Onkyo

Onkyo PR-SC5509 9.2-Channel Network A/V Preamplifier, 87.5-108 MHz FM Frequency Range, 40 stations FM/AM Preset Memory

SKU: ONKPRSC5509 MFR: PR-SC5509
Usually ships in 7-10 Business Days.
Your card will only be charged once item ships.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

Our Price

$2,499.00 $98 per week
Free Expedited Shipping
Qty:
Add to Wishlist

Protect your investment

About the Onkyo PR-SC5509

The Onkyo PR-SC5509 9.2-Channel Network A/V Controller is the ultimate conduit for all your music, games and movies. Whether from a Blu-ray or SACD player, from your PC or the web, from a game console or an iPhone, your entertainment is brought stunningly to life. Eight HDMI inputs for high-definition formats such as 3D video and lossless audio and an Ethernet jack for home-network audio make system integration a breeze. HDMI terminals, 9.2-channel XLR outs and stereo XLR inputs are gold-plated for pristine signal transfer. Further evidence of audiophile build quality comes in the form of a customized toroidal transformer, separate audio/video transformers and an anti-vibration chassis.

Processing is also top-notch. For video, an HQV Vida processor and Qdeo technology work to liminate noise and upscale video to eye-popping 4K resolution. On the audio side, Audyssey MultEQ XT32 and DTS Neo: X offer incredible flexibility for creating an immersive room-matching soundstage. Partnered with a high-end 9-channel power amp and surround speakers, the PR-SC5509 keeps the high-quality entertainment flowing.

Onkyo PR-SC5509 Includes

  • Onkyo PR-SC5509 9.2-Channel Network A/V Controller
  • Indoor FM Antenna
  • AM Loop Antenna
  • Speaker Cable Labels
  • Speaker Set-up Microphone
  • Instruction Manual
  • Quick Set-up Guide
  • Remote Controller
  • 2 x AA (R6) Batteries
  • Onkyo Warranty

Onkyo PR-SC5509 Features

  • THX Ultra2 Plus Certified
  • HDMI Support for 3D, Audio Return Channel, DeepColor, x.v.Color, LipSync, Dolby TrueHD, DTS-HD Master Audio, DVD-Audio, Super Audio CD, Multichannel PCM and CEC
  • Massive Toroidal Transformer and Two Separate Transformers for Audio and Video Processing
  • Separate Anti-Vibration Aluminum Panels
  • VLSC (Vector Linear Shaping Circuitry) for All Channels
  • High-Quality HQV Vida VHD1900 Video Processor
  • ISF (Imaging Science Foundation) Video Calibration for Optimal Video Performance
  • HDMI Video Upscaling to 4K with Qdeo Technology by Marvell
  • DTS Neo:X, Audyssey DSX and Dolby Pro Logic IIz for Expanded Surround Channels
  • Audyssey MultEQ XT32 to Correct for Room Acoustics
  • Direct Digital Connection of iPod/iPhone via Front-Panel USB Port
  • Supports Onkyo Remote Apps for Control of A/V Receiver via iPod touch/iPhone1 and Android Phone2
  • Playback of Audio Files Through Local Network (MP3, WMA, WMA Lossless, FLAC, WAV, Ogg Vorbis, AAC, LPCM)
  • Internet Radio and Music Streaming Connectivity (vTuner, Last.fm3, Napster3, Spotify3, AUPEO!)
  • Bi-Amping Capability
  • DSD Direct for Super Audio CD
  • Zone 2/3 Pre-Outs and Subwoofer Pre-Outs and Zone 2 Video Out for Distributed A/V Playback in Multiple Rooms
  • Gold-Plated HDMI Terminals (2 Inputs and 1 Output Only)
  • Gold-Plated, Machined Solid Brass A/V Terminals (19 mm-Pitch Inputs for TV/CD and Phono)
  • Gold-Plated, 9.2-Channel Balanced XLR Pre Outs (with Front Bi- Amping Capability)
  • Gold-Plated, 2-Channel Balanced XLR Inputs
  • Dolby TrueHD and DTS-HD Master Audio Decoding
  • TI Burr-Brown 192 kHz/32-Bit DACs (PCM1795 x 6) for All Channels
  • Advanced 32-Bit Processing DSP Chip
  • Linear Optimum Gain Volume Circuitry

Onkyo PR-SC5509 Specifications

Total Harmonic Distortion+Noise 0.05% (20 Hz-20 kHz, Half power
Input Sensitivity and Impedance 200 mV/47 kohm (Line)
2.5 mV/47 kohm (Phono MM)
Rated RCA Output Level and Impedance 1.0 V/470 ohm (Pre out)
Maximum RCA Output Level and Impedance 5.5 V/470 ohm (Pre out)
Rated XLR Output Level and Impedance 2.0 V/470 ohm (Pre out)
Maximum XLR Output Level and Impedance 11.0 V/470 ohm (Pre out)
Phono Overload 70 mV (MM, 1 kHz, 0.5%)
Frequency Response 5 Hz-100 kHz/+1 dB, -3 dB (Direct mode)
Tone Control ±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 110 dB (Line, IHF-A)
80 dB (Phono MM, IHF-A)
Input Sensitivity/Output Level/Impedance 1.0 Vp-p/75 ohm (Component and S-Video Y)
0.7 Vp-p/75 ohm (Component PB/CB, PR/CR)
0.28 Vp-p/75 ohm (S-Video C)
1.0 Vp-p/75 ohm (Composite)
Component Video Frequency Response 5 Hz-100 MHz/0 dB, -3 dB
Tuning Frequency Range FM: 87.5 MHz-108 MHz
AM: 522 kHz-1,611 kHz
FM/AM Preset Memory 40 stations
Power Supply AC 220-240 V-, 50/60 Hz
Power Consumption 110W
Dimensions (W x H x D) 435 x 198.5 x 453.5 mm / 17.12 x 7.81 x 17.85"
Weight 14.0 kg / 30.86 lbs
