ZyXEL ZyWALL USG300 iCard Unified Security Gateway with SSL VPN 10 to 25 Tunnel Upgrade License

SKU: ZYSU1025G300 MFR: SSL10TO25USG300

About ZyXEL USG300

In addition to basic access control capabilities, the intelligent user-aware policy engine on the ZyWALL USG 300 (SSL10TO25USG300) is designed to make packet-forwarding decisions based on multiple criteria (such as user ID, user group, time of access and network quota, etc.). Furthermore, security staff can apply access policies against a variety of security features such as VPN, Content Filter and Application Patrol. In conjunction with VLAN and custom security zones, corporate security policies can be effectively enforced to prevent unauthorized access to the network resources.

ZyXEL USG300 Features

  • Hybrid VPN, both SSL and IPSec VPNs supported for flexible deployment
  • Comprehensive threat protection with firewall, VPN, anti-virus, content filtering, Intrusion detection and prevention to secure front line threats
  • IM/P2P management can prevent P2P or Instant Messaging applications to increase productivity
  • Flexible security zone using VLAN technology to segregate local networks
  • User-aware policy engine can set bandwidth or network access based on user login
  • Bandwidth management for traffic prioritization for VoIP or mission critical applications
  • Network resilience with multiple WANs, 3G cellular support and device high availability

ZyXEL USG300 Specifications

SPI Firewall Throughput
IPSec VPN (AES) Throughput
Maximum SSL VPN Tunnels
New Session Rate
2,000 (sessions/sec)
No of users
10-25 User
Clientless Secure Remote Access (Reverse Proxy Mode)
SecuExtender (Full Tunnel Mode)
Unified Policy Enforcement
Supports Two Factor Authentication
Customizable User Portal
Routing Mode / Bridge Mode / Mixed Mode
Layer 2 Port Grouping
Ethernet / PPPoE / PPTP
Tagged VLAN (802.1Q)
Virtual Interface (Alias Interface)
Policy-Based Routing (User-Aware)
Policy-Based NAT (SNAT / DNAT)
RIP v1 / v2
IP Multicasting (IGMP v1 / v2)
DHCP Client / Server / Relay
Built-in DNS Server
Dynamic DNS
Bandwidth Management
Bandwidth Priority
Policy-Based Traffic Shaping
Maximum / Guaranteed Bandwidth
Bandwidth Borrowing
Internal User Database
Microsoft Windows Active Directory
External LDAP / RADIUS User Database
ZyWALL OTP (One Time Password)
Force User Authentication (Transparent Authentication)
High Availability
Device HA (Active-Passive Mode)
Device Failure Detection
Link Monitoring
Auto-Sync Configurations
Multiple WAN Load Balancing
VPN HA (Redundant Remote VPN Gateways)
System Management 1
Role-Based Administration
Simultaneous Administrative Logins
Multi-Lingual Web GUI (HTTPS / HTTP)
Object-Based Configuration
Command Line Interface (Console / WebConsole / SSH / TELNET)
Comprehensive Local Logging
System Management 2
Syslog (4 Servers)
E-mail Alert (2 Servers)
Real-Time Traffic Monitoring
System Configuration Rollback
Text-Based Configuration File
Firmware upgrade via FTP / FTP-TLS / Web GUI
Advanced Reporting (Vantage Report 3.1*)
Centralized Network Management (Vantage CNM 3.0*)
256MB RAM / 256MB Flash
GbE x 7 (RJ-45, with LED)
Auto-Negotiation and Auto MDI/MDI-X
A Console
RS-232 (DB9F)
RS-232 (DB9M)
LED Indicator
Power Switch
Reset Pinhole
Extension Card Slot
Yes (2)
Yes (2)
Rack Mountable
Yes (19-inch, rack-mount kit included)
Input Voltage
100-240VAC, 50/60Hz, 0.55-0.3A
Power Rating
35W Max
Operating Temperature
32deg.F - 122deg.F / 0deg.C - 50deg.C
Storage Temperature
-22deg.F - 140deg.F / -30deg.C - 60deg.C
20% to 95% (non-condensing)
Standard Compliance
HSF (Hazardous Substance Free): RoHS and WEEE
EMC: FCC Part 15 Class A, CE-EMC Class A, C-Tick Class A, VCCI Class A
Safety: CSA International (ANS/UL60950-1, CSA60950-1, EN60950-1, IEC60950-1)
Dimension (W x D x H)
17" x 8.3" x 1.7" / 430.0 x 201.2 x 42.0 mm
6.2lbs / 2800g
