NEC MultiSync PA301W-BK-SV 30" Widescreen Color-Critical LCD Monitor w/IPS
NEC

NEC MultiSync PA301W 30" Widescreen Color-Critical LCD Monitor with IPS Technology, 2560x1600 Resolution, 1000:1 Contrast Ratio, 7ms Response Time

SKU: NCPA301WBKSV MFR: PA301W-BK-SV
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 / 212-741-0052

$2,492.47 Special Price Available
Qty:

Add to Wishlist

About the NEC PA301W-BK-SV

The MultiSync PA301W 30" Widescreen Color-Critical Desktop LCD Monitor with SpectraView II from NEC is a serious, high-performance LCD display, designed to handle your most demanding color-critical projects. This LCD features a 1000:1 contrast ratio, a 2560 x 1600 native resolution with a wide color gamut and 350cd/m2 of brightness. In addition, it clocks in a super-speedy 7ms response time.

When using the monitor, you'll have at your disposal 1.07 billion out of 4.3 trillion displayable colors. Designed for professionals, the unique screen provides 98.2% coverage of the AdobeRGB Color Space, ensuring that what you see on the screen corresponds to what you'll see on the final product. For tweaking those colors, the included SpectraViewII Color Calibration Solution allows you to calibrate your monitor for consistent output. The monitor also features a programmable 14-bit 3D Lookup Table (LUT), among many other color-related features.

So as to establish connections to computers and other devices, this LCD monitor has two DVI-D ports, one DisplayPort and a USB 2.0 hub. The hub itself features two upstream ports and three downstream ports. Plus, the hub is integrated with DisplaySync Pro, so you can control two computers with only one keyboard and mouse hooked up to the monitor.

NEC PA301W-BK-SV Includes

  • NEC MultiSync PA301W 30" Widescreen Color-Critical LCD Monitor
  • Power Cord
  • DVI Cable
  • USB Cable
  • 6.6' Mini DisplayPort Male to DisplayPort Male Cable (Black)
  • Mounting Screw
  • SpectraViewII Color Calibration Kit (SVII-PRO-KIT)
  • NEC 4 Years Warranty

NEC PA301W-BK-SV Features

  • 98.2% coverage of AdobeRGB color space
  • This monitor offers superior screen performance with a 1000:1 contrast ratio, a 2560 x 1600 native resolution and 350cd/m2 of brightness
  • Supports internal programmable 14-bit 3D lookup tables (LUTs) for calibration
  • DisplaySync Pro controls two computers with only one keyboard and mouse
  • Color Vision Emulation for type P/D/T supporting Color Universal Design
  • The monitor utilizes the SpectraView II Color Calibration Solution, which includes software and colorimeter, so as to help the display achieve accurate, consistent and repeatable color performance
  • The MultiProfiler software provides complete control over the five picture modes, including the loading of any ICC profile directly into the monitor for optimal color space matching
  • The monitor allows for wide connectivity with one DisplayPort, two DVI-D inputs and a USB hub
  • DisplayPort is designed to be the future-ready, scalable solution for high performance digital display connectivity. It enables high resolutions, fast refresh rates and deep color depths over standard cables
  • An all-digital interface for flat panel monitors which is signal compatible with DVI. As a DVI-based digital only connection, only a simple adapter is necessary for compatibility between DFP and other DVI-based digital connectors such as DVI and P&D
  • The VESA standard for digital flat panel monitor interfaces. It is more robust than DFP since it allows for other options off a signal connector. The VESA committee has recognized that DFP is a subset of P&D
  • Allows users to adjust the monitor to the orientation that best fits their application, choosing Landscape orientation for wide documents or Portrait orientation for the ability to preview a full page on one screen at one time
  • Provides the ideal solution for environments requiring superior image quality but with size and weight limitations. The monitor's small footprint and low weight allow it to be moved or transported easily from one location to another
  • Allows you to adjust the colors on your screen and customize the color accuracy of your monitor to a variety of standards
  • The sRGB standard provides the monitor with a uniform color profile. This assures that the colors displayed on the monitor are exactly the same as on the color printout (with sRGB supporting operating system and sRGB printer)
  • Allow you to quickly and easily adjust all elements of your screen image via simple to use onscreen menus
  • Enhanced human ergonomics to improve the working environment, protect the health of the user and save money
  • The Microsoft solution with the Windows operating system facilitates setup and installation by allowing the monitor to send its capabilities (such as screen size and resolutions supported) directly to your computer, automatically optimizing display performance
  • Provides innovative power-saving methods that allow the monitor to shift to a lower power consumption level when on but not in use, saving two-thirds of your monitor energy costs, reducing emissions and lowering the air conditioning costs of the workplace
  • Automatically adjusts monitor to the display card's scanning frequency, thus displaying the resolution required
  • Allows you to use the entire screen area in most resolutions, significantly expanding image size
  • Allows the user to be able to see the monitor from any angle (178deg.) from any orientation - Portrait or Landscape
  • Allows users to connect their MultiSync monitor to any VESA standard third party mounting arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant device
  • This is a ground-breaking software family, developed by NEC Display Solutions, providing intuitive access to all monitor setting controls and remote diagnosis via the Windows interface, based upon the VESA standard, DDC/CI
  • An optimized color management standard which allows for color matching on computer displays and other peripherals. The sRGB, which is based on the calibrated color space, allows for optimal color representation and backward compatibility with other common color standards

