| Type |
Single-lens reflex digital camera |
| Lens Mount |
Nikon F bayonet mount |
| Picture Angle |
Nikon FX format |
| Effective Pixels |
24.3 million |
| Image Sensor |
CMOS sensor, 35.9mm x 24.0mm, Nikon FX format |
| Total Pixels |
24.7 million |
| Dust-Reduction System |
Image sensor cleaning |
| Dust-Off Reference Photo |
Yes |
| File Format |
JPEG: JPEG-Baseline Compliant; can be selected from Size Priority and Optimal Quality
JPEG: JPEG-Baseline Compliant with fine (approx 1:4), Normal (approx 1:8) or Basic (approx 1:16) Compression
NEF (RAW): Lossless Compressed, Compressed or Uncompressed 12 or 14 bit
TIFF (RGB) |
| Picture Control System |
Landscape
Monochrome
Neutral
Portrait
Standard
User-customizable Settings
Vivid |
| Storage Media |
SD
SDHC
SDXC
Card Slots: 2 Secure Digital (SD) |
| File System |
Compliant with DCF (Design Rule for Camera File System) 2.0
DPOF (Digital Print Order Format)
EXIF 2.3 (Exchangeable Image File Format for Digital Still Cameras)
PictBridge |
| Viewfinder |
Eye-level Pentaprism Single-Lens Reflex Viewfinder |
| Viewfinder Frame Coverage |
FX (36x24): 100% Horizontal and 100% Vertical Approx.
DX (24x16): 97% Horizontal and 97% Vertical Approx. |
| Viewfinder Eyepoint |
20.6mm (-1.0) |
| Viewfinder Diopter Adjustment |
Built-in diopter adjustment (-3 to +1) |
| Viewfinder Magnification |
0.70x Approx. |
| Focusing Screen |
Type B BriteView Clear Matte Mark VIII with AF Area Brackets (grid lines can be displayed) |
| Compatible Lenses |
AF NIKKOR lenses, including type G and D lenses (some restrictions apply to PC lenses) and DX lenses (using DX 24 × 16 1.5x image area), AI-P NIKKOR lenses, and non-CPU AI lenses (A and M modes only).
IX NIKKOR lenses, lenses for the F3AF, and non-AI lenses cannot be used. |
| Reflex Mirror |
Quick-return type |
| Slowest Shutter Speed |
30 sec. |
| Depth-of-field Control |
Yes |
| Bulb Shutter Setting |
Yes |
| Fastest Shutter Speed |
1/4000 sec. |
| Lens Compatibility at a Glanc |
AF-S or AF lenses fully compatible
Metering with AI lenses |
| Shutter Type |
Electronically controlled vertical-travel focal-plane shutter |
| Self-timer |
2, 5, 10, 20 sec. Timer duration electronically controlled |
| Speed |
1/4000 to 30 sec.
Bulb |
| Flash Sync Speed |
Up to 1/200 sec.
Synchronizes with shutter at 1/250s or slower |
| Release Modes |
Continuous low-speed [CL] mode; 1-5 frames per second
Continuous high-speed [CH] mode; 5.5 frames per second
Mirror-up [Mup] mode
Quiet Shutter Release
Self-timer mode
Single-frame [S] mode |
| Continuous Shooting Options |
FX-format
CH: Up to 6 frames per second
CL: Up to 1-5 frames per second |
| Top Continuous Shooting |
at full resolution 5.5 frames per second |
| Mirror Lock Up |
Yes |
| Metering System |
TTL exposure metering using 2,016-pixel RGB sensor |
| Metering System |
Center-weighted: Weight of 75% given to 8mm circle in center of frame
Matrix: 3D color matrix metering II (type G and D lenses); color matrix metering II (other CPU lenses)
Spot: Meters 4mm circle (about 1.5% of frame) centered on selected focus point |
| Metering Range |
0 to 20 EV (3D color matrix or center-weighted metering)
0 to 20 EV (spot metering) |
| Exposure Meter Coupling |
Combined CPU and AI |
| Exposure Modes |
Aperture-Priority (A)
Manual (M)
Programmed auto with flexible program (P)
Shutter-Priority (S) |
| Exposure Compensation |
±5 EV in increments of 1/3, 1/2 or 1 EV in P, S, A, and M modes |
| Exposure Lock |
Yes |
| Exposure Bracketing |
2 or 3 frames in steps of 1/3, 1/2, 2/3, 1 or 2 EV |
| ISO Sensitivity ISO 100 - 6400 |
Lo-1 (ISO 50)
Hi-1 (ISO 12,800)
Hi-2 (ISO 25,600) |
| Lowest Standard ISO Sensitivity |
100 |
| Highest Standard ISO Sensitivity |
6400 |
| Lowest Expanded ISO Sensitivity |
Lo-1 (ISO 50 equivalent) |
| Highest Expanded ISO Sensitivity |
