| Total Video Inputs |
6 |
| SDI Video Inputs |
4 x 10 bit SD/HD switchable |
| HDMI Video Input |
4 x HDMI 1.4a 10 bit SD/HD switchable |
| Analog Video Input |
No |
| Audio Input |
1 x AES/EBU. Unbalanced via BNC connector |
| Sync Input |
Tri-Sync or black burst |
| Internal Frame Synchronizers |
6. All inputs |
| Total Outputs |
6 |
| SDI Program Outputs |
2 x 10 bit SD/HD switchable |
| HDMI Program Outputs |
1 x HDMI 1.4a 10 bit, SD/HD switchable |
| Analog Program Outputs |
No |
| Down Converted SDI Program Outputs |
No |
| Down Converted Composite Program Output |
No |
| SDI Preview Outputs |
No |
| SDI Aux. Outputs |
No |
| SDI M/E 2 Program Output |
No |
| Computer Output |
1 x USB 2.0 H.264 encoded from program output. Media Express for Mac OS X and Windows included |
| Qty of Multi View's |
1 |
| Outputs Per Multi-View |
1 x HD-SDI and 1 x HDMI |
| SDI Audio Outputs |
2 Ch embedded into SDI output |
| Analog Audio Outputs |
No |
| Control Panel Connection |
Ethernet supports 10/100/1000 BaseT. Allows direct connection between panel and chassis, or via network |
| Serial Communication Outputs |
No |
| Software Updates |
Using USB connection directly connected to Mac OS X or Windows computers. Includes ATEM Switcher Utility. |
| Configuration |
Set via ATEM Software Control Panel, excluding ATEM chassis IP address which is set via the ATEM Switcher Utility connected via USB to chassis. |
| Colorspace Conversion |
Hardware based real time |
| HD Down Conversion |
No |
| HD Format Support |
1080i50, 1080i59.94, 720p50, 720p59.94. |
| SD Format Support |
625/25 PAL, 525/29.97 NTSC. |
| SDI Compliance |
SMPTE 259M, 292M |
| Video Sampling |
4:2:2 10 bit |
| Color Precision |
4:2:2 10 bit |
| Color Space |
4:2:2 YUV |
| Media Players |
2 |
| Channels |
2x for fill and key |
| Media Pool Still Image Capacity |
2 with fill and key |
| Media Pool Clip Capacity |
No |
| Maximum Clip Length in 1080i |
No |
| Maximum Clip Length in 720p |
No |
| Maximum Clip Length in NTSC/PAL |
No |
| Media Pool Still Image Format |
PNG, TGA, BMP, GIF, JPEG and TIFF |
| Media Pool Video File Format |
No |
| Media Pool Audio File Format |
No |
| Number of Windows |
1 x 10 |
| Routable Windows |
Fixed Routing |
| Tally |
Red for program and green for preview indication |
| Window Source Labels |
Yes |
| HDMI Input Resolutions for Computers |
720 x 480 59.94Hz, 720 x 576 50Hz, 1280 x 720 59.94Hz 50Hz and 1920 x 1080 59.94Hz 50Hz |
| Redundant Power |
No |
| Input Voltage |
12V-30V |
| Power Consumption |
20W |
| Size |
1 Rack Unit |
| Dimensions (W x H x D) |
19" x 1.75" x 2.5"/482mm x 44mm x 62mm |
| Weight |
3 lbs or 1.4 kg |
