Shure PGXD14-X8 Digital Wireless Guitar/Bass System, X8 (902-928 MHz) Band

Shure
SKU: SHPGXD14X8 MFR: PGXD14-X8

List Price: $536.00

Protect Your Investment:

Add a Protection Plan
  • Add a protection plan
  • New Leaf 3 Year Extended Warranty + $24.95
  • New Leaf 3 Year Drops & Spills Extra Protection + $39.95
  • New Leaf 5 Year Drops & Spills Extra Protection + $84.95
20% Off

Our Price

$429.00
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

Shure PGXD14-X8: Picture 1 regular $429.00

About Shure PGXD14-X8

The Shure PGXD14-X8 Digital Wireless Guitar/Bass System with state-of-the-art, 24-bit digital audio and trusted Shure microphones, delivers stunning sound and a strong, clean RF signal. The slim, compact bodypack with belt clip features power, mute and battery status LEDs; recessed dial with 26 dB of adjustable gain and lockable interface that prevents accidental setting change.

Shure PGXD14-X8 Specifications

RF Carrier Range
X8: 902-928 MHz
Audio Frequency Response
20-20000 Hz
Dynamic Range
>108 dB, A-weighted
Operating Temperature Range
-18deg.C (0deg.F)- +50deg.C (122deg.F)
Transmitter: Audio Input Level
+10 dBV maximum, at minimum gain setting
-16 dBV maximum, at maximum gain setting
Transmitter: Gain Adjustment Range
26 dB
Transmitter: Input Impedance
1M ohms
Transmitter: RF Output Power
10 mW varies by region
Transmitter: Pin Assignments
TA4M:
1: ground (cable shield)
2: + 5 V Bias
3: audio
4: Tied through active load to ground (On instrument adaptor cable, pin 4 floats)
Transmitter: Housing
Molded polycarbonate case
Transmitter: Power Requirements
2 "AA" size alkaline or rechargeable batteries
Transmitter: Battery Life
Up to 10 hours
Receiver: Audio Output Level
XLR connector: -2.5 dBV (into 3 kOhm load)
6.35 mm (1/4") connector: +10 dBV (into 10 kOhm load)
Receiver: Housing
ABS
Receiver: Sensitivity
-102 dBm @ 10-5 BER
Receiver: Power Requirements
12-18 V DC @ 150 mA, supplied by external power supply (tip positive)
Receiver: Audio LED
Red: 2 dB below clip
Amber: 12 dB below clip
Green: 50 dB below clip
Receiver: Impedance
XLR: 50 ohms
6.35 mm (1/4"): 50 ohms
Receiver: Pin Assignments
XLR: 1=ground, 2=hot, 3=cold
6.35 mm (1/4") TRS: Tip=audio, Ring=no audio, Sleeve=ground
Dimensions (H x W x D)
Transmitter: 108 mm x 64 mm x 19 mm (4.25" x 2.51" x 0.74")
Receiver: 40 mm X 181 mm X 104 mm (1.57" x 7.12" x 4")
Weight
Transmitter: 128 g (4.5 oz)
Receiver: 289 g (10.2 oz)
Mfr #
PGXD14-X8
SKU
SHPGXD14X8
