| Output |
Center (Reference): 167W
Front (Rated FTC 1%): 60W+60W
Front (Reference): 167W
Subwoofer (Reference): 165W
Surround (Reference): 167W
Total (Reference): 1000W |
| Video Output |
Video Output - DVD - Video: Yes
Video Output - DVD Upscaling: Yes
Video Output - DVD R/RW BD R/RE: Yes
Video Output - BD-ROM: Yes |
| DVD/CD Specifications |
DVD 24p output: Yes
NTSC/PAL (60Hz/50Hz): 60Hz
TV Type Default Setting: 16:9 |
| D/A Conversion |
Video Digital-to-Analog Converter |
| BD Live Profile |
HD (24Hz) (24p True Cinema): Yes
HD (60Hz): Yes
HD 24Hz to 60Hz conversion: Yes
SD (60Hz): Yes |
| Inputs/Outputs |
Component Video Output(s): 1
Composite Video Output(s): 1
HDMI Output(s): 1
Analog Audio Input(s): PIN Jack: 1
Auto Calibration Mic Input(s): 1
Coaxial Audio Input(s): 1
Ethernet Connection(s): 1
HDMI Input(s): 2
Infrared Input(s): 1
Optical Audio Input(s): 1
USB Input(s): 2 |
| OSD Language |
English (US) or English (GB): Yes-US
French or French (CA): Yes-Canada
Portuguese or Portuguese (LA): Yes-Latin America
Spanish or Spanish (LA): Yes-Latin America |
| Amplifier |
Wireless Amplifier: (5.8GHz)
Power Consumption (in Operation): 50W
Power Consumption (in Standby): 0.5W
Wireless Amplifier Compatibility: Yes
S-Master Digital Amplifier: 24-bit
Function: AUDIO / BD/DVD / FM / HDMI1 / HDMI2 / SAT/CABLE / TV |
| Video Format |
AVCHD Disc Format Folder: Yes
MPEG-1 Video/PS (.mpg .mpeg, .m2ts, .mts): Yes
MPEG-2 Video/PS, TS (.mpg, mpeg, .m2ts, .mts): Yes
MPEG-4 AVC (.mkv, .mp4, .m4v, .m2ts, .mts): Yes
WMV9 (.wmv, .asf): Yes
Xvid HD 1080: Yes
Mixed Disc:
BDAV/BDMV: BDMV
Photo Format:
GIF (.gif): Yes (BD, DVD, CD, USB, DLNA)
JPEG (.jpg, .jpeg): Yes (BD, DVD, CD, USB, DLNA)
PNG (.png): Yes (BD, DVD, CD, USB, DLNA) |
| Audio Format |
AAC(.m4a): Yes
DTS: Yes (BD, DVD, CD, USB, DLNA)
LPCM (.wav): Yes (BD, DVD, CD, USB, DLNA)
MP3 (.mp3): Yes (BD, DVD, CD, USB, DLNA)
MP3 ID3 Tag V1.1 Support: Yes
MP3 ID3 Tag V2.0 Support with Text Info Only: Yes
MP3 ID3 Tag unicode support: Yes
MPEG-2 Audio: Yes
WMA Tags: Yes
WMA9 Standard(.wma): Yes (BD, DVD, CD, USB, DLNA)
BDMV:
BD-R: Yes (SL/DL)
BD-RE: Yes (SL/DL)
BDAV:
BD-R: Yes (SL/DL)
BD-RE: Yes (SL/DL)
Hybrid Disc:
BD/CD: Yes BD/DVD: Yes |
| Power Requirements |
120V AC, 60Hz |
| Power Consumption |
In Operation: 170W
In Standby: 0.3W |
| Region |
Region Code (BD): A
Region Code (DVD): 1 |
| Decoding |
DSD: Yes (via HDMI Input)
DTS: Yes (via HDMI Input)
DTS-ES Discrete6.1: Yes (via HDMI Input)
DTS-ES Matrix6.1: Yes (via HDMI Input)
DTS-HD HR: Yes (via HDMI Input)
DTS-HD LBR: Yes (via HDMI Input)
DTS-HD MA: Yes (via HDMI Input)
DTS96/24: Yes (via HDMI Input)
Dolby Digital: Yes
Dolby Digital Plus: Yes (via HDMI Input)
Dolby Prologic: Yes (via HDMI Input)
Dolby True HD: Yes (via HDMI Input)
LPCM (2ch/5.1ch/7.1ch): Yes (via HDMI Input)- Supports 2ch/5.1ch/7.1ch |
| Tuner |
Auto Scan Tuning: Yes
Band (FM/AM): FM
External Antenna (FM/AM): FM (75ohm)
Preset Station (FM/AM): 20 (FM) |
| Center Speaker |
Enclosure Type (Bass Reflex/Acoustic suspension/Passive radiator/others): Acoustic suspension
Front Grille (Removable/Fixed)/ Material: Fixed / Cloth net
Full Range Unit: 1.2 x 2.4" (30x60mm)
Input Terminal: Push Type
Magnetically Shielded: Yes
Rated impedance: 3 ohm
Speaker System: 1 way
Speaker Unit: 1 unit Supplied Cable Length: 6' (2 m)
Type (Tall boy, Micro satellite): center |
| Surround Speaker |
Enclosure Type (Bass Reflex/Acoustic suspension/Passive radiator/others): Bass Reflex
Front Grille (Removable/Fixed)/ Material: Fixed / Cloth net
Full Range Unit: 2.2 x 3.1" (55x80mm)
Input Terminal (Screw/Push Type/Golden Plated/Pig Tail): Push Type
Rated impedance: 3 ohm
Speaker System: 1 way
Speaker Unit: 1 unit
Supplied Cable Length: 15' (5 m)
Type (Tall boy, Micro satellite): Micro satellite |
| Subwoofer |
Active/Passive: Passive
Cabinet Material: PTB
Enclosure Type (Bass Reflex/Acoustic suspension/Passive radiator/others): Bass Reflex
Front Grille (Removable/Fixed)/ Material: No
Input Terminal: Push Type
Rated impedance: 3ohm
Refraction Board: Yes
Speaker System: Subwoofer
Speaker Unit: 1 unit
Supplied Cable Length: 9' (3 m)
Woofer unit: 7.1" (180mm) |
| Front Speaker |
Enclosure Type (Bass Reflex/Acoustic suspension/Passive radiator/others): Bass Reflex
Front Grille (Removable/Fixed)/ Material: Fixed / Cloth net
Full Range Unit: 2.2 x 3.1" (55x80mm)
Input Terminal: Push Type
Rated impedance: 3 ohm
Speaker System: 2 way
Speaker Unit: 2 units
Supplied Cable Length: 9' (3 m)
Tweeter unit: 0.8" (20mm) (Cone type)
Type (Tall boy, Micro satellite): Desktop |
| Dimensions (W x H x D) |
Center Speaker: 12.4 x 2.3 x 2" (315 x 59 x 53mm)
Surround Speaker: 3.7 x 9.6 x 3.7" (96 x 245 x 96mm)
Subwoofer: 16.3 x 13.3 x 8.4" (415 x 340 x 215mm)
Front Speaker: 4.1 x 12.7 x 4.2" (106 x 325 x 107mm) (6 degree) |
| Weight |
Center Speaker: 0.8 lb. (0.4kg)
Surround Speaker: 1.3 lb. (0.6kg)
Subwoofer: 17.1 lb. (7.8kg)
Front Speaker: 1.7 lbs. (0.8kg) |
