| Camera type |
Single-lens reflex autofocus camera with multiple automatic exposure control, variable metering pattern, TTL autoflash (SCA-3000) and motorized film advance |
| Autofocus |
Cross-type autofocus sensor |
| Analogue negative sizes |
4.5 x 6 cm and 6 x 6 cm (the latter in preparation) |
| Film sizes |
Size 120 and 220 roll film for 16 or 32 exposures in 4.5 x 6 cm format |
| Film speed |
ISO 25/15° to 6400/39° can be set in 1/3rd EV increments on interchangeable magazine |
| Shutter |
Electronically controlled between-the-lens shutter with speeds from 1/1000s (with PQS lenses) to 32s plus B |
| Exposure-metering modes |
Multi-zone metering
Centre-weighted multi-zone metering
Spot metering via central photodiode (approx. 1 % of 6 x 6 cm format)
Multi-spot metering with storage of up to five readings
Automatic compensation of extraneous light during metering
Integral RGB sensor for automatic white balance in digital photography |
| Exposure modes |
Shutter-speed priority AE
Aperture-priority AE
Programmed AE biased for high speeds
Metered manually in 1/3rd EV increments |
| Operating ranges |
Exposure metering: EV 0 to EV 19 at ISO 100/21° with 80mm f/2.8 lens
Autofocusing: EV 1 to EV 19 at ISO 100/21° with 80mm f/2.8 lens
TTL flash ISO 25 - 1600 |
| AE lock |
Operational in all automatic modes
Locks exposure value (EV) of shutter speed and aperture |
| Exposure compensation |
Manual in 1/3rd EV increments from -4 2/3 to +2 EV
Via autobracketing (in s± setting) in 1/3, 2/3 and 1EV increments |
| Autoflash |
OTF TTL flash metering
Flash-ready display and exposure control in viewfinder
Optional automatic flash firing with Metz flash units in low light
Additive fill-in flash
TTL studio pre-flash metering with studio flash units |
| Flash synchronization |
At any shutter speed from 1/1000 s to 32 s
Hot shoe with contacts for Metz flash units
SCA interface via Rollei SCA-3562 Adapter |
| Fast shutter release |
Shutter lag with PQ lenses approx. 3 - 4 ms, with PQS lenses approx. 2 ms |
| Depth-of-field preview |
In any operating mode by depression of a button |
| Mirror lockup |
In any operating mode with AE lock and display
With mirror up, shutter speed, ISO speed and exposure compensation can still be varied |
| Lens mount |
Rollei bayonet mount, 10-pole contact strip for signal transfer for aperture and shutter drives
Fully functional exposure control, even with bellows unit, extension tubes and reversing ring |
| Multiple exposures |
By electronic suppression of film advance, without image viewing, e.g. for digital prints |
| Reflex mirror |
Pre-lockable instant return mirror with motorized direct drive, with partially transmitting multicoating
Control options even with mirror up |
| Viewfinder system |
Standard folding finderhood with collapsible magnifier, interchangeable for telescopic 90° high-eyepoint viewfinder, interchangeable focusing screen
Hi-D focusing screen is standard equipment |
| Film advance |
Automatic film advance by high-performance motor in film magazine, single frames and continuous shooting with up to1.5 fps
Automatic film winding to the first frame, automatic film winding after exposure of last frame |
| Power supply |
Rechargeable high-performance lithium-ion battery, 7.4 V, 2200 mAh |
| Handgrip |
With four click stops (for use with folding finder hood or 90° viewfinder)
Detachable leather wrist strap |
| Interchangeable film magazines |
Type 4560 film magazine for 4.5 x 6 cm with integral laminar drawslide, frame counter, film-speed setting, film-type display and preloadable film insert
Type 6060 film magazine for 6 x 6 cm (in preparation) |
| Custom functions and basic menu settings |
Leading or trailing sync
Pre-flash metering
Self-timer
Quiet mirror ON/OFF
Centre-weighting of exposure reading
ON/OFF
Autobracketing in increments of ±1/3, ±2/3, ±1 EV
Frame-counter display |
| Interfaces |
Digital-back interface
Screw-type 8-pole universal connector for electrical cable release and other electronic accessories
USB port |
| Working temperature |
From -20° C to +60° C |
| Tripod quick-release adapter |
With 1/4" and 3/8" tripod sockets |
| Compatible digital backs |
Sinarback eMotion 22 / 54 / 75
Sinarback eVolution 75 H
Sinarback 54 MC / M
Some Leaf backs |
| Compatible lenses |
Schneider Digital AFD 50, 80, 150, 180, Zoom 60 - 140 as well as AFD-Flektogon 35
All lenses compatible with Rolleiflex 6000 cameras |
| Camera body Dimensions |
157 x 112 x 78mm |
| Film magazine Dimensions |
88 x 86 x 50mm |
| 80mm f/2.8 Lens Dimensions |
67 x 90mm |
| Camera body incl. battery weight |
990g |
| Type 4560 film magazine weight |
330g |
| 80mm f/2.8 Lens weight |
500g |
| Warranty |
Rollei warranty |
