| Standards |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Radio Frequency |
2.4 GHz, 5.0 GHz (Selectable) |
| LEDs |
1 - Status / Activity |
| No. of Antennas |
3 Internal Antennas |
| Detachable (y/n) |
No |
| Transmitted Power |
802.11a: 14 +/- 2.0 dBm
802.11b: 15 +/- 2.0 dBm
802.11g: 15 +/- 2.0 dBm
802.11n:
MCS15 (20MHz): 14 +/- 2.0 dBm
MCS8 (20MHz): 14 +/- 2.0 dBm
MCS7 (20MHz): 14 +/- 2.0 dBm
MCS0 (20MHz): 14 +/- 2.0 dBm
MCS15 (40MHz): 13 +/- 2.0 dBm
MCS8 (40MHz): 13 +/- 2.0 dBm
MCS7 (40MHz): 13 +/- 2.0 dBm
MCS0 (40MHz): 13 +/- 2.0 dBm |
| Receive Sensitivity |
802.11b: (+2/-4 dB)
DBPSK: -96 dBm Typical
DQPSK: -96 dBm Typical
CCK: -90 dBm Typical
802.11g: (+2/-4 dB)
BPSK: -93 dBm Typical
QPSK: -90 dBm Typical
16-QAM: -84 dBm Typical
64-QAM: -76 dBm Typical
802.11n: (+2/-4 dB)
MCS15 (20MHz): -72 dBm Typical
MCS0 (20MHz): -90 dBm Typical
MCS15 (40MHz): -68 dBm Typical
MCS0 (40MHz): -87 dBm Typical |
| Antenna Gain in dBi |
2.4GHz Wireless @ ± (Typical): 3dB +/-1dB
5GHz Wireless @ ± (Typical): 4dB +/- 1dB |
| Power Consumption |
TX (20MHz, MCS15): 364 mA Typical
TX (20MHz, MCS8): 447 mA Typical
RX (20MHz): 176 mA Typical
TX (40MHz, MCS15): 316 mA Typical
TX (40MHz, MCS8): 430 mA Typical
RX (40MHz): 173 mA Typical
Standby: 48 mA Typical
Radio Off: 48 mA Typical |
| Security |
WEP 64/128-bit, WPA-TKIP and WPA2-Personal & Enterprise (AES/TKIP), WPS |
| Security key bits |
Up to 256-bit encryption |
| OS Requirements |
Windows XP SP3 (32-bit), Vista SP1/SP2 (32 & 64-bit), Win7 (32-bit & 64-bit) |
| Certification |
FCC, CE, IC, Wi-Fi A/B/G/N |
| Operating Temp. |
0deg.C - 40deg.C (32deg.F - 104deg.F) |
| Storage Temp. |
-20deg.C - 70deg.C (14deg.F - 158deg.F) |
| Operating Humidity |
10% to 85% Non-Condensing |
| Storage Humidity |
5% to 90% Non-condensing |
| Dimensions (W x H x D) |
23.8 x 9 x 73mm/0.937 x 0.35 x 2.87" |
| Weight |
0.01kg/0.022lb |
