Ikan Lyra LBF60Z-POE Bi-Color LED Fresnel Zoom 3-Light Kit with Netgear PoE++ Ultra60 Unmanaged Switch

SKU: IALBF60ZPOE MFR: LBF60Z-POE-3L-1SU
Earn VIP Reward Points

Key Features

  • Achieve superior color accuracy with a CRI of 97 & TLCI of 98 on these LED Fresnel lights.
  • Enjoy precise brightness control with the built-in dimmer, adjustable from 0 to 100%.
  • The 3.25" lens diameter offers a beam angle from 30 to 60 degrees for versatile lighting.
  • Each LED Fresnel light is equipped with a fan cooling system for optimal heat management.
  • Easily mount these lights using the 5/8" receiver and manually-operated yoke included.
  • This Bi-Color LED Fresnel zoom kit includes a Netgear PoE++ switch for easy setup.
See More Product Details
Pre Order Now?
Free Expedited Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$129.99

3 Year

$179.99

4 Year

$215.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Ikan LBF60Z-POE Specifications

General

General

Jump to...
  • Color Temperature

    Bi-Color

  • Color Temperature Range

    2700-6500K

  • Beam Angle

    30 to 60 Degree

  • Lens Diameter

    3.25" (8.26cm)

Light Fixture

Jump to...
  • Fixture Type

    LED Fresnel

  • Number of Heads/Lights

    3

  • Photometrics

    60 Degree at 3200K:
    73 fc / 794 Lux at 3.3' / 1 m
    9 fc / 102 Lux at 9.8' / 3 m
    60 Degree at 5600K:
    86 fc / 931 Lux at 3.3' / 1 m
    10 fc / 117 Lux at 9.8' / 3 m
    30 Degree at 3200K:
    566 fc / 6097 Lux at 3.3' / 1 m
    68 fc / 740 Lux at 9.8' / 3 m
    30 Degree at 5600K:
    612 fc / 6592 Lux at 3.3' / 1 m
    75 fc / 811 Lux at 9.8' / 3 m

  • Dimming

    Built-In Dimmer / DMX:
    0 to 100%

  • Cooling System

    Fan

  • Color Accuracy Standard

    CRI 97
    TLCI 98

  • Power Source

    AC to DC Adapter (Not Included)

  • Power Consumption

    60W

  • Inline Switch

    No

Mounting

Jump to...
  • Front Accessory Mount

    Proprietary

  • Fixture Mounting

    1x 5/8" Receiver (Via Yoke Mount)

  • Umbrella Mount

    No

  • Yoke Type

    Manually-Operated Yoke

Battery

Jump to...
  • Battery Connection

    No connection included

Connectivity

Jump to...
  • Mobile App Compatible

    No

Physical Details

Jump to...
  • Dimensions

    14.3 x 5.8 x 4.2" (36.3 x 14.7 x 10.7cm)

  • Weight

    3.6 lbs (1.6kg)

  • UPC Code

    847983037605

Models
Ikan Lyra LBF60Z-POE Bi-Color LED Fresnel 3-Light Kit with PoE++ Ultra60 Switch
$3,799.00

$3,999.00

Save:$200.00 (5%)

Pre Order Now

You may place this on order now and it will be shipped on a first come first serve basis. We do not charge your card until we actually ship.

Ikan Lyra LBF60-POE 3.25" 60W Bi-Color Fresnel LED 3-Light Kit w/Ultra60 Switch
$3,199.00

$3,399.00

Save:$200.00 (6%)

Ships from Manufacturer

Usually ships within 2-5 Days. Delivery is subject to availability.

Ikan Lyra 1x1 Bi-Color 3-Point Soft Panel LED Light Kit
$2,899.00

$3,099.00

Save:$200.00 (6%)

Ships from Manufacturer

Usually ships within 2-5 Days. Delivery is subject to availability.

