| Image Device |
1/4.1 Type MOS (3.32 MP) |
| Effective Pixels |
Motion Image: 4:3: 1.02 Mp (tele) to 1.44 Mp (wide) 16:9: 1.36 Mp (tele) to 1.92 Mp (wide) Still Image3:2: 1.46 Mp (tele) to 2.08 Mp (wide) 16:9: 1.36 Mp (tele) to 1.92 Mp (wide) 4:3: 1.52 Mp (tele) to 2.16 Mp (wide) |
| Illumination |
Standard: 1400 lux Minimum: Approx. 4 lux (1/30 Low Light scene mode); approx. 1 lux (Color Night View) |
| White Balance |
Auto / Indoor1 / Indoor2 / Sunny / Cloudy / White settings |
| Shutter Speed |
Motion Image: (At 60i) 1/60 to 1/8000 sec Still Image 1/2 to 1/2000 sec |
| Image Stabilizer |
Hybrid Optical Image Stabilizer (O.I.S.) / O.I.S. Lock |
| Focus |
Auto/manual |
| Iris |
Auto/manual |
| Backlight Compensation |
Yes |
| Lens |
Panasonic Lens, 2.9-48.7mm (16.8x optical zoom, 23x intelligent zoom) |
| Digital Zoom |
50x / 1200x |
| 35mm Equivalent Focal Length |
Motion Image: 35.8-716mm (16:9), 43.9-878 (4:3) Still Image: 35.8-716mm (16:9), 35.8-716mm (4:3), 35.8-716mm (3:2) |
| F Number |
f/1.8 (wide) to f/2.7 (tele) |
| LCD Monitor |
2.7 inch (6.7 cm) widescreen LCD (230,000 pixels) |
| Viewfinder |
Yes (no specifications provided) |
| Still Mode |
JPEG (design rule for Camera File system, based on Exif 2.2 standard) |
| Still Picture Resolution |
Still Picture Only: 3:2: 2.8 Mp (2064 x 1376) 16:9: 2.1 Mp (1920 x 1080) 4:3: 2.9 Mp (1952 x 1464); 0.3 Mp (640 x 480) Simultaneous Recording: 16:9: 2.1 Mp (1920 x 1080) 4:3: 0.3 Mp (640 x 480) Creating Still Picture from Motion Picture: 16:9: 2.1 Mp (1920 x 1080); 0.2 Mp (640 x 360) 4:3: 0.3 Mp (640 x 480) |
| Signal System |
1080i60, 480i60 |
| Compression |
MPEG-4 AVC / H.264 |
| Recording Modes |
1920 x 1080: HA (approx. 17 Mb/s VBR), HG (approx. 13 Mb/s VBR), HX (approx. 9 Mb/s VBR), HE (approx. 5 Mb/s VBR)720 x 480: SA (approx. 9 Mb/s VBR), SX (approx. 4.5 Mb/s VBR) |
| Media |
SD/SDHC/SDXC Memory Card Slot |
| Maximum Recording Time |
HA Mode: Approx. 8 hrs 30 min HG Mode: Approx. 11 hrs HX Mode: Approx. 16 hrs 50 min HE Mode: Approx. 27 hrs 30 min SA Mode: Approx. 16 hrs 30 min SX Mode: Approx. 33 hrs |
| Audio Compression |
Dolby Digital (2-channel) |
| Microphone |
2-channel stereo (with zoom function) 1x 3.5 mm external mic-in jack |
| Speaker |
1 round speaker, dynamic type |
| Outputs |
HDMI USB 2.0 Component connector video output level: Y; 1.0 Vp-p, 75 h/Pb; 0.7 Vp-p, 75 h/Pr; 0.7 Vp-p, 75 h AVconnector video output level: 1.0 Vp-p, 75 h, NTSC system AV connector audio output level (Line): 316 mV, 600 h, 2 ch Headphone: 77mV, 32 h (stereo mini jack) |
| Power Requirements |
9.3V DC (when using AC adapter) 7.2V DC (when using battery) |
| Power Consumption |
5.0W (recording) |
| Dimensions (W x H x D) |
8.5 x 8.9 x 17.1 inch (216 x 224 x 432mm) |
| Weight |
Main body only: Approx. 3.97 lb (1.8 kg) |
