TP-Link TL-WR940N 300Mbps Advanced Wireless N Router with 3 Fixed Antennas

See all TP-Link items
SKU: TPLWR940N MFR: TL-WR940N
TP-Link TL-WR940N: Picture 1 thumbnail TP-Link TL-WR940N: Picture 2 thumbnail TP-Link TL-WR940N: Picture 3 thumbnail TP-Link TL-WR940N: Picture 4 thumbnail
Free Shipping

See all shipping options

In Stock Online - Usually ships in 1-2 Days learn more

Our Price

$24.99
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

Special Offers

Product Highlights

  • 10/100 Transfer Rate
  • Connects Wirelessly
  • 2.4 GHz Frequency
  • WEP / WPA / WPA2
  • N-Technology
  • Single-band
  • 802.11 g/b
  • 300 Mbps

About TP-Link TL-WR940N

The TP-Link TL-WR940N 300 Mbps Wireless N Router is a combined wired / wireless network connection device engineered for small business and home office networking needs. It features MIMO Technology and 3 antennas to enhance wireless robustness and stability. The router boasts data transfer rates of up to 300 Mbps. It produces exceptional, advanced wireless performance, making it great for HD video streaming, VoIP and online gaming. Additionally, the Quick Setup Security (QSS) button on the sleek exterior ensures WPA2 encryptions, safeguarding the network against outside intrusions. It also makes life easy, since you don't have to remember a password. IP QoS based bandwidth control enables network administrators to determine what quantity of bandwidth is allotted to each computer, helping to reduce congestion and prevent bandwidth abuse.

Complying with the IEEE 802.11n standard, TL-WR940N is able to establish a wireless network and achieve up to 15x the speed and 5x the range of traditional 11g products. It also demonstrates a better ability to mitigate data loss over long distances and through obstacles in a small office or a large apartment, even in a steel-and-concrete building. Easily pick up your wireless network with a long-distance connection of which legacy 11g products may not be capable.

This router possesses the speed to work smoothly with virtually any bandwidth-intensive application, including VoIP, HD streaming or online gaming, without lag time. Utilizing its powerful N technologies, the router can also transform your home and even your yard into a large hot-spot. Clear Channel Assessment (CCA) automatically avoids channel conflicts via the clear channel selection feature and completely realizes the benefits of channel binding for substantially improved wireless performance.

Feel more secure knowing that TL-WR940N offers WPA / WPA2 encryptions (both Personal and Enterprise) produced by the WI-FI Alliance industry group, promoting interpretability and security for WLAN. The router includes a CD with an Easy Setup Assistant to lead you through the setup process step-by-step and even assists you with wireless network settings and security configurations.

TP-Link TL-WR940N Features

  • Wireless N speed up to 300Mbps makes it ideal for bandwidth consuming or interruption sensitive applications like video streaming, online gaming and VoIP
  • 3T3R MIMO delivers greater throughput at range versus conventional 2T2R
  • Easily setup a WPA encrypted secure connection at a push of the QSS button
  • WDS wireless bridge provides seamless bridging to expand your wireless network
  • SST dramatically increases link robustness and stability
  • CCA improves wireless performance while automatically avoiding channel conflicts
  • QoS function assures the quality of VoIP and multimedia streaming
  • Features parental control function managing the internet access of children or employee's computer
  • Supports virtual server, special application and DMZ host ideal for creating a website within your LAN
  • Offers Auto-mail function for system log, convenient for managing the router
  • Backward compatible with 802.11b/g products
  • Easy Setup Assistant provides quick & hassle free installation
  • External fixed antennas allow for better alignment and stronger antenna upgrades
  • Sleek exterior, can be mounted on a wall or placed horizontally on a table or desk

TP-Link TL-WR940N Specifications

Interface
4 10/100Mbps LAN PORTS
1 10/100Mbps WAN PORT
Button
Quick Setup Security Button
Reset Button
External Power Supply
9VDC / 0.85A
Wireless Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Antenna
3dBi Fixed Omni Directional Antenna
Frequency
2.4-2.4835GHz
Signal Rate
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
EIRP
<20dBm(EIRP)
Reception Sensitivity
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Wireless Functions
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security
64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
WAN Type
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)/BigPond
DHCP
Server, Client, DHCP Client List, Address Reservation
Quality of Service
WMM, Bandwidth Control
Port Forwarding
Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS
DynDns, Comexe, NO-IP
VPN Pass-Through
PPTP, L2TP, IPSec (ESP Head)
Access Control
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
Management
Access Control
Local Management
Remote Management
Certification
CE, FCC, RoHS
System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
Operating Temperature
0 Deg.C to 40 Deg.C (32 Deg.F to 104 Deg.F)
Storage Temperature
-40 Deg.C to 70 Deg.C (-40 Deg.F to 158 Deg.F)
Operating Humidity
10% to 90%, non condensation
Storage Humidity
5% to 90% non-condensing
Dimensions ( W x D x H )
7.9 x 5.5 x 1.2" (200 x 140 x 28mm)
Mfr #
TL-WR940N
SKU
TPLWR940N
