Mole-Richardson 575 Watt HMI DayLite Par Kit with Case

See all Mole-Richardson items
SKU: MR662101 MFR: 662101
Free Shipping

See all shipping options

In Stock Online - Usually ships within 1-2 Days learn more

Made in USA

Our Price

$7,995.95
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

Mole-Richardson : Picture 1 regular $7,995.95

About Mole-Richardson

The Mole Richardson 575 Watt HMI DayLite Par Kit includes dimmable electronic ballast, 25' cable, barn doors, 4 lens set and scrims. A hard case is also included. The DayLite PAR is designed for cinema, TV and other media events where high output and daylight color balance are required to meet the challenge of ambient conditions.

Fabricated from solid cast aluminum, it benefits from improved ventilation and features a Brytal Aluminum parabolic reflector which boasts 95% reflectivity. The fixture has been fitted with a swing out door for quick access to safety and igniter switches.

Lamping is achieved via a hinged, locking front door which is fitted with a stainless safety screen that sits over the reflector. Tactile and visual focal indicators denote lamp position which can be tweaked when using the supplied lenses to optimize beam pattern.

When fitted with a 575 watt HMI bulb and no lens, this fixture will throw a beam of light of 4670 foot-candles 2.1' in diameter from a distance of 20'. Mounting one of the four included lenses will alter the beam spread and diminish the light output.

Mole-Richardson Features

  • Dimmable to 50% of full power
  • Multi-Voltage - 90-260VAC, auto-sensing
  • Microprocessor control, constant power output
  • Scrims diminish the intensity of the light
  • 25' Head-to-ballast cable

Mole-Richardson Specifications

Light Fixture: Rating
575 Watts max
Light Fixture: Socket (Lampholder)
G22, Heavy duty electrical grade porcelain body with friction type bi-post brass inserts.
Light Fixture: Lens (Condenser)
4 accessory lenses included
Light Fixture: Mounting
5/8" (16 mm) standard stud
HMI Ballast: Rating
575 Watts, 90-260VAC
HMI Ballast: Cable
25', included
Dimensions
Light Fixture: 10.75x10.75x14.5" (27.3x27.3x36.8cm) without yoke
10.75x10.75x19.25" (27.3x27.3x49cm) with yoke
HMI Ballast: 6.25x11x7" (15.9x28x17.8cm)
Weight
Light Fixture: 13 lbs (5.9 kg) with cable
HMI Ballast: 10 lbs (4.5 kg)
Kit:63 lbs (28.6 kg)
Mfr #
662101
SKU
MR662101
