SBIG Seeing Monitor Specifications

  • CCD

    Kodak KAF-0402ME

  • Pixel Array

    765 x 510 pixels

  • CCD Size

    6.9x4.3mm

  • Total Pixels

    390000

  • Pixel Size

    9x9 microns

  • Full Well Capacity

    - 100,000 e-

  • Dark Current

    - 1e/pixel/sec at 0deg. C

  • Dark Current Doubling Temp

    - 6 deg. C

  • Exposure

    0.04 to 3600 seconds, 10ms resolution

  • Correlated Double Sampling

    Yes

  • A/D Converter

    16 bits

  • A/D Gain

    1.5e- unbinned
    2.0e- binned 2x2, 3x3

  • Read Noise

    13.8e RMS Typical

  • Binning Modes

    1 x 1, 2 x 2, 3 x 3

  • Pixel Digitization Rate

    Up to 800.000 pixels per second with USB 2.0

  • Full Frame Download

    <1 second

  • Lens Focal Length

    150mm

  • Lens Focal Ratio

    f/5.6

  • Field of View

    2.6x1.7 degrees

  • Cooling

    Ambient, or

  • Power

    12VDC, 1A without cooling on, 3A with cooling enabled (power supply included)

  • Computer Interface

    USB 2.0
    (USB 1.1 compatible)

  • Computer Compatibility

    Windows 32 bit and 64 bit

  • Dimensions

    6x8x10" / 15.24x20.32x25.4cm

  • Weight

    17lbs / 7.71kg

About SBIG Seeing Monitor

The SBIG Seeing Monitor is an automated unit for monitoring and logging the seeing throughout a night. The Seeing Monitor, pictured on the right, uses an ST-402ME camera with custom optics and software. The Seeing Monitor is intended to be set up once and left outdoors for an indefinite period.
