PowerDsine 5524G PoE 24-Port 30 Watts Midspan
PowerDsine

PowerDsine 5524G PoE 24-Port 30 Watts Midspan, 10/100/1000 Mbps Pass Through Data Rate, 100 to 240 VAC Input Power

SKU: JF5524GM MFR: PD-5524G/ACDC/M
Write a Review
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 / 212-741-0052

$1,638.05 Was
- $8.19 Price Drop

Our Price

$1,629.86
Free Shipping (USA)
Qty:

Add to Wishlist
OverviewFeaturesTech Specs
Its never too late...Click by 8! Same day shipping.

About this item

The PowerDsine 5524G PoE 24-Port 30 Watts Midspan delivers up to 30 watts (W) of Power over Ethernet (PoE) to network devices including IP cameras, access control systems, thin clients and other Ethernet end terminals.

PD-5524G EEPoE Midspan is unique in their ability to deliver power over all 4 pairs of the Cat 5 or better cable, dissipating 50% less power than PoE Switches and 2-pair Midspan, while complying with the IEEE802.3at-2009 standard.

EEPoE allows reduced power dissipation to new powered devices and also to the huge installed base of over 100 million existing IEEE standard-compliant PDs worldwide.

With the midspan's plug-and-play installation, it is easily and cost effectively implemented leveraging an existing Ethernet infrastructure while at the same time providing the assurance of a future proof network.

Key Features

  • PoE over 4-pair's
  • Powers all IEEE8O2.3af and IEEEBO2.3 at devices
  • High efficiency, dissipating 50% less power than 2-pair switches and Midspan
  • PowerView Pro secure, remote SNMPv3 web-based management
  • Supports both lPv4 and lPv6 addressing
  • Plug-and-play installation

Technical Specs

No. of Ports 24
Pass Through Data Rates 10/100/1000 Mbps
Power over Ethernet Output Pin Assignment and Polarity:
Output Data Pairs 1/2 (-) and 3/6 (+)
Spare Pairs 4/5 (+), 7/8 (-)
Output Power Voltage: 55Vdc
User Port Power: 30W guaranteed
Aggregate Power: 450W
Input Power AC Input Voltage: 100 to 240 Vac
Requirements DC Input: RPS or another PD-5524G midspan
AC Input Current:
5.5A @ 110 Vac; 2.75A
AC Frequency: 50 to 60 Hz
Management PowerView Pro included
Indicators System Indicator: AC Power (Green)
User Indicator: Channel Power (Green/Orange)
Connectors PoE ports and management port:
Shielded RJ-45, EIA 568A and 568B
Console Port: USB Connector Type B
DC Connector: DC Block Terminal
RPS Com Connector: HD-D-sub-15
Operating Ambient Temperature 32deg. to 104deg.F (0 to 40deg.C
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -4deg. to 158deg.F (-20deg. to 70deg.C)
Storage Humidity 5% to 95%, Non-condensing
Operating Altitude -1000 to 10,000 ft. (-304.8 to 3048 m)
Thermal Rating 365 BTU/Hr
Regulatory Compliance IEEE 802.3af (PoE, PoH Type 1), IEEE 802.3at (PoE+ including 2-event, PoH Type 2), RoHS Compliant, VCCI, CE, C-Tick
Safety Approvals UL/cUL Per EN 60950-1
GS Mark Per EN 60950-1
Dimensions 438 x 272 x 44mm / 17.3 x 10.8 x 1.75"
Weight 14.3 lbs (6.5 kg)
