JBL AM7200/64 High Power Mid-High Frequency Loudspeaker with Rotatable Horn, 60x40 degree Coverage, White

JBL
SKU: JBLAM720064W MFR: AM7200/64-WH
Free Shipping

See all shipping options

In Stock Online Usually ships within 1-2 Days learn more

Protect Your Investment:

Add a Protection Plan
  • Add a protection plan
  • New Leaf 3 Year Extended Warranty + $114.95
  • New Leaf 3 Year Drops & Spills Extra Protection + $174.95
  • New Leaf 5 Year Drops & Spills Extra Protection + $399.95

Our Price

$2,646.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About JBL AM7200/64

The JBL AM7200/64-WH is a high power mid-high frequency loudspeaker system comprised of one 200 mm (8") CMCD (Cone Midrange Compression Driver) and one 38 mm (1.5") exit/75 mm (3") voice-coil HF compression driver. The multi-band PT (Progressive Transition) mid-high frequency waveguide provides well-controlled 60 degree x 40 degree coverage and is rotatable for cabinet positioning in either horizontal or vertical orientation. High-slope crossovers minimize band overlap and well-controlled off-axis response enhances arrayability.

The cabinet is fitted with M10 threaded suspension points. Pre-engineered array bracketry is available. The AM7200/64-WH is part of JBL's AE (Application Engineered) series, a versatile family of loudspeakers for a wide variety of fixed installation applications.

JBL AM7200/64 Features

  • 60 x 40 coverage, rotatable for use in either vertical or horizontal orientation
  • CMCD (Cone Midrange Compression Driver) provides low Midrange distortion, increased Sensitivity, extended Bandwidth and improved Phase coherency
  • 2432H High-Frequency Compression Driver
  • PT (Progressive Transition) Waveguide for excellent pattern control with low distortion
  • Bi-Amp/Passive Switchable

JBL AM7200/64 Specifications

Frequency Range (-10 dB)
260 Hz - 20 kHz
Frequency Response (±3 dB)
330 Hz - 18 kHz
Coverage Pattern
: 60deg. x 40deg., rotatable waveguide
Directivity Factor (Q)
20
Directivity Index (DI)
13 dB
Crossover Modes
Bi-amp/Passive switchable
Crossover Frequency
2.3 kHz
Transducer Power Rating (AES)
MF: 350 W (1400 W peak), 2 hrs
HF: 100 W (400 W peak), 2 hrs
Long-Term System Power Rating (IEC)
MF/HF: 200 W (800 W peak), 100 hrs
Maximum SPL
Bi-amp mode:
MF: 133 dB-SPL cont avg (139 dB peak)
HF: 135 dB-SPL cont avg (141 dB peak)
Passive mode:
MF/HF: 133 dB-SPL cont avg (139 dB peak)
System Sensitivity (1W @ 1m)
Passive mode: 108 dB SPL
Transducers: Midrange Driver
JBL CMCD-82H Cone Midrange Compression Driver with integral 200 mm (8 in) diameter Differential Drive dual voice-coil internal driver
Nominal Impedance
8 ohms
Sensitivity (1W @ 1m)
108 dB SPL
Transducers: High Frequency Driver
JBL 2432H, 38 mm (1.5 in) exit compression driver, 75 mm (3 in) voice coil
HF Nominal Impedance
8 ohms
HF Sensitivity (1W @ 1m)
115 dB SPL
Waveguide
PT-K64MH
Enclosure
Trapezoidal with 15 degree side angles, 16 mm (5/8 in) exterior grade 11-ply Finnish birch plywood
Suspension Attachment
13 points (3 top, 3 bottom, 2 each side, 3 rear), M10 threaded hardware
Input Connector
NL4 Neutrik Speakon and CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AWG) wire or max width 9 mm (.375 in) spade lugs. Speakon in parallel with barrier strip for loop-through
Environmental Specifications
Mil-Std 810; IP-x3 per IEC529
Dimensions (H x W x D)
548 x 561 x 657 mm / 21.6 x 22.1 x 25.9" (in vertical cabinet orientation)
Weight
27.2 kg (60 lb)
