New Arrival

Logitech Rally Bar 4K UHD All-in-One Video Conference Camera with CTL Meet Compute SFF PC and 10.1" TAP Touch Controller for Medium Google Meet Meeting Room

SKU: LOTAPRGLCTL4 MFR: TAPRBGGGLCTL4
Earn VIP Reward Points

Key Features

  • Experience seamless 4K conference camera quality with the Logitech Rally Bar for crystal-clear video calls.
  • Enhance your Google Meet sessions with the included SFF PC, delivering reliable and powerful performance.
  • Effortlessly manage meetings using the intuitive 10.1" TAP Touch Controller, ensuring smooth navigation.
  • Benefit from advanced AI Viewfinder technology, intelligently framing participants for inclusive virtual meetings.
  • Enjoy superior audio with beamforming microphones and noise suppression, making every voice heard clearly.
  • The all-in-one design simplifies setup and provides a professional, clutter-free conference room solution.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Logitech Rally Bar + SFF PC + TAP Specifications

Rally Bar: General

Rally Bar: General

Jump to...
  • Color

    Graphite

  • Compatibility

    USB Mode: Windows 11, Windows 10, the two most recent versions of macOS
    Appliance Mode: Room solution software license (not included)

  • Built-in Components

    6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management and retention system, table stand, Logitech CollabOS platform

  • Enclosure

    All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference

  • Device Management

    Logitech Sync

  • Displays Supported

    2

  • Display Resolution

    Up to 1080p

  • Network Protocol Support

    IPv4, IPv6

  • Proxy Support

    IP based Proxy, FQDN based Proxy, Proxy using PAC file

  • Country of Origin

    China

Rally Bar: Camera

Jump to...
  • Resolution

    4K, 1440p, 1080p, 900p, 720p, and SD at 30fps

  • Pan

    Motorized +/-25 Degree

  • Tilt

    Motorized +/-15 Degree

  • Zoom

    15X HD zoom (5X optical and 3X digital)

  • Diagonal Field of View

    90 Degree

  • Horizontal Field of View

    82.1 Degree

  • Vertical Field of View

    52.2 Degree

  • Total Room Coverage

    132.1 Degree Horizontal x 82.2 Degree Vertical (field of view + pan and tilt)

Rally Bar: Speakers

Jump to...
  • Drivers

    2x 2.7" (70mm)

  • Sensitivity

    92dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at 1/2 meter

  • Rated Power

    8W

  • THD

    1kHz < 2% at 1W

  • Speaker Sampling Rate

    48 kHz

  • Impedance

    4 Ohms

Rally Bar: Microphones

Jump to...
  • Frequency Response

    90Hz - 16kHz

  • Sensitivity

    >-36dBFS +/-1 dB @ 1Pa

  • Microphone data rate output

    48KHz

  • Pickup Range

    Up to 23' (7m)

  • Beamforming Elements

    6 omnidirectional digital MEMS microphones forming 5 adaptive acoustic broadside beams

  • Audio processing

    AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)

  • Noise suppression

    AI based de-noising algorithm

  • Add-on Mics

    Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms

Rally Bar: RightSense Tech

Jump to...
  • RightLight

    Renders natural skin tones for each participant

  • RightSight

    Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room

  • RightSound

    Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo

  • Grid View

    Detects and frames all meeting participants in order to create equitable hybrid meeting experiences.

Rally Bar: Interfaces

Jump to...
  • HDMI Out

    2x (up to 1080p)

  • HDMI In

    1x

  • USB

    3x Type A, 1x Type C

  • Network

    10/100/1G Ethernet

  • Wi-Fi

    802.11a/b/g/n/ac (Rally Bar No-Radio does not support Wi-Fi connectivity)

  • External Mic Input

    Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)

  • Remote Control

    Bluetooth Low Energy (Rally Bar No-Radio does not have a remote control and/or support Bluetooth)

Rally Bar: Power & Cables

Jump to...
  • Power supply

    Auto-sensing

  • Operating Voltage/Power

    100-240V, 19V, 4.74A

  • DC Cable

    5' (1.5m)

  • AC Cable

    3.28' (1m)

  • HDMI 1.4 Cable

    6.5' (2m)

  • USB A to USB C 3.0 Cable

    7.2' (2.2m)

Rally Bar: Environmental

Jump to...
  • Operating Temperature

    32 to 104 Degree F (0 to 40 Degree C)

