New Arrival

Astera Helios Tube 1.8' 24W RGB LED Tube 4-Light Kit

SKU: ASFP2QUADSET MFR: FP2-QUAD SET
Earn VIP Reward Points

Key Features

  • Experience vibrant, customizable lighting with the Astera Helios Tube, perfect for dynamic visual effects.
  • Achieve precise color matching and stunning illumination with a wide 1750-20,000K RGB LED color temperature range.
  • Enjoy creative freedom on location with the built-in battery, offering up to 20 hours of continuous operation.
  • Control your lighting wirelessly via Wi-Fi, CRMX, or Wireless DMX for seamless integration into any setup.
  • The water-resistant (IP65) design ensures reliable performance in diverse environments, from studios to outdoor shoots.
  • Effortlessly manage settings and effects using the intuitive AsteraApp on your Android or iOS device.
See More Product Details
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Astera Helios Tube Specifications

General

General

Jump to...
  • Tube Length

    1.8' (0.5m)

  • Water Resistance/IP Rating

    Water-Resistant (IP65)

Light Fixture

Jump to...
  • Fixture Type

    LED Light Tube/Wand

  • Number of Heads/Lights

    4x

  • Photometrics

    3200K: 33 fc / 360 Lux at 3.3' (1m)
    4000K: 36 fc / 393 Lux at 3.3' (1m)

  • Color Accuracy Standard

    96

  • Color Temperature

    RGB

  • Color Temperature Range

    1750 to 20,000K

  • Dimming

    Built-In Dimmer

  • Cooling System

    Passive

  • Power Source

    Battery (Built-In)
    AC to DC Adapter (Not Included)

  • Power Consumption

    24W

  • Lumens

    1285 (at 3200K)
    1340 (at 4000K)

Mounting

Jump to...
  • Fixture Mounting

    2x M5 Female Thread

  • Front Accessory Mount

    No

  • Umbrella Mount

    No

Connectivity

Jump to...
  • Wireless Control

    Wi-Fi
    CRMX
    Wireless DMX

  • Mobile App Compatible

    Yes: Android & iOS
    App Name: AsteraApp
    Functionality: Remote Control, Setup

Battery

Jump to...
  • Battery Type

    Non-Universal

  • Battery

    4x Rechargeable (Built-In)
    Up to 20-Hour Runtime
    3-Hour Charge Time

Physical Details

Jump to...
  • Dimensions

    21.6 x 1.6" (54.9 x 4.1cm)

  • Weight

    1.69 lbs (766g)

  • Country of Origin

    China

About Astera Helios Tube

Shorter tube for more portability and flexibility.
Helios Tube has all the features of the popular Titan Tube while offering a smaller format. It allows mounting in areas where a Titan Tube wouldn't fit, and also increases portability. This LED lighting Tube has 8 pixels, half the brightness of the Titan tube and just over half its length. Colors and brightness are perfectly matched to those of the Titan Tube's.

Mounting accessories

TubeStand
Tripod with M5 thread to set up your tube vertically. Can be folded for storage. Compatible with Titan Tube, Helios Tube, AX1 PixelTube.

TubeHolder
Essential grip to mount tubes. Connect Astera's BabyPin to the backside 1/4"-20 thread to insert it into Super Clamps and Gobo Heads. Comes with pin to keep it securely locked.

EyeBolt
EyeBolt with M5 thread that works with Astera's tubes and a wide range of other Astera products. Also used as safety mounting point for tubes.

App Control
AsteraApp offers intuitive and fast control of complex lighting setups and is also used for preparation and monitoring of our lights.

Wireless DMX
All Astera lights contain a wireless DMX module by LumenRadio, enabling them to be controlled by CRMX and W-DMX transmitters alongside other wireless fixtures. The AsteraBox has built-in CRMX and can be used to transmit DMX data to your lights. (Sold Separately)

Wired DMX
Connect power and DMX, Artnet or sACN to an Astera PowerBox. Then, connect your lights with a Power/Data combination cable. (Sold Separately)

On your light
The control panel offers intuitive control over your light. Dedicated buttons offer swift control over brightness and HSI colors.

Built-in Battery
Helios Tube has a powerful built-in battery. With our "seamless runtime" technology, it can be set to a specific length of time to ensure that your lights won't run out of battery while still getting the maximum brightness. When displaying white light in maximum brightness, it will last 1 h 45 min.

Power Supply
AC to DC power converter to charge 1 Titan Tube or Helios Tube or to wire it for a longer installation. Usable in most countries since it comes with EU, US, UK adapters and accepts 110-240VDC. 1 m cable length and 24VDC, 2A output.

Seamless Runtime
To ensure that your light's batteries last throughout your entire production, you can select how many hours they have to last. This limits the light's output to a level where you get the maximum brightness to achieve the selected runtime.

Effects
Quickly build programs out of colors and effects, trigger them or make them match a beat. Turn multiple programs and lights into scenes.

Talkback+
Detect all available lights, set them up, check their status, configure DMX addresses and DMX profiles.

Anti-Theft
When enabled, the integrated theft alarm gives visual and audible alarm if lights are being moved. In addition, the AsteraApp also shows the alarm.

Emergency Light
With this innovative feature, the lights can double as a battery-powered emergency light. When activated, the fixture can detect power loss and instantly switches to bright white light to illuminate the venue.

Astera Helios Tube Features

  • 4 lights with chargers, accessories & bag
  • Portable design for charging & mounting
  • 393 lux output at 3.3 ft per light
  • 1750K-20,000K CCT range + RGB mode
  • Control via onboard, DMX, CRMX & app
  • High color accuracy: CRI 96, TLCI 96
  • Customizable lighting effects included
  • Built-in battery, up to 20 hrs runtime
  • Optional PowerBox for extended power
  • IP65 water & dust resistant build

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Experience vibrant, customizable lighting with the Astera Helios Tube, perfect for dynamic visual effects.
  • Achieve precise color matching and stunning illumination with a wide 1750-20,000K RGB LED color temperature range.
  • Enjoy creative freedom on location with the built-in battery, offering up to 20 hours of continuous operation.
  • Control your lighting wirelessly via Wi-Fi, CRMX, or Wireless DMX for seamless integration into any setup.
  • The water-resistant (IP65) design ensures reliable performance in diverse environments, from studios to outdoor shoots.
  • Effortlessly manage settings and effects using the intuitive AsteraApp on your Android or iOS device.

What's in the box:

  • 4x Astera Helios Tube 1.8' 24W RGB LED Tube Light
  • 4x Charger
  • 4x Foldable Stand
  • 8x Astera M5 Eyebolt
  • 8x Astera Metal Holder
  • 8x Baby Pin Double-Ended Spigot
  • Soft Bag
  • Astera 2 Year Limited Warranty
