| System |
NTSC |
| Region |
Blu-ray Region A DVD Region 1 |
| Refresh Rate |
60Hz |
| Progressive Scan |
24p True Cinema |
| HD Upconversion |
Yes |
| Surround Sound |
CD-DA Dolby Dolby bitstream output over HDMI Dolby True HD bitstream output over HDMI Dolby Pro Logic DTS HD bitstream output over HDMI |
| Built-in Decoder |
Yes |
| HDCD Decoding |
No |
| Bass Management |
No |
| THX Certified |
No |
| Video |
BD-ROM (SL/DL) BD-ROM Bonus View (Profile 1.1) BD-ROM BD-Live (Profile 2.0) BD-R BD-RE DVD-ROM DVD-R/DVD-RW DVD+R/DVD+RW Hybrid Disc (BD/DVD) |
| Audio |
CD-DA (Music CD) CD-R/CD-RW CD-ROM CD-R/CD-RW Super Audio CD Hybrid Disc (BD/CD) |
| Files Supported |
AAC/MPEG4-AAC GIF H.264/MPEG-4 AVC JPEG MP3 (MPEG-1 Audio Layer) PNG |
| Laser |
Semiconductor Laser |
| Digital Media Slot |
No |
| Slow Motion Playback |
Yes |
| Frame-by-Frame Playback |
No |
| Bookmarking |
No |
| Zoom |
Yes |
| Connectors |
HDMI Out x1 HDMI In x1 Audio (Optical Out) x1 USB (Type A for I/O) x4 LAN (RJ45 for I/O) x1 Wireless LAN (802.11a/b/g/n For I/O) x1 IR Blaster x1 |
| Inputs/Outputs I |
HDMI IN: HDMI 19-pin standard connector Video 480p, 720p, 1080i, 1080p Audio Linear PCM (2ch Up to 48kHz) HDMI OUT: HDMI 19-pin standard connector Video 720p, 1080i, 1080p, 1080/24p Audio DTS bitstream, DTS HD Master Audio bitstream, DTS HD High Resolution Audio bitstream, Dolby Digital bitstream, Dolby Digital Plus bitstream, Dolby TrueHD bitstream, Linear PCM (2ch Up to 192kHz), Linear PCM (6ch Up to 192kHz), Linear PCM (8ch Up to 96kHz) |
| Inputs/Outputs II |
Digital Audio Out (Optical) Optical output jack/-18dBm (wave length 660 nm) PCM/DTS/Dolby Digital optical signal LAN 1000BASE-T/100BASE-TX/10BASE-T Terminal USB Jack Type A IR Blaster Mini jack (For connecting the IR Blaster cable) |
| Optical Out |
Optical Digital Audio Output Signals DTS bitstream Yes Dolby Digital bitstream Yes LPCM 2ch Yes |
| Wireless |
IEEE 802.11a/b/g/n |
| Wireless Frequency |
5 GHz band Channels 36-64, 100-140, 149-165 |
| Modulation |
DS-SS Modem and OFDM Modem |
| Tray Type |
Single disc |
| Remote |
Yes |
| Operating Temperature |
5 - 35deg.C (41 - 95deg.F) |
| Humidity |
25 - 80% |
| Power Requirements |
120 V AC, 1.0 A, 60 Hz (the unit DC 19.5 V, 2.0 A) |
| Power Consumption |
43W |
| Dimensions (W x H x D) |
13 x 2.3 x 9.8" (330 x 58.5 x 249mm) |
| Weight |
5.3 lb (2.4kg) |