  • Storage Temperature

    -40 to 158 Degree F (-40 to 70 Degree C)

  • Humidity

    10 to 95%

  • BTU/hr

    57 idle, 64 in meeting

Rally Bar: Security

Jump to...
  • Full Disk Encryption

    AES-128

  • Data Encryption

    Symmetric Keys, PKI

  • Device Identity

    Protected by device attestation

  • Device Access

    Authenticated using API

  • Key Protection

    Arm TrustZone, RPMP

Rally Bar: Accessories

Jump to...
  • Mounts

    Wall Mount for Video Bars, TV Mount for Video Bars

  • Audio

    Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable

  • Connectivity

    Logitech Strong USB Cable 32.81' (10m)
    65.6' (25m)
    147.64' (45m)

  • Touch Controller

    Logitech Tap and Tap IP

Rally Bar: Certifications

Jump to...
  • Certifications & Compatibility

    For the latest information on certifications and compatibility
    Microsoft Teams Rooms on Android
    Microsoft Teams Rooms on Windows

Rally Bar: Physical

Jump to...
  • Lens Depth

    1.13" (28.8mm)

  • Dimensions (H x W x D)

    6.46 x 35.88 x 5.14" (164 x 910 x 130.5cm)
    Power Supply: 5 x 2.01 x 1.18" (127 x 51 x 30mm)

  • Weight

    15.6 lbs (7.08kg)

TAP Touch Controller

Jump to...
  • Color

    Graphite

  • Room Solutions Compatibility

    Google Meet on ChromeOS
    Google Meet on Android

  • Screen size

    10.1" (25.65cm) diagonal touch display
    1280 x 800 pixels

  • Screen type

    Capacitive Touch with Oleophobic Coating

  • Power

    Included Power Supply inline via Cat5e

  • Connectivity

    Cat5e ethernet kit (9.7' (2.97m)
    22' (7m) Cat5e cables)

  • Content-Sharing

    HDMI ingest

  • Motion sensor

    Yes

  • Built-in cable

    Yes (retention and strain relief)

  • Headphone jack

    Yes

  • Compatible Accessories

    Riser, Table, Wall Mounts

  • Dimensions (W x D x H)

    9.60 x 7.04 x 2.28" (244 x 179 x 58mm)

  • Weight

    2.75 lbs (1.25kg)

Meet Compute SFF PC

Jump to...
  • Operating System

    Google Chrome OS for Meet

  • Graphics

    Intel Iris Xe Graphics

  • Form Factor

    Small Form-Factor PC

  • Processor

    Intel Core i5-1335U 1.3GHz( Up to 4.6GHz Max Frequency)

  • Memory

    16GB LPDDR4x 4266 SDRAM

  • Storage

    256GB SSD

  • Wi-Fi

    Wi-Fi 6E

  • Bluetooth

    5.2

  • Ports

    2x USB-C
    2x HDMI
    2x USB 3.0
    1x Thunderbolt, Barrel Jack (Power)
    1x RJ45 1GbE

  • Dimensions (W x D x H)

    11.5 x 5.25 x 1.13" (29.21 x 13.34 x 2.87cm)

  • Weight

    3.2 lbs (1.45kg)

  • UPC Code

    0715663131182

About Logitech Rally Bar + SFF PC + TAP

Better Together For The Hybrid Worker
Reimagine work with solutions for a hybrid world. Logitech and Google Meet make meetings more collaborative, more productive, and even more enjoyable. So you can give every employee the ability to work from anywhere, maximize their impact, share knowledge, and fully participate regardless of location, device, language, or experience level. Bridge the gap between in-person and anywhere else with Google Meet-certified Logitech video solutions.

Flexible Solutions For Every Room Size
Bring meetings to life with Logitech hardware and Google Meet. Our flexible solutions for Large rooms let you choose between a Google Meet Compute deployment or Google Meet on Android, and switch as your needs evolve. With Logitech and Google Meet, you can drive connection, communication, and creativity wherever people get business done. That's the New Logic of Work.


- Rally Bar -
Logitech Rally Bar is the premier video bar for medium to large meeting rooms. Discover remarkably simple, all-in-one video conferencing with built-in AI technology, brilliant optics, and powerful audio.

All-in-One Video Bar for Medium and Large Rooms
Discover a remarkably simple all-in-one video conferencing setup with brilliant optics, AI-based audio, remote management with Logitech Sync, and more.

