| Speaker System |
Built-In Stereo |
| Timer Events |
Fall Asleep to Music (Select from 6 Timed Shut Offs) |
| Component Compatible |
Yes (MP3, PC, TV, VCR and others) |
| Radio |
AM, FM |
| Tape Cassette |
Player, Casette Recorder |
| Component Video Output(s) |
Headphone (sterro mini jack) |
| Headphone Input(s) |
1 |
| Input(s) |
Line in (stereo mini jack) |
| PC Audio Input(s) |
Yes |
| Disc Capacity |
1 |
| Tray Type |
Top Loading Single CD |
| Type of Use |
Portable Boombox |
| CD |
Player |
| Antenna System |
AM: Built-in Ferrite Bar Antenna;
FM: Telescopic Antenna |
| CD Play Mode(s) |
Program, Shuffle, Repeat, 20 Track RMS Programming |
| Digital Filter |
8X Oversampling |
| Digital-to-Analog Converter |
1 Bit |
| Equalizer |
5 presets (Rock, Dance, Reggaeton, Salsa, Flat) |
| Format(s) Supported |
CD-R/RW MP3 Playback Compatibility |
| Frequency Range |
AM: 530-1710kHz;
FM: 87.5-108.0MHz |
| Frequency Response |
CD: 20-20000Hz (+1/-2dB);
Cassette: 50-13000Hz ±3dB) |
| Sound Enhancer |
Power Drive Woofer |
| Station Preset(s) |
30(10 AM, 20 FM) |
| Tape Operation |
Single Stereo Cassette (fast winding) |
| Tape System |
4 Track, 2 channel Stereo Cassette, Synchronized CD/Cassette Dubbing |
| Tuner Type |
Digital |
| Tuning |
Auto Scan Radio FM20/AM10 |
| Battery Life (Approx) |
Unit: up to 18 hours (w/ SONY Alkaline Batteries) |
| Battery Type |
Unit: 'D' x 8 (optional);
Remote: 'AA' x 2 |
| Output Power |
20W Total (4W + 4W (at 3.2 ohms, 10% harmonic distortion);
12W (at 4 ohms, 10% harmonic distortion) (Woofer)) |
| Power Handling Capacity |
With 3.2-ohm loads, both channels driven from 150-10000Hz; rated 3 W per channel minimum RMS power, with No more than 10% total harmonic distortion in AC operation Woofer with 4 ohm loads, driven at 50-150Hz; rated 7 W minimum RMS power, with No more than 10% total harmonic distortion in AC operation. |
| Power Requirements |
AC 120V, 60Hz |
| Power Consumption (in Operation) |
28W |
| Speaker Unit |
4" (10cm) x 2 |
| Tweeter Size |
0.8" (2cm) |
| Woofer Size(s) |
5" (13cm) |
| Speaker Dimensions |
4" (10cm) x 2 |
| Dimensions (Approx.) |
21-3/4 x 14-9/16 x 9-11/16" (551 x 370 x 246mm) |
| Weight (Approx.) |
18 lbs 9 oz (8Kg) w/ batteries |
