP) |
| Weights and Measurements |
Dimensions (Approx.): Approx. 4-7/8 x 3-5/8 x 3-1/3" (124.4 x 92 x 84.7mm) (W/H/D) excl grip & lens mount Weight (Approx.): Approx. 1.12 lb 17.8 oz (506g) (w/battery & media) Approx. 1 lb/ 15.8 oz (448g) (excl battery, lens & media) |
| Power |
Battery Type: InfoLITHIUM® NP-FW50 (7.2V) Number of Still Images: Approx. 450 images with viewfinder, 500 images with LCD monitor (CIPA standard) |
| Software |
Supplied Software: PlayMemories Home, Image Data Converter SR 3.2 Image Data Lightbox SR 2.2 Operating System Compatibility: Windows XP SP3 (64-bit and Starter Editions are not supported,Windows Image Mastering API(IMAPI)Ver.2.0 or later is required to use the function for creating discs.) Windows Vista SP2 (Starter Edition is not supported) Windows 7; Mac OS X(v10.4-v10.6) (Image Data Converter & Image Data Lightbox only, PMB is not Mac compatible) |
| Service and Warranty Information |
Limited Warranty Term: 1 Year Parts & Labor |
