| Leaf Aptus-II: Imaging Sensor |
54 x 40mm CCD |
| Leaf Aptus-II: Effective Resolution |
80Mp |
| Leaf Aptus-II: Pixels |
10,320 x 7,752 |
| Leaf Aptus-II: Capture Rate |
1.5 frames/second
Lens factor: 1.04 |
| Leaf Aptus-II: File Format |
Leaf MOS file format: Phase One Capture One; Leaf Capture; Adobe Lightroom; Adobe Photoshop / Adobe Camera RAW |
| Leaf Aptus-II: File Size |
MOS File Size - RAW Uncompressed: 165MB
MOS File Size - RAW Compressed: 107MB
TIFF 16-bit: 480MB
8 bit RGB: 240MB
8 bit CMYK: 274MB |
| Leaf Aptus-II: ISO |
50-800 ISO sensitivity |
| Leaf Aptus-II: Dynamic Range |
12 f/stops |
| Leaf Aptus-II: Exposure Time |
1/10,000 - 32 seconds |
| Leaf Aptus-II: Color Depth |
16 bits (65,536 levels per channel) |
| Leaf Aptus-II: Color Management System |
16 profiles including factory profiles, plus optional own custom camera profiles |
| Leaf Aptus-II: Utilities |
Management: Preshoot file naming, image flagging, full browsing, creation of job folders, custom file annotations |
| Leaf Aptus-II: Images |
Viewing: Preview up to 20 images on one LCD screen, true 1:1 zoom
Measuring tools: Histogram, exposure alarms, average exposure meter, spot meter (f/stop) |
| Leaf Aptus-II: Connection |
FireWire 800 |
| Leaf Aptus-II: LCD |
3.5" / 6 x 7cm high-contrast LCD touch screen |
| Leaf Aptus-II: Languages |
English, German, French, Spanish, Italian, Chinese and Japanese |
| Leaf Aptus-II: Image Settings |
Custom and preset gray balance, ISO, selectable image-setting tags, IPTC and EXIF metadata |
| Leaf Aptus-II: Storage |
CF cards and high volume portable FireWire disks |
| Leaf Aptus-II: Operating Environment |
32 to 104Deg.F / 0 to 40Deg.C |
| Leaf Aptus-II: Power Supply |
Leaf battery - 2350mAh power |
| Camera Body: Camera Type |
6 x 4.5cm format, electronically controlled focal-plane shutter, TTL multiple mode AE, AF single lens reflex camera for digital backs |
| Camera Body: Image Size |
56 x 41.5mm (actual image) |
| Camera Body: Lens Mount |
Mamiya 645 AF Mount, compatible with M645 Mount (manual focus confirmation, focus aid, stopped-down exposure metering) |
| Camera Body: Shutter |
Touchscreen
Both the shutter speed and the aperture level can be set to 1/3 or speed and aperture 1/2 using the electronic dial lock function
AE 30 to 1/4000 sec. (1/8 step), manual 30 to 1/4000 sec. (1/2 or 1/3 steps), 1 min-60 sec. (1 step), X, bulb (Bulb, electronically controlled), Time, shutter curtain protection mechanism |
| Camera Body: Shutter Release |
Utilizes standard screw-in type cable release located on shutter button
Remote-Control Terminal: Located on the side of the body: Electromagnetic Cable Release RE401 is 5m and coiled; Electromagnetic Cable Release RE402 is 1m and is straight |
| Camera Body: Self Timer |
With shutter release mode selector 2 to 60sec. (default setting: 10sec., can be set in 1sec. steps between 2 and 10sec. and in 10sec steps between 10 and 60sec.) |
| Camera Body: Flash Synchronization |
X contact point, 1/125 second (focal plane), 1/800 or 1/1600 second (leaf shutter) |
| Camera Body: Exposure Metering |
Aperture-priority AE, shutter-priority AE, programmed AE (PH, PL setting possible) and manual
TTL metering, center-weighted average (AV), spot (S) and variable ratio (A-S auto) |
| Camera Body: Exposure Bracketing |
Enabled with Auto-Bracketing button (2 or 3 frames selectable), 0.3, 05, 0.7, 1EV step units selectable |
| Camera Body: Exposure Compensation |
Expandable to ±5 EV |
| Camera Body: Depth-of-Field Preview |
Preview Button on body |
| Camera Body: Viewfinder |
Fixed prism viewfinder magnification x0.71; built-in diopter adjustment (-2.5 to +0.5, optional diopter correction lenses provide adjustment ranges of -5 to -2 diopter and 0 to +3 diopter); built-in eye-piece shutter |
| Camera Body: Viewfinder Info |
Focus mark, defocus mark, warning mark, aperture value, shutter speed, metering mode (A, S, A/S), exposure compensation value (difference between set value and metered value) and flash ready/OK lamp with TTL Metz connection. |
| Camera Body: Focusing System |
TTL phase difference detection method; sensor: CC D line sensor (I+I type); operating range: EV0 to EV18 (ISO 100) |
| Camera Body: Power Source |
6 AA-size batteries (alkaline-magnesium, lithium, nickel-hydride or nickel-cadmium rechargeable batteries) |
| Camera Body: Custom Functions |
19 items |
| LS D Lens: Focal Length |
80 mm |
| LS D Lens: Aperture |
Maximum: f/2.8
Minimum: f/22 |
| LS D Lens: camera Mount Type |
Mamiya M645 Mount |
| LS D Lens: Format Compatibility |
Digital Medium Format Sensor |
| LS D Lens: Angle of View |
47Deg. |
| LS D Lens: Minimum Focus Distance |
27.6" (70 cm) |
| LS D Lens: Magnification |
0.15x |
| LS D Lens: Maximum Reproduction Ratio |
1:6.6 |
| LS D Lens: Groups/Elements |
5/6 |
| LS D Lens: Image Stabilization |
No |
| LS D Lens: Autofocus |
Yes |
| LS D Lens: Tripod Collar |
No |
| LS D Lens: Flash Synchronization |
Shutter speed up to 1/1600 |
| LS D Lens: Exposure Control |
1/800 - 1 sec |
| LS D Lens: Filter Thread |
72 mm |
| Dimension |
Leaf Aptus-II: 3.7 x 3.2 x 2.3" / 95 x 82 x 59mm
Camera Body: 6 x 5 x 6" (15.3 x 12.8 x 15.2 cm)
LS D Lens: 2.03 x 3.17" (5.15 x 8.05 cm) |
| Weight |
Leaf Aptus-II: 1.3 lb / 600g
Camera Body: 2.3 lbs (1.04 kg) (body only)
LS D Lens: 15.87 oz (450 g) |