Kit Style3 Light Kit3 Light Kit3 Light Kit
Power SourceACAC/DCAC/DC
MountManual YokeStand Mount-
Color TemperatureBi-ColorBi-ColorBi-Color
Battery ConnectionNo Connection IncludedNo Connection IncludedGold & V Mount
Color Temperature Range2700-6500K2700-6500K3200-5600K
Panel Size--14" x 14"

About Ikan LBF60Z-POE

The Ikan LBF60Z-POE is a PoE-powered Fresnel light designed for professional studio, broadcast, and stage applications. Building on the foundation of its predecessor, it utilizes a single Ethernet (RJ45) cable for both power and DMX control, thanks to PoE++ compatibility. The light features a manual zoom Fresnel lens, allowing users to smoothly adjust the beam angle anywhere between 30 to 60 degrees, providing greater flexibility to shape and control light output. Outfitted with high-CRI (97) LEDs, it delivers exceptional color accuracy across a wide color temperature range from 2700K to 6500K. The robust aluminum yoke with tension knobs ensures secure positioning, while the rear control panel with an LED display allows for precise adjustment of brightness, color temperature, and DMX settings. Seamless integration with Q-SYS systems is supported through the Q-SYS Designer Plugin, enhancing workflow efficiency. The LBF60Z-POE combines power, versatility, and networked control into a compact, professional lighting solution.

Power Over Ethernet PoE++
The LBF60Z-POE is powered using a single Ethernet cable (Cat6 RJ45 24AWG or better). This eliminates the necessity for additional wiring or power outlets, saving both time and reducing installation costs on obtaining permits or hiring electricians to install new ceiling outlets. The LBF60Z-POE supports IEEE 802.3bt Type 3 PoE++, ensuring efficient power delivery over the network.

Note: IEEE 802.3bt Type 3 switch is required

ArtNet and sACN Compatibility
The LBF60Z-POE supports both ArtNet and sACN DMX protocols. A single RJ45 cable can be used for both power and DMX. This versatility empowers users to integrate the light seamlessly into their preferred DMX control systems.

Q-SYS Designer Plugin Integration
Easily integrate Ikan Lyra PoE Lights into your Q-SYS ecosystem with the Q-SYS plugin, available in the Q-SYS Designer Asset Manager. This plugin allows users to control light intensity and color temperature for up to 256 lights per universe directly within Q-SYS Designer. Designed for streamlined workflows in spaces like conference rooms, the plugin eliminates the need for specialized lighting knowledge. With the press of a button, all lights can be set to optimal, pre-configured settings, ensuring a seamless and user-friendly experience for any environment.

Web GUI
Utilize the web GUI to modify ArtNet & sACN settings, including DMX addresses and universes, as well as access configured IP address settings.

Adjustable Beam Angle
The LBF60Z-POE's manual zoom Fresnel lens gives you full control over your beam angle, allowing smooth adjustment from a narrow 30 Degree spotlight to a wide 60 Degree flood-and anywhere in between. Whether you need a tight, focused beam to highlight your subject or a broader wash for even coverage, simply twist the lens to dial in the perfect spread. This seamless flexibility lets you adapt your lighting to any scene without the hassle of swapping lenses or repositioning your fixture.

Low-Profile
The Ikan LBF60Z-POE is perfect for areas with low ceiling clearance, combining functionality with adaptability. It includes a baby 5/8" and junior 1 1/8" combo pin, allowing for versatile mounting options on grids, drop ceilings, or light stands to suit a range of lighting configurations.

Ikan LBF60Z-POE Features

  • 3 x 60W PoE++ Light
  • Includes Netgear Ultra60 PoE++ 802.3bt 380W Switch
  • 60W PoE++ Light
  • Art-Net & sACN DMX-Over-IP
  • Q-SYS Control Compatible
  • 30 to 60 Degree Beam Angle
  • 97 CRI
  • Bi-Color Adjustable 2700K-6500K
  • Consistent Light Across All Color Temperatures
  • Low Profile Yoke
  • Combo Pin

Warranty Information

This product has a limited warranty of 12 months for parts and 12 months for labor.

Key Features

  • Achieve superior color accuracy with a CRI of 97 & TLCI of 98 on these LED Fresnel lights.
  • Enjoy precise brightness control with the built-in dimmer, adjustable from 0 to 100%.
  • The 3.25" lens diameter offers a beam angle from 30 to 60 degrees for versatile lighting.
  • Each LED Fresnel light is equipped with a fan cooling system for optimal heat management.
  • Easily mount these lights using the 5/8" receiver and manually-operated yoke included.
  • This Bi-Color LED Fresnel zoom kit includes a Netgear PoE++ switch for easy setup.

What's in the box:

  • 3x Ikan Lyra LBF60Z-POE Bi-Color LED Fresnel Zoom Light
  • 3x Standard Yoke
  • 3x Low Profile Yoke
  • 3x Barn Doors
  • 3x Combo Pin
  • 3x Safety Wire
  • PoE++ 380W Unmanaged Ultra60 Switch
  • Ikan 1 Year Limited Warranty
