| Image sensor |
CCD sensor |
| Sensor size |
Leica Pro format 45 x 30 (mm) |
| Aspect ratio |
3:2 |
| Sensor resolution |
37.5 MP 7500 x 5000 pixel |
| Pixel size |
6um |
| Micro lenses on sensor |
Yes, with micro lens shift |
| Dynamic range |
12 f-stops |
| Low-pass filter |
No, for maximum detail transfer |
| IR filter |
On Sensor |
| Color depth |
16 bit |
| Working color space (JPEG) |
sRGB, AdobeRGB, ECI-RGB V2 |
| Image settings (JPEG) |
Contrast, Sharpness, Saturation |
| ISO range |
autoISO, ISO100, ISO200, ISO400, ISO800, ISO1600 |
| White balance |
autoWB, daylight 5200K, cloudy 6000K, shade 7000K, tungsten light 3200K, HMI 5600K, Neon warm 4000K, Neon cool 4500K, Flash 5400K, Gray card, Color temperature 2000K to 13100K |
| Exposure modes |
Single Continuous Self-timer 2s with mirror-up function Self-timer 12s with mirror-up function M (manual), P (program automatic), T (time pre-select), A (aperture priority), B (BULB with time pre-select) |
| Mirror-up function |
Yes |
| Image data format |
DNG, DNG lossless compressed, JPEG fine/standard, 37.5 MP, 9.3 MP 2.3 MP, DNG+JPEG |
| File sizes |
DNG: approx. 72MB, DNG lossless compressed: 42MB JPEG: approx. 1MB-16MB (depending on image content, compression ratio and resolution) |
| Storage media |
SD (SDXC), CF (UDMA7), external (PC) |
| Continuous shooting mode |
(Burst frequency: max. number of pictures / max. resolution) 2 B/s: max. number 100 / 10 MP max. resolution 5 B/s: max. number 100 / 10 MP max. resolution 11 B/s: max. number 12/ 10 MP max. resolution 40 B/s: max. number 40 / 5 MP max. resolution B/s: max. number 60 / 2.5 MP max. resolution |
| Memory |
2GB RAM |
| Frame rate |
Max 1.5 fps |
| Buffer memory |
DNG: up to 28 consecutive images, DNG lossless compressed: up to 32 consecutive images JPEG: unlimited |
| Menu languages |
English, French, German, Spanish, Italian, Japanese, Chinese traditional and simple, Russian |
| Computer interface |
High-speed USB2.0 |
| Exposure metering |
Open aperture measurement through lens TTL |
| Exposure metering method |
Multi-pattern, center-weighted, spot (3.5 %) |
| AE lock |
Shutter release or AF/AE memory button (on back of camera) |
| Exposure compensation |
+ /- 3 EV in 1/2 f-stops |
| Bracketing |
Yes, 3 or 5 images, 1/2EV, 1EV, 2EV, 3EV automatic mode (all images captured with a single press of the shutter release) |
| Light metering range |
Spot (ISO100, f=2.5 ) +2.1EV to +20EV Multi-pattern/center-weighted (ISO100, f=2.5 ) +1.1EV to +20EV |
| Shutter |
Focal plane shutter (microprocessor-controlled shutter) Central shutter (with Leica S central shutter lenses) |
| Shutter speeds |
1/4000s to 125s |
| Flash control |
SCA 3502 max. compatibility LEICA SF58 TTL, TTL-HSS (up to 1/4000s), A, M, Strobe, start or end of exposure |
| Flash synchronization |
Focal plane shutter: 1/125s with Leica SF58 in HSS (high-speed sync) up to 1/4000s Central shutter: 1/1000s |
| Flash synchronization point |
Start of exposure End of exposure |
| Flash sockets |
Accessory shoe, Flash sync socket, LEMO synchronous flash |
| Focus |
Central cross type sensor (phased autofocus) |
| Focus methods |
AFs (sharpness priority), AFc (shutter release priority) AF (can be can be corrected at any time by manual focus) MF (manual focus with focus indicator on back panel display) |
| Focus memory |
Shutter release pressure point, AF/AE memory button |
| Viewfinder |
Pentaprism type |
| Diopter compensation |
-3 dpt to +1dpt |
| Viewfinder coverage |
Approx. 98% |
| Viewfinder magnification |
0.86 with 70mm lens, infinity, 0 diopter |
| Software |
Adobe Photoshop Lightroom 4 |
| Eyepieces |
Mag. Viewfinder shutter (included) |
| Viewfinder information |
Horizon, exposure time, exposure metering mode, aperture, flash status, exposure balance, flash synchronization indicator, focus indicator, exposure metering method, exposure compensation, remaining shots (on storage medium), buffer, warnings, ISO |
| Top plate display |
Colored OLED |
| Back panel display |
3" brilliant TFT LCD, Resolution: 921,600 pixels, Color space: sRGB, 16 million colors, Frame coverage: 100%, View angle: 170 deg., Cover glass: Corning Gorilla Glass |
| Power supply |
Leica Battery S Lithium-ion battery, 7.4V, 2100mAh, Leica AC Adapter S |
