| Windows Requirements |
Computer: Avid-qualified Windows-based computer or laptop OS: Windows 7 Professional (64-bit), Windows XP Professional SP3 (32-bit), Windows Vista Business SP2 (64-bit), Windows Vista Ultimate SP2 (64-bit) Processor: Intel Core 2 Duo 2.33 GHz processor/faster Memory: 2GB of RAM (Windows Vista requires 4GB of RAM) Graphics Card: NVIDIA Quadro FX family Internal Hard Drive: Minimum 80GB 7200 rpm hard disk Connectivity: Free FireWire port for Mojo SDI |
| Mac Requirements 2 |
Computer: Avid-qualified Mac-based computer or laptop (see details) OS: Mac OS X 10.6.3 (Snow Leopard) Processor: Intel Dual or Intel Dual Core 2.66 GHz Xeon processor or faster, or Intel Core 2 Duo 2.33 GHz processor or faster (laptops) Memory: 2 GB of RAM (4 GB of RAM recommended) Graphics Card: NVIDIA GeForce family Internal Hard Drive: Minimum 80 GB 7200 rpm hard disk Connectivity: Free FireWire port for Mojo SDI |
| Video |
SD 1:1 interlaced 8-bit 1:1 interlaced 10-bit 1:1 progressive 8-bit 1:1 progressive 10-bit HD 1:1 8-bit (no capture) 1:1 10-bit (no capture) YUV 4:2:2 RGB 4:4:4 (via dual link HD-SDI) |
| Formats |
NTSC 23.976p 24p 30i PAL 24p 25i 25p HD - 720 720p/23.976 720p/25 720p/29.97 720p/50 720p/59.94 HD - 1080 1080p/23.976 1080p/24 1080p/25 1080p/29.97 1080i/59.94 1080i/50 |
| Codecs 1 |
Avid DNxHD All DNxHD formats (review the DNxHD Technology white paper for details) Avid Compressed SD Resolutions AVR (playback only) 15:1s, 4:1s, 2:1s 20:1, 10:1, 3:1, 2:1 35:1p, 28:1p, 14:1p, 3:1p, 2:1p 4:1m, 10:1m, 3:1m(p), 8:1m(p) Avid Proxy Formats Interplay MPEG-2 proxy, MPEG-4 proxy, 720p H.264 proxy (transcode service only) Canon XF 50 Mb/s, 4:2:2 DV DV25 / DVCAM (25 Mb/s): 4:1:1 NTSC, 4:1:1 PAL, 4:2:0 PAL, 24p DV50 (50 Mb/s) |
| Codecs 2 |
HDV JVC HDV (19Mb/s) - 720p Sony HDV (25Mb/s) Canon HDV 1080 at 24p/50i / 59.94i Native project formats: 1080i/59.94, 1080i/50, 720p/23.976 (with support for 24p material), 720p/25, 720p/29.97, 720p/50, 720p59.94 Capture over IEEE-1394, edit, play back, export to file without timecode Ikegami GFCAM GFCAM 50 Mb/s GFCAM 100 Mb/s Microsoft VC-1 VC-1 (edit/play back on Intel Macs only) Panasonic DVCPRO (SD) DVCPRO - 25 Mb/s DVCPRO50 - 50 Mb/s |
| Codecs 3 |
QuickTime ProRes Most QuickTime-compatible movies (playback performance dependent on codec, frame size and hardware configuration) Full metadata support RED R3D (frame sizes scaled to HD) RLX support Full metadata support Sony XDCAM (SD) DV - 25 Mb/s IMX30 - 30 Mb/s IMX40 - 40 Mb/s IMX50 - 50 Mb/s |
| Codecs 4 |
Sony HDCAM SR Lite 220 Mb/s Sony XDCAM EX MPEG - 25 Mb/s CBR MPEG - 35 Mb/s VBR Sony XDCAM HD MPEG - 18 Mb/s VBR MPEG - 25 Mb/s VBR MPEG - 25 Mb/s CBR MPEG - 35 Mb/s VBR MPEG - 50 Mb/s CBR MPEG-4 Proxies |
| File Support 1 |
Canon XF Full native direct access to Canon XF media & metadata Native editing of all listed formats MXF Full native direct access to MXF media & metadata Native editing of all formats Sony XDCAM / XDCAM EX / XDCAM HD Full native direct access to XDCAM Media & metadata Native editing of all listed SD & HD data rates Import via File Access Mode (FAM) over IEEE-1394 Ingest via FTP client over Ethernet Ingest, Playout & Write-back of finished program to XDCAM media |
| File Support 2 |
RED Full native direct access to RED (.R3D) media and metadata Native editing of all listed formats Direct edit of RED (.R3D) files from a RED-FLASH card or RED-DRIVE QuickTime Full native direct access to QuickTime media and metadata (including Canon 5D and 7D media) Native editing of all listed formats Direct edit of QuickTime movie files Sony HDCAM SR Lite Full native direct access to HDCAM SR Lite media and metadata Native editing of all listed HD data rates |
| File Support 3 |
Panasonic P2 Full native direct access to P2 Media and metadata Native DVCPRO HD editing of all listed HD formats (see Native Codec Support) Direct edit of P2 media from cards or disk drive Support for P2 Store Write-back of finished program to P2 media (Windows only) Ikegami GFCAM Full native direct access to GFCAM material and metadata Native GFCAM editing of all listed formats (see Native Codec Support) Direct edit of GFCAM media from GFPAK cards or disk drive |
| Video System |
NTSC/PAL |
| Video Formats |
Standard Definition I/O (4:2:2), DV (4:1:1) |
| Audio Formats |
20-bit analog input and output 24-bit audio file compatible with Digidesign Pro Tools |
| Host Connection |
FireWire 400 |
| Input and Output Connectors |
Composite Video: RCA (x1 Input, x1 Output) Component Video: RCA (x1 Input, x1 Output) S-Video: 4-Pin Mini DIN (x1 Input, x1 Output) SDI: BNC (x1 Input, x1 Output) S/PDIF Digital Audio (x1 Input, x1 Output) AES Digital (x4 Input, x4 Output) FireWire: 6-Pin (x1) |
| Real-Time Output |
Component, Composite, S-Video, DV, SDI |
| Real-Time Layers |
Multiple Streams of DV25 and/or one stream of uncompressed video |
| Hardware Real-Time Effects |
Over 115 effects |
| Agency Certifications |
UL, FCC Class A, CE |
| Base Dimensions (W x H x D) |
1 x 11.25 x 6.75" (2.5 x 28.6 x 17 cm) |
| Weight |
1.5 lb (0.68 kg) 2.82 lb (1.28 kg) with stand |
