| Type |
6x4.5cm format (actual image size 56x41.5mm) Electronically controlled focal-plane shutter TTL multiple mode AE AF single lens reflex |
| Film Type |
120 roll film (16 exposures) 220 roll film (32 exposures) Polaroid Land Pack Film (100 & 600 series) |
| Lens Mount |
Mamiya 645 AF Mount |
| Viewfinder |
Fixed prism viewfinder magnification x0.71 Built-in Diopter adjustment -2.5 to +0.5 (separate diopter correction lenses provide adjustment ranges of -5 to -2 and 0 to +3) Built-in eyepiece shutter |
| Focusing Screen |
Interchangeable:Matte (supplied with camera) Grid (Checker) Manual Focus Microprism for M645 lenses |
| Field of View |
94% of actual image |
| AF System |
TTL phase-difference detection type, user-selectable focusing point (center, left, right or auto) |
| Detecting Device |
4 CCD line sensors in a | + | shape (area indicated on the focusing screen, 10.8 x 3.6mm) |
| Infrared AF Sub-Beam |
Activates automatically under low light, low contrast in Single (S) AF Mode Switchable On/Off. Range: 29.5 ft. with 80mm f/2.8 AF lens Automatic switching to flash unit's built-in sub-beam when Metz flash unit is attached with SCA 3952 adapter |
| AF Lock |
Half-press on shutter release and AF Lock Button |
| Setting Steps |
Shutter speed and aperture both can be set in 1/3 or 1/2 steps Electronic dial lock (in X, M, Av and Tv exposure modes) |
| Metering Range |
EV 2 to EV 19 (with ISO 100 film, f/2.8 lens) |
| Exposure Compensation |
+/-3 EV or +/- 5EV (1/3, 1/2 or 1 steps) |
| Film Speed |
ISO 25 to 6400 |
| Sync Terminal |
X contact (sync speed 1/125th sec. and slower) |
| Tripod Socket |
1/4 inch and 3/8 inch included |
| Power Requirements |
6 AA batteries (alkaline-magnesium or rechargeable Nickel-metal hydride) |
| Custom Functions |
36 custom settings |
| Dimensions |
6"(W) x 5"(H) x 7"(D) (153 x 128 x 184mm) |
| Weight |
61oz. (1730g). w/o batteries |
| Warranty |
Mamiya warranty |
