Shure

Shure P9TR425CL-X1 PSM900 Wireless Personal Monitoring System with IEMs (X1: 944-952 MHz)

SKU: SHP9TR425X1 MFR: P9TR425CL-X1
Please note! This is a Special Order Item and is Non Cancelable and Non Returnable.
We Charge you when you place your order. Approximate arrival at Adorama 1 - 2 Weeks from date of order.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$1,800.00 List Price

Our Price

$1,330.00 $53 per week
Free Shipping
Qty:
Add to Wishlist

Protect your investment

About the Shure P9TR425CL-X1

The Shure P9TR425CL-X1 PSM900 Wireless Personal Monitoring System with IEMs (X1: 944-952 MHz) is a professional-quality wireless monitoring system that provides high-quality audio and RF performance in a compact and durable design. The system consists of a P9T transmitter, a P9R bodypack receiver and a set of in-ear monitoring headphones. The system features an enhanced digital stereo encoder that enhances audio detail and clarity and patented Audio Reference Companding that sounds more like wired audio than other competing wireless systems.

Patent-pending CueMode technology lets you monitor different stage mixes, as well as store up to 20 different channels on a single bodypack receiver. A Scan and Sync function creates an IR link between the components for fast and easy syncing. RF muting provides easy setup without creating RF interference. RF scan and automatic gain features provide excellent RF stability and channel availability and prevent dropout due to RF overload. MixMode technology lets the receiver balance the levels of 2 audio channels while receiving each signal in both ears simultaneously.

The transmitter has a compact half-rack design with XLR/TRS combo inputs, loop outputs and a 3.5 mm headphone jack for monitoring. It also has a backlit LCD display and LED level meters. The receiver has a slim aluminum housing with volume and balance controls and a 3.5 mm headphone jack. It has an LCD screen for navigating settings and menus and it operates on a pair of standard AA batteries.

The included headphones provide crisp, detailed audio for excellent monitoring. Dual HD MicroDrivers provide a full frequency response, while the in-ear design and included fit kit ensure a proper fit for comfort and noise isolation. They also have a detachable cable with a 3.5 mm plug and a 1/4" adapter, allowing you to use them with the P9R receiver, as well as other devices.

Shure P9TR425CL-X1 Includes

  • Shure P9T Wireless Transmitter for PSM900 (X1: 944-952MHz)
  • P9R Wireless Bodypack Receiver for PSM900 (X1: 944-952MHz)
  • SE425 Sound Isolating In-Ear Stereo Headphones (Clear)
  • Shure Warranty

Shure P9TR425CL-X1 Features

  • Enhanced digital stereo encoder enhances audio detail and clarity, while patented Audio Reference Companding sounds more like wired audio than other competing wireless systems
  • Patent-pending CueMode technology lets you monitor different stage mixes, as well as store up to 20 different channels on a single bodypack receiver
  • Scan and Sync function creates an IR link between the components for fast and easy syncing
  • RF muting provides easy setup without creating RF interference
  • RF scan and automatic gain features provide excellent RF stability and channel availability and prevent dropout due to RF overload
  • MixMode technology lets the receiver balance the levels of 2 audio channels while receiving each signal in both ears simultaneously
  • Compact half-rack design for easy transportation and installation in any standard equipment rack
  • Front-panel input gain control and LED level meters
  • 3.5 mm headphone jack for convenient monitoring
  • Backlit LCD displays vital info
  • XLR/TRS combo inputs accept a variety of audio sources
  • Loop out connectors make it easy to create multiple mix setups
  • Compatible with the PA421SWB and PA821SWB antenna combiners and offers front or back mountable antennas
  • Slim and compact extruded aluminum construction for easy placement on a performer and lasting durability
  • Output power is switchable from 10/50/100 mW to provide a robust link in any environment
  • Volume and balance controls are provided for easy customization
  • Selectable high frequency EQ boost
  • Audio and RF status LEDs, as well as audio level and battery life metering
  • Operates on a pair of standard AA batteries for 5-7 hours of continuous use
  • Standard 3.5 mm headphone jack is compatible with all Shure SCL sound isolating earphones and other headphones
  • LCD screen displays settings and menus
  • Detachable antenna
  • Dual high-definition MicroDrivers in each earpiece put a separate woofer and tweeter into each ear for rich, detailed audio across the full frequency spectrum
  • Ergonomic, professional design has a low-profile shape with an optimized nozzle angle for exceptional comfort
  • The 3.5 mm stereo mini plug and 1/4" adapter provide wide compatibility with consumer and professional audio devices

Shure P9TR425CL-X1 Specifications

Modulation FM, MPX Stereo
Pilot Tone 19kHz (±0.3kHz)
Frequency Stability ±2.5ppm
Operating Range 300' (91.4 m)
Frequencies X1: 944-952MHz (20 Per Band)
Tuning 36-40MHz, US
Frequency Response 35Hz - 15kHz
Separation 60dB
Signal to Noise Ratio 90dB
Total Harmonic Distortion (THD) < 0.8%
Compander Patented Shure Audio Reference Companding
Spurious Rejection > 80dB
Operating Temperature -0.4 to 134.6deg.F (-18 to +57deg.C)
Transmitter: Output Power 10/50/100mW, Selectable (Regionally Dependent)
Transmitter: Output Impedance 50 Ohms (RF, Typical)
Transmitter: Input Level +4dBu (+29.3dBu Max) and -10dBV (+12.2dBu), Switchable
Transmitter: Connectors 2 x XLR/TRS Combo Inputs
2 x 1/4" Loop Outputs
1 x DC Power Input
1 x Antenna Connector
1 x 3.5mm Headphone Jack
Transmitter: Phantom Power Protection Up to 60VDC
Transmitter: Power Requirements 15VDC, 415mA, Typical (RF On, 100mW Power Mode, No Audio)
Receiver: RF Sensitivity 2.2uV
Receiver: Filter -3dB @ 30.5MHz, Front-End RF Filtering
Receiver: Gain Control 31dB
Receiver: Image Rejection > 100dB
Receiver: Adjacent Channel Crosstalk > 70dB
Receiver: Squelch 22dB SINAD
Receiver: Intermodulation Distortion > 70dB
Receiver: Blocking > 80dB
Receiver: Load Impedance 9.5 Ohms
Receiver: Output Power 10/50/100mW, Selectable
Receiver: Gain Boost +2dB, +4dB @ 10kHz, Selectable
Receiver: Limiter 3-9, Selectable
Receiver: Connectors 1 x 3.5mm Headphone Jack
1 x Antenna Connector
Receiver: Battery Type/Life 2 x AA, Approx 5-7 Hours
Headphone Type In-Ear Noise-Isolating Stereo Headphones
Headphones: Frequency Response 20Hz - 19kHz
Headphones: Impedance 22 Ohms @ 1kHz
Headphones: Sensitivity 109dB SPL/mW
Headphones: Connectors Gold-Plated 3.5mm Stereo Mini Plug with 1/4" Adapter
Headphones: Cable Length 5.3' (1.63 m) (Detachable)
Dimensions Transmitter: 7.75" x 6.5" x 1.6" / 196.85 x 165.1 x 40.64 mm
Receiver: 3.3" x 2.6" x 0.9" / 83.82 x 66.04 x 22.86 mm
Weight Transmitter: 1.9 lbs / 0.86 kg
Receiver (With Batteries): 7.05 oz / 199.86 g
