Sonnet Presto 1-Port 10 Gigabit Ethernet PCIe Express Card with SFP+ (Thunderbolt Compatible), 9.9Gbps with 9KB MTU/9.5Gbps with 1500B MTU

SKU: SNTG10ESFPE

This item is no longer available.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Sonnet G10E-SFP-E Specifications

  • Transceiver Interface Type

    SFP+

  • Bus Interface

    PCI Express v1.1, x8

  • Network

    10 Gigabit Ethernet

  • Packets

    Maximum packet size: 9000 bytes (jumbo packets)

  • Throughput

    -9.9 Gb/s with 9KB MTU, - 9.5 Gb/s with 1500B MTU

  • Stateless Offloads

    IP and TCP checksum offload, send and receive
    TSO (TCP Segmentation Offload, AKA Large Send Offload)
    LRO (Large Receive Offload)
    RSS (Receive-Side Scaling)
    Interrupt Coalescing
    Multicast filtering

  • RoHS Compliant

    Yes

  • Mac Compatibility

    Mac Pro
    OS X Server 10.6.8+
    OS X Server and OS X Mountain Lion compatible

  • Windows Compatibility

    Windows 8
    Windows 7
    Windows Vista
    Windows Server 2008 R2
    Windows Server 2008

  • Thunderbolt Compatibility

    Any computer with a Thunderbolt port
    Thunderbolt-to-PCIe expansion chassis

  • UPC Code

    732311009402

About Sonnet G10E-SFP-E

The Sonnet Presto 1-Port 10 Gigabit Ethernet PCI Express adapter card enables you to connect your computer to high-speed infrastructure and storage without stepping down in speed. Setup is simple-install the low-profile card into an available x8 or x16 PCIe slot in your computer, install a driver, connect to the switch or 10GbE port via LC fiber optic or copper cable (sold separately) and then configure the card through the OS X Network control panel or Windows Device Manager. This Sonnet solution is perfect for high-performance computing, where low latency, high bandwidth and low CPU overhead are required. Its increased throughput performance and low host-CPU utilization is achieved with stateless offloads, allowing your computer to perform better while large files transfers or high I/O operations take place.

Ultra-Fast 10 Gb/s Network Connection
With increasing demands for greater data transfer speeds and more bandwidth over shared networks and with specialized applications such as HD video editing using high-performance shared storage systems, 10 Gigabit Ethernet (10GbE) use has skyrocketed. This high-speed wired networking standard offers ten times the performance of Gigabit Ethernet, the common wired network connection included with most computers today. Sonnet offers a powerfully simple way to add 10GbE connectivity to your Mac Pro or Windows PC-the Presto 10GbE 1-Port.

Flexibility of Short-Range or Long-Range SFP+ Transceivers
Sonnet offers two SFP+ transceiver options (sold separately), a short-range module (up to 300 meters, part number G10E-SFP-SR) and a long-range module (up to 10 kilometers, part number G10E-SFP-LR) that connect the Presto card via LC fibre optical cable (sold separately) to a network switch or storage.

Optimized for Thunderbolt
Presto 10GbE 1-Port is ideal for use in one of Sonnet's Echo Express Thunderbolt expansion chassis or the xMac mini Server-the combo enables you to add an ultra-fast 10GbE network connection to iMac, Mac mini, MacBook Air and MacBook Pro computers.

Sonnet G10E-SFP-E Features

  • Provides 10GbE Connectivity to Mac Pro and Windows PCs-Powerfully simple way to add high-performance 10GbE connectivity to your computer with PCIe slots
  • Connection Flexibility-Choose either a short-range or a long-range SFP+ transceiver (sold separately), or a SFP+ terminated "Direct Attach" twinax copper cable (sold separately) to connect the Presto card to your network or storage
  • Simple Setup-Low-profile x8 PCI Express card installs into an available slot, provides a simple driver installation and configures through OS X Network control panel or Windows Device Manager
  • Optimized for Thunderbolt-Ideal for use in Sonnet's Echo Express chassis and xMac Mac mini Server Thunderbolt expansion products

Key Features

  • Connection Flexibility-Choose either a short-range or a long-range SFP+ transceiver
  • Simple Setup-Low-profile x8 PCI Express card installs into an available slot

What's in the box:

  • Sonnet Presto 1-Port 10 Gigabit Ethernet PCI Express Card
  • Low Profile PCI Bracket
  • User's Guide
  • Sonnet 1 Year Warranty
