New Arrival

Shure SLXD4Q+ Quad-Channel Digital Wireless Rackmount Receiver, G57: 470-608MHz,TAA Compliant

SKU: SHSLXD4QTA MFR: SLXD4Q+TA=-G57
Earn VIP Reward Points

Key Features

  • Four channels in one rack space design with rugged metal construction
  • Rock solid RF with 138 MHz wide-tuning range for greater geographical coverage
  • Once linked, SLX-D+ receivers and transmitters stay connected, despite any RF interference
  • Unlock hands-free oversight for volunteers & engineers
See More Product Details
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Shure SLXD4Q+ TAA Specifications

General

General

Jump to...
  • Color

    Black

  • Material

    Galvanized Steel

  • TAA Compliant

    Yes

  • Environmental Resistance

    No

  • Rackmount Size

    1 RU (Full Rack)

  • Power Requirements

    15 V @ 0.9

  • Country of Origin

    Mexico

RF Input

Jump to...
  • Spurious Rejection

    >75 dB

  • Connector Type

    BNC

  • Impedance

    50 Ohm

  • Bias Voltage

    15 V DC, 150 mA maximum, per antenna

Audio Output

Jump to...
  • Audio Frequency Response

    20 Hz- 20 kHz (+1, -2 dB)

  • Gain Adjustment Range

    -18 to +42 dB in 1 dB steps

  • Configuration

    1/4" (6.35mm): Balanced (Tip=audio +, Ring=audio, Sleeve=ground)
    XLR: Balanced (1=ground, 2=audio +, 3=audio)

  • Impedance

    1/4" (6.35mm): 1.1 k Ohm (550 Ohm Unbalanced)
    XLR (line): 500 Ohm (250 Ohm Unbalanced)
    XLR (mic): 150 Ohm

  • Full Scale Output

    1/4" (6.35mm): +12 dBV Unbalanced (+18 dBV Balanced)
    XLR (LINE setting): +18 dBV
    XLR (MIC setting): -12 dBV

  • Mic/Line Switch

    30 dB pad

  • Phantom Power Protection

    1/4" (6.35mm): Yes
    XLR: Yes

Cascade Output

Jump to...
  • Connector Type

    BNC

  • Configuration

    Unbalanced

  • Impedance

    50 Ohm

  • Insertion Gain

    0-2 dB, typical

Networking

Jump to...
  • Network Interface

    20 Hz- 20 kHz (+1, -2 dB)

  • Network Addressing Capability

    DHCP or Manual IP address

  • Maximum Cable Length

    328' (100m)

Physical

Jump to...
  • Dimensions

    1.65 x 15.47 x 5.98" (42 x 393 x 152mm)

  • Weight

    3.85 lbs (1.75kg) (without antennas)

  • UPC Code

    042406931731

About Shure SLXD4Q+ TAA

The SLXD4Q+ is a quad channel digital receiver for use with SLX-D+ transmitters. Unlock a new world of hands-free oversight and management for seasoned volunteers and pro engineers alike. With a dedicated ShowLink Ease control link, the SLXD4Q+ stays in sync with SLX-D+ transmitters to manage interference, scan for new channels and update for clear transmission automatically. Features a wide 138 MHz tuning range, audio output summing for compact and powerful wireless versatility. Includes SLXD4Q+ Quad Channel Receiver, two 1/4" antennas, two bulkhead adapters, two 22" BNC cables, rack mount kit and power supply.

With ShowLink Ease, transmitter parameters can be adjusted remotely over the air from the linked receiver, including: Changing the transmitter frequency once open frequency is identified, Adjust transmitter gain, Automatically find and deploy new frequency to both receiver and transmitter upon interference, Lock and unlock transmitter controls, Transmitter firmware updates

Shure SLXD4Q+ TAA Features

  • Four channels in one rack space design with rugged metal construction
  • Rock solid RF with 138 MHz wide-tuning range for greater geographical coverage
  • Automatic Setup - once linked, SLX-D+ receivers and transmitters stay connected, despite any RF interference
  • Unlock a new world of hands-free oversight and management for seasoned volunteers and pro engineers alike

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Four channels in one rack space design with rugged metal construction
  • Rock solid RF with 138 MHz wide-tuning range for greater geographical coverage
  • Once linked, SLX-D+ receivers and transmitters stay connected, despite any RF interference
  • Unlock hands-free oversight for volunteers & engineers

What's in the box:

  • Shure SLXD4Q+ Quad-Channel Digital Wireless Rackmount Receiver (TAA Compliant/Black)
  • 2x Bracket
  • 2x 1/4 Wave Antenna
  • 2x Bulkhead BNC Adapter
  • 2x 22" BNC Cable
  • Power Supply
  • Rack Mount Hardware
  • Adhesive Foot
  • Shure 2 Year Limited Warranty
