| Construction |
Black polycarbonate Port: Corrosion-resistant aluminum alloy (alumite coating) + acrylic Arm set: Corrosion-resistant anodized aluminum |
| Control Type |
Mechanical |
| Controls 1 |
Front: Power switch, Hand strap eyelet, Display button, ISO button, Main dial, Shutter lever, Buckle, Accessory shoe, Fiber-optic cable socket (x2), Focus / Zoom dial, Port mount ring |
| Controls 2 |
Rear: Info button, MENU button, Tripod socket, Viewfinder, Mode dial, Live View shooting / Movie shooting button, AE lock / FE lock / Index / Reduce button, AF point selection / Magnify button, Exposure compensation / Aperture button, Quick control button, White balance selection button, Setting button, AF mode selection button, Picture Style selection button, Erase button, Pressure balance control valve, Play back button, Drive mode selection button |
| Camera Controls |
All essential controls accessible |
| Depth Rating |
200' (60.96m) Port: 330' (100.58m) |
| Port |
Flat RDX Standard Port included Various other ports including NX ports can be mounted via the RDX Port Base L or the RDX Port Base S, to accommodate many kinds of lenses |
| Internal Flash Usable |
Yes |
| External Strobe Connector |
Yes, 2 |
| TTL Compatible |
Yes, with optional YS Converter/C 6 pin Connector |
| Light Source |
Strobe: Bright 1 W LED |
| Beam Angle |
Strobe: 100 x 100deg. |
| Number of Flashes |
Strobe: Up to 330 at full power with NiMH batteries |
| Recycle Time |
Strobe: 1.9 sec with NiMH batteries |
| Magnification |
Viewfinder: 0.5x |
| Dimensions |
Housing: 7.9x7.5x5.5" (20.1x19.05x13.97cm) Port: 5.5x3.5" (13.97x8.89cm) Arm: 8" (20.3cm) long |
| Weight |
4.4lbs (1.99kg) |
