| Magnification |
3.5x - 18x |
| Objective / Field of View |
44mm / 30.0' (10.0m) @ 3.5x at 100 yds.(100m), 6.0' (2.0m) @ 18x at 100 yds.(100m). |
| Main (Center) Tube Diameter |
1" |
| Objective Tube Diameter |
48mm |
| Lens Coatings |
High Light Transmission Optical System |
| Reticle |
4 Reticle |
| Reticle Image Plane (Magnifying) |
Reticle in Second (ocular-side) Focal Plane, Only the Target is Enlarged |
| Twilight Performance |
7.1 - 25.7 (DIN 58388), Transmission 90% |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/3-M.O.A. Per Click |
| Maximum Adjustment |
64.8" Elevation / 36" Windage |
| Exit Pupil |
9.5mm - 2.9mm |
| Eye Relief |
3.74" |
| Parallax Correction Control |
With 3rd Turret: 50 yards - Infinity |
| Diopter Adjustment |
- 3.0 / + 2.0 |
| Material |
Aluminum |
| Nitrogen Filled |
Yes |
| Waterproof / Fogproof |
Yes |
| Length |
14.02", (356.0mm) |
| Mounting Length |
5.4", (137.0mm) |
| Weight |
19.6 oz., 555g. |
| Special Features |
Objective Filter Thread: 46mm. |
