| Magnification |
12x - 42x |
| Objective / Field of View |
56mm / 8.2' (2.5m) @ 12x at 100 yds.(100m), 2.4' (0.73m) @ 42x at 100 yds.(100m) |
| Main (Center) Tube Diameter |
30mm |
| Objective Tube Diameter |
65mm |
| Eyepiece Tube Diameter |
43mm |
| Lens Coatings |
Broadband Multi-coated |
| Reticle |
Illuminated CH-2 |
| Reticle Image Plane (Magnifying) |
Second, Non-Magnifying |
| Twilight Performance |
Not Specified by Manufacturer |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
.25 MOA Elevation & Windage |
| Maximum Adjustment |
45 MOA E & 35 MOA W |
| Exit Pupil |
4.7mm at 12x / 1.3mm at 42x |
| Eye Relief |
3.8" / 98.0mm @ 12x, 3.8" / 98.0mm @ 42x |
| Parallax Correction Control |
50 yards to Infinity |
| Diopter Adjustment |
+ / - 5 |
| Battery |
CR-2032 |
| Battery Life |
About 200 Hours Depending on Intensity |
| Material |
6061-T6 Aircraft Grade Aluminum Alloy |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
16.1", (409.8mm) |
| Mounting Length |
6.9" |
| Weight |
34.0 oz., 963.9g |
| Special Features |
Reticle Image in the Second Focal Plane. |