Expand the Conversation
Add up to four Rally Mic Pods to extend the audio pick up range and provide convenient access to mute controls.

Ensure Everyone Is Seen and Heard
AI video intelligence, advanced sound pickup, noise suppression, and continuous software improvements provide a clear and natural meeting experience for remote workers.

Manage Remotely with Sync
Monitor room and device health, deploy updates, and modify settings, all from a single cloud-based platform.

Certified for Business
Leverage the video conferencing platforms and features you already use. Rally Bar is certified for leading video platforms like Microsoft Teams, Zoom, and Google Meet.


- Tap Touch Controller -
Make video meetings simple to join with a USB-connected touch controller with an included Cat5e Kit for flexible cabling.

Deploy Room Solutions with Ease
Transform your space into a Google Meet room with Logitech Tap. Deliver one-touch join, calendar integration, easy content-sharing, and a consistent experience across all rooms.

Clean and Convenient Setup

Just the Right Presence
With a spacious 10.1" display, low profile, and motion sensor for always-on readiness, Tap has a sleek and unobtrusive presence in the room.

Simple and Secure Cabling
Route cables out the back or through the bottom. Keep connections tight with built-in strain relief and retention mechanisms.

Multiple Mounting Options
Install Tap almost anywhere in the room with Table and Riser Mounts that fit standard grommets and rotate 180 Degree for visibility and convenience, or save table space in small rooms with the Wall Mount.

Clean Installation
Use the included or compatible category cabling to position the controller flexibly, up to 131 ft (40 m) away. This allows Tap to be conveniently placed near participants for easy operation, while installing the host computer in a cabinet, beneath a table, or behind a display.

Share Effortlessly
Bring instant content sharing via wireless or HDMI connections to video meetings rooms with Tap.

Simple To Manage
With Logitech Sync, you can monitor and manage Tap along with your other meeting room devices from one single platform.

Enhanced Performance with Logitech Services
Remove barriers to effective collaboration with global support, powerful software, and fast product replacements.

Expert Help Desk
Keep downtime to a minimum with fast response times. Our experts have deep expertise in video collaboration and partner ecosystems for quick issue resolution.


- CTL Meet Compute System -
Introducing CTL's newly redesigned Meet Compute System, refreshed for enhanced performance. An Enterprise-grade solution for Meet purposefully designed to provide an effortless setup process while prioritizing reliability and security.

Our product is built with rigorously tested, enterprise-grade production materials and combines multiple seating and mounting options with secure on-device encryption to make it both durable and reliable.

In addition to outstanding performance, the CTL Meet Compute was designed with sustainability in mind, including the use of 75% Post post-consumer recycled plastics and eco-friendly packaging with FSC certification. Finally, it meets the latest Energy Star standards to meet your power conservation needs.

With the CTL Meet Compute system, you'll have the power of an Enterprise computing solution at your fingertips without sacrificing scalability or security. Introducing CTL's newly redesigned Meet Compute System, refreshed for enhanced performance. An Enterprise-grade solution for Meet purposefully designed to provide an effortless setup process while prioritizing reliability and security.

Logitech Rally Bar + SFF PC + TAP Features

  • All-in-one Rally Bar delivers brilliant optics and powerful AI-driven audio
  • Add up to four Mic Pods to extend pickup range and mute access
  • AI video intelligence ensures everyone is clearly seen and heard
  • Manage rooms and devices remotely with Logitech Sync
  • Certified for leading platforms like Google Meet
  • Tap controller offers one-touch join and easy content sharing
  • Flexible mounting and secure cabling for clean, convenient installs
  • CTL Meet Compute provides secure, enterprise-grade performance and reliability

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Experience seamless 4K conference camera quality with the Logitech Rally Bar for crystal-clear video calls.
  • Enhance your Google Meet sessions with the included SFF PC, delivering reliable and powerful performance.
  • Effortlessly manage meetings using the intuitive 10.1" TAP Touch Controller, ensuring smooth navigation.
  • Benefit from advanced AI Viewfinder technology, intelligently framing participants for inclusive virtual meetings.
  • Enjoy superior audio with beamforming microphones and noise suppression, making every voice heard clearly.
  • The all-in-one design simplifies setup and provides a professional, clutter-free conference room solution.

What's in the box:

  • CTL Meet Compute SFF PC (CBXUS190020)
  • Logitech 2 Year Limited Warranty