NEC PA301W-BK-SV Specifications

Display Type LCD Flat Panel with IPS technology
Viewable Size 29.8" Widescreen
Brightness 350cd/m2
Contrast Ratio 1000:1
Viewing Angle 178deg. Vertical, 178deg. Horizontal (89U/89D/89L/89R) at CR>1
Pixel Dot Pitch 0.25mm
Response Time 7ms Gray-to-Gray
Colors Supported Adobe RGB Coverage/Size: 98.2% / 106.7%
NTSC Coverage/Size: 93.3% / 102%
sRGB Coverage/Size: 100% / 144%
Displayable Colors 1.07 billion out of 4.3 trillion
Internal Interface DisplayPort and DVI-D Dual Link
Frequency Horizontal: 31.5 to 98.7 kHz (Digital only)
Vertical: 30 to 87 Hz
Resolution 2560 x 1600
Analog No
Digital 2x DVI-D
1x DisplayPort
Hub Ports 2x USB 2.0 upstream ports
3x USB 2.0 downstream ports
Mount VESA 100 x 100 mm Configuration
VESA 200 x 100 mm Configuration
Buttons Power, Input, Left, Right Up, Down, Reset/PIP
On-Screen Display Yes
Auto Configuration Yes
Touch Screen No
Tilt/Swivel Range Tilt: Yes
Swivel: Yes
Height: Yes
Pivot: Yes
Safety Compliance UL / C-UL, CE, Gost/PCT, PSB, CCC, NOM, TUV GS, FCC Class B/Canadian DOC, C-tick, MPR III, VCCI (class 2)
Environmental Compliance TCO: 5.0
RoHS: Yes
System Requirements PC or Mac with DVI or DisplayPort Output
SpectraView Software Requirements: Apple Mac OS X 10.2.8 or higher/Microsoft Windows 2000, XP, XP x64, Server 2003 or Vista 32 bit. At least one available USB port for GretagMacbeth color sensor
Power Requirements AC 100-120V / AC 220-240V
Power Consumption Typical: 155W (without USB active) / 161W (with USB active)
Power Saving Mode: 1.7W (without USB active) / 12W (with USB active)
Environmental Requirements Operating Temperature: 41deg. to 95deg.F / 5deg. to 35deg.C
Storage Temperature: 14deg. to 140deg.F / -10deg. to 60deg.C
Operating Humidity: 30% to 80% (non-condensing)
Storage Humidity: 10% to 85%
Operating Altitude: Up to 10,000' / 3048 m
Storage Altitude: Up to 40,000' / 12,192 m
Dimensions (WxHxD) With Stand: 27.1x18.4 to 24.3x11.9" / 68.83x46.74 to 61.72x30.23 cm
Without Stand: 27.1x17.6x4.9" / 68.83x44.7x12.45 cm
Weight With Stand: 41.5 lbs / 18.8 kg
Without Stand: 27.6 lbs / 12.5 kg
