Panasonic PT-DX100 10000 Lumens DLP Projector, Powered Zoom Lens, 10000:1 Contrast Ratio, XGA 1024x768 Resolution, 4:3 Aspect Ratio, 3D Ready, Black

SKU: PCPTDX100UK MFR: PT-DX100UK

Our Price

$7,999.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

Availability: Pre Order Now Pre Order Now - You may place this on order now and it will be shipped on a first come first serve basis. We do not charge your card until we actually ship the item to you.

See all shipping options

Panasonic PT-DX100: Picture 1 regular $7,999.00

About Panasonic PT-DX100

The Panasonic PT-DX100 10000 Lumens DLP Projector (Black) features a dynamic RGB Booster to provide high picture quality and color reproduction and DIGITAL LINK for All-in-One connectivity.

With the incorporation of the new 420W dual lamp and new lamp drive system, the PT-DX100 is able to deliver a high brightness of 10,000 lumens in an incredibly compact body. The Panasonic proprietary Dynamic RGB booster, which has been enhanced, provides images with brilliant color and brightness, optimizing lamp intensity of individual red, green and blue colors according to each scene. Detail Clarity Processor 3 improves the clarity, detail and depth of images and the System Daylight View 2 function also helps maintain picture quality, even in a bright room. The PT-DX100 is 3D-compatible and supports various 3D formats including frame packing, side by side, top and bottom, line by line and simultaneous.

The projector delivers continuous immersive image quality thanks to its shielded optical system which effectively blocks dust and its new heat pipe system which enables an efficient cooling system. The PT-DX100 is also designed with a dual lamp system that eliminates projection interruption due to a lamp failure. The Lamp Relay mode alternates operation of each lamp to enable 24/7 operation of the projector. Furthermore, its lamp replacement cycle has been improved compared to conventional Panasonic 1-chip DLP models and is now up to 3000 hours in normal mode and 4000 hours in eco mode for reduced maintenance.

Panasonic PT-DX100 Features

  • DIGITAL LINK for simplified AV infrastructure: The PT-DX100 Series offers more than just high picture quality, ease of maintenance and system reliability
  • Flexible installation and diverse functions: Application flexibility is further enhanced through the lens being located in a centralized position in the projector chassis, by a wide range of movement in the motorized horizontal / vertical lens shift and through 360-degree installation capability

Panasonic PT-DX100 Specifications

Power supply
120-240 V AC, 10-5.2 A, 50/60 Hz
Power consumption
1,030 W (1,060 VA) (0.3 W when STANDBY MODE set to ECO, 3 W when STANDBY MODE set to NORMAL)
Dissipation BTU
3,516 BTU/hour (without light 3379 BTU/hour)
Panel size
17.8 mm (0.7") diagonal
Aspect ratio
4:3
Display method
DLP chip x 1, DLP projection system
Pixels
786432 (1024x768) pixels
Lens
Powered zoom (throw ratio 1.8-2.5:1), powered focus F 1.7-1.9, f 25.6-35.7 mm
Lamp
420 W UHM lamp x 2
Screen size (diagonal)
1.27-15.24 m (50-600 in), 1.27-5.08 m (50-200 in) with the ET-DLE055, 4:3 aspect ratio
Brightness
10,000 lm (dual-lamp, LAMP MODE: NORMAL)
Center-to-corner uniformity
90%
Contrast
10,000:1 (full on/full off, in dynamic iris 3 mode)
Resolution
1,024 x 768 pixels (Input signals that exceed this resolution will be converted to 1,024 x 768 pixels)
Scanning frequency: HDMI/DVI-D
fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 25-162 MHz
Scanning frequency: RGB
fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 162 MHz or lower
Scanning frequency: YPBPR (YCBCR)-1
fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1035 (1125)/60i]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]
fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
Scanning frequency: YPBPR (YCBCR)-2
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
Scanning frequency: Video/YC
fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60], fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis shift: Vertical
+50 % from center of screen (powered)
Optical axis shift: Horizontal
±10 % from center of screen (powered)
Keystone correction range
Vertical ±40deg.
Installation
Ceiling/floor, front/rear
HDMI IN
HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
DVI-D IN
DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
RGB 1 IN
BNC x 5 (RGB/YPBPR/YCBCR/YC x 1)
RGB 2 IN
D-Sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1)
3D SYNC 1 IN/OUT
BNC x 1 (3D timing signal)
3D SYNC 2 OUT
BNC x 1 (3D timing signal)
VIDEO IN
BNC x 1 (composite video)
SERIAL IN
D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
SERIAL OUT
D-sub 9-pin (male) x 1 for link control
REMOTE 1 IN
M3 x 1 for wired remote control
REMOTE 1 OUT
M3 x 1 for link control (for wired remote control)
REMOTE 2 IN
D-sub 9-pin (female) x 1 for external control (parallel)
LAN / DIGITAL LINK
RJ-45 x 1 (for network and DIGITAL LINK (video/network/serial control) connection, 100Base-TX, compatible with Art-Net, compliant with PJLink, Deep Color, compatible with HDCP)
Cabinet materials
Molded plastic
Operation noise
40 dB (dual lamp operation, lamp mode: NORMAL), 35 dB (dual lamp operation, lamp mode: ECO)
Operating temperature
0-45 deg.C (32-113 deg.F)
Operating humidity
10-80 % (no condensation)
Applicable software
Logo Transfer Software, Multi Projector Monitoring & Control Software
Dimensions
498x200x556mm (19.60x7.87x21.88") with supplied lens
Weight
18.3 kg (40.3 lbs) with supplied lens
Mfr #
PT-DX100UK
SKU
PCPTDX100UK
Q&A

Questions & Answers Powered by TurnTo®

Questions about this item:

Christine G  What is the throw distance for a 100" projected image? How far away would the projector sit from the screen?
Andrew R  The manufacturer specifies a throw ratio of 1.8-2.5:1 and works with the following screen sizes: 1.27-15.24 m (50-600 in), 1.27-5.08 m (50-200 in) with the ET-DLE055, 4:3 aspect ratio.
Christine G  Sorry - I don't know how to get my answer from that information. For a 100" projection, how far away would the projector sit? Thanks
Andrew R  The manufacturer has not released the manual for this unit yet, but you'd probably be at more than 10 feet (I'm not sure of the actual distance). Actual projection distance will be specified in the manual. Distance would also vary depending on the aspect ratio (4:3 or 16:9).
