JBL SRX738F 18" Three-Way Speaker, Flytrack & Suspension, 44Hz-20kHz Frequency Response

The JBL SRX738F 18" Three-Way Speaker is for applications requiring suspension. The F-version offers the option of selecting economical, forged eyebolts (not included) for fixed installation or the convenience of detachable track fittings (not included) for portable applications.

The JBL SRX738F combines the performance of a subwoofer-equipped system with single-enclosure ease of use. The 2268H 457 mm (18") patented Differential Drive woofer delivers impressive low-frequency extension without a sub. The midrange is covered by JBL's CMCD (Cone Midrange Compression Driver) technology using a 2169H 203 mm (8") driver.

The CMCD design provides very low midrange distortion, increased sensitivity, extended bandwidth and improved phase coherence. The multi-band, Progressive Transition waveguide assembly also hosts a 75 mm (3") voice coil 2431H compression driver. Bi-amp or full-range passive operation may be selected by means of an internal network mode selector.

The attractive CNC-machined, 16-gauge steel grille wraps around the sides of the enclosure so there are no protruding lips on the front of the box to create acoustical interference. The grilles are internally lined with acoustically transparent foam to provide additional driver protection and give a very professional appearance.
