||Condenser (electret bias)
||Trombone, Trumpet, Tom Toms (Drums) , Saxophone, Soprano Saxophone
||20 to 20,000 Hz.
||Rated at 150.0 ohms (actual) Recommended minimum load impedance: 1 k ohms May be used with loads as low as 150 ohms with reduced clipping level)
||(0 dB = 1 volt per Pascal) Open Circuit Voltage: -56 dB (1.6 mV)
Output Clipping Level at 1kHz, THD < 1%): 2.5 k ohms load 11 dBV (3.5 V) 1.0 k ohms load 3 dBV (1.4 V)
Maximum SPL 2.5 k ohms load 163 dB 1.0 k ohms load 155 dB
Dynamic Range (maximum SPL to A-weighted noise level): 132 dB (2.5 k ohms load)
Output Noise (equivalent SPL) 31 dB typical, A-weighted
Signal-to-noise ratio 63 dB at 94 dB SPL (IEC 651)
||Mini Q-G Connector from Microphone, XLR-3M Type from Pre-Amp
||Positive pressure on microphone diaphragm produces positive voltage on pin 2 relative to pin 3 of preamplifier output connector.
||Microphone w/cable and preamplifier: 156 g (5.5 oz.)
||Recommended Operating Voltage 11 to 52 Vdc Phantom
