| Format |
HD: MPEG-4 AVC/H.264 AVCHD; SD: MPEG-2 PS |
| Video Recording System |
Real-Time HD Codec Engine, HDV/DV Recording |
| Video Signal |
NTSC color, EIA standards |
| Imaging Device |
3x 1/3" Exmor CMOS sensor |
| Processor |
EIP (Enhanced Imaging Processor) |
| Pixel Gross |
3x 1,120K each (Red, Green, Blue) |
| Video Actual |
3x 1,1040K (16:9) each (Red, Green, Blue) |
| Video Resolution |
Full HD 1920x1080 |
| Recording Media |
Memory Stick PRO Duo Media (sold separately) |
| Recording and Playback Times |
HD: 180 min (32GB FX Mode), 235 min (32GB FH Mode), 435 min (32GB HQ Mode), 750 min (32GB LP Mode); SD: 475min (32GB HQ Mode) |
| Recording Format |
Stereo |
| Audio Format |
HD: Dolby Digital 2ch, 16bit, 48kHz / SD: Dolby Digital 2ch, 16bit, 48kHz |
| Microphone |
Yes (Built-in) |
| Multiple Language Display |
Yes |
| Remote Control |
Yes (RMT-845) |
| Audio/Video Remote Terminal |
Yes |
| Analog Audio/Video Output(s) |
Multi AV (Video/S Video/Audio) |
| Digital Audio/Video Output(s) |
Yes (HDMI) |
| USB Port(s) |
Yes (mini B / Hi-Speed) |
| Component Video (Y/Pb/Pr) Output(s) |
Yes (Mini-D jack) |
| HDMI Connection Output(s) |
Yes (HDMI connector) |
| Headphone Jack |
Yes (Stereo-minijack 3.5 mm) |
| Microphone Input |
XLR X2 (LINE,MIC, MIC +48V) |
| LANC Terminal |
Yes (Stereo Mini) |
| S-Video Output(s) |
Included in A/V Jack |
| Remote Jack |
Yes (Stereo-minijack 2.5 mm) |
| Active Interface Shoe |
Yes (Cold) |
| Battery Type |
InfoLITHIUM Rechargeable Battery (NP-F570) |
| Power Requirements |
7.2V (battery pack); 8.4V (AC Adaptor) |
| Power Consumption (in Operation) |
HD: 6.7W (VF/LCD), SD: 5.9W (VF/LCD) |
| Lens Type |
G Lens |
| 35mm Equivalent |
29.5 - 590mm (16:9) 36.1 - 722mm (4:3) |
| Aperture |
f1.6-3.4 |
| Digital Zoom |
30x approx. (When Digital Extender "ON") |
| Filter Diameter |
72mm |
| Focal Distance |
4.1 - 82mm |
| Focus |
Full Range Auto, Manual (Ring), One Touch |
| Shutter Speed |
1/60 - 1/2000 (60i), 1/30 - 1/2000 (30p), 1/48 - 1/2400 (24p) |
| Minimum Illumination |
1.5 lx (lux) (Fixed Shutter Speed 1/25, auto gain, auto iris) F1.6 |
| Optical Zoom |
20x |
| Exposure |
Exposure control assignable to IRIS ring |
| Manual / Auto Lens Cover |
Manual |
| Memory Stick slot |
Dual Memory Stick PRO Duo Media slots (2 slots A/B) |
| S/S & Zoom button on LCD |
Yes (Zoom Seesaw/ Ring/ Handle seesaw) |
| Memo |
Future model for 2010, U2 added, copy added. |
| Image Stabilization |
Yes (Optical with Active Mode) |
| Low Light Capability |
1.5Lux Minimum Illumination (Fixed shutter speed when 1/30sec, Auto IRIS, Auto GAIN) |
| x.v.Color |
Yes |
| Memory Stick PRO Media Compatibility |
Tested to support up to 32GB media capacity; |
| Dual Record |
No |
| Fader Effect(s) |
Black, White |
| Picture Effect(s) |
CinemaTone Gamma , CinemaTone Color |
| Movie Mode(s) |
HD: AVCHD, SD: MPEG2 |
| Scene Mode(s) |
Picture Profile (up to 7 pre-set conditions) |
| Easy Operation |
Assignable Buttons, End Search |
| White Balance |
Auto (Intelligent, High, Middle, Low) / outdoor / indoor / One-push (A/B) |
| LCD Screen |
3.2" Wide Xtra Fine Touch Panel LCD display (921k pixels) |
| Viewfinder |
0.45" Xtra Fine (16:9) Wide LCD (1,227k pixels) B/W or Color |
| Dimensions (Approx.) |
173 x 187x 342 mm (6-7/8 x 7-3/8 x 13-1/2 inch) including protrusions w/o gripbelt |
| Weight (Approx.) |
4 lb 11 oz (2.1kg) w/ Lens hood with Lens cover |