HI-2 (ISO 25,600 equivalent) |
| Expanded ISO Sensitivity Options |
Hi-1 (ISO-12,800 equivalent) in 1/3, 1/2 or 1 EV
Hi-2, (ISO-25,600 equivalent) 1 EV |
| Long Exposure Noise Reduction |
Yes |
| High ISO Noise Reduction |
Low
Normal
High
Off |
| Active D-Lighting |
Auto
Extra High
High
Normal
Low
Off |
| D-Lighting Bracketing |
D-Lighting Bracketing 2 frames using selected value for one frame
3-5 frames using preset values for all frames |
| Single-point AF Mode |
Yes |
| Dynamic AF Mode Number of AF points |
9, 21, 39 and 39 (3D-tracking) |
| Auto-area AF Mode |
Yes |
| Autofocus System |
Nikon Multi-CAM 4800 autofocus sensor module with TTL phase detection |
| Detection Range |
-1 to 19 EV (ISO 100, 68°F/20°C)
Lens Servo Autofocus (AF): Single-servo AF (AF-S); Continuous-servo AF (AF-C); auto AF-S/AF-C selection (AF-A); predictive focus tracking activated automatically according to subject status
Manual focus (MF): Electronic rangefinder can be used |
| AF-area mode |
9, 21 or 39 point Dynamic-area AF
Auto-area AF
Single-point AF
3D-tracking (39 points) |
| Focus Lock |
Focus can be locked by pressing AE-L/AF-L button
Focus can be locked by pressing shutter-release button halfway (single-servo AF) |
| Focus Modes |
Auto AF-S/AF-C selection (AF-A)
Continuous-servo (AF-C)
Face-Priority AF available in Live View only and D-Movie only
Manual (M) with electronic rangefinder
Normal area
Single-servo AF (AF-S)
Wide area |
| Maximum Autofocus Areas/Points |
39 |
| Autofocus Sensitivity |
-1 to +19 EV (ISO 100, 20°C/68°F) |
| Autofocus Fine Tune |
Yes |
| Built-in Flash |
Yes |
| Flash Bracketing |
2 to 3 frames in steps of 1/3, 1/2, 2/3, 1 or 2 EV |
| Built-in Flash Distance |
39 ft. (ISO 100) |
| X-Sync Speed |
1/200 |
| Top FP High Speed Sync |
Up to 1/4000 |
| Flash Control |
TTL: i-TTL flash control using 2,016-pixel RGB sensor are available with built-in flash and SB-910, SB-900, SB-700, SB-400 or SB-300; i-TTL balanced fill-flash for digital SLR is used with matrix and center-weighting metering, standard i-TTL flash for digital SLR with spot metering |
| Flash Sync Modes |
Front-curtain sync (normal)
Rear-curtain sync
Red-Eye reduction
Red-Eye reduction with slow sync
Slow sync |
| Flash Compensation |
-3 to +1 EV in increments of 1/3, 1/2 or 1 EV |
| Flash-ready indicator |
Lights when built-in flash or optional flash unit such as SB-910, SB-900, SB-400, SB-80DX, SB-28DX or SB-50DX is fully charged |
| Accessory Shoe |
Yes |
| Nikon Creative Lighting System |
(CLS) CLS Supported |
| White Balance |
Auto
Choose color temperature (2500K-10000K)
Cloudy
Direct Sunlight
Flash
Fluorescent (7 types)
Incandescent
Preset manual (up to 4 values can be stored)
Shade |
| White Balance Bracketing |
2 or 3 exposures |
| Live View Shooting |
Photography Live View Mode
Movie Live View Mode |
| Live View AF-area mode |
Face-priority AF
Wide-area AF
Normal-area AF
Subject-tracking AF |
| Live View Autofocus |
Contrast-detect AF anywhere in frame (camera selects focus point automatically when face-priority AF or subject-tracking AF is selected) |
| Live View Scene Auto Selector |
Auto mode
Auto (flash off) mode |
| Movie Metering |
TTL exposure metering using main image sensor |
| Movie Maximum recording time |
20 minutes at highest quality
29 minutes 59 seconds at normal quality |
| Movie File Format |
MOV |
| Movie Video Compression |
H.264/MPEG-4 Advanced Video Coding |
| Movie Audio recording format |
Linear PCM |
| Movie |
HD 1,920x1,080 / 30 fps
HD 1,920x1,080 / 25 fps
HD 1,920x1,080 / 24 fps
HD 1,280x720 / 60 fps
HD 1,280x720 / 50 fps
HD 1,280x720 / 30 fps
HD 1,280x720 / 25
|
| Movie Audio |
Built-in microphone, monaural
External stereo microphone (optional) |
| Monitor Size |
3.2 in. diagonal |
| Monitor Resolution |
921,000 Dots |
| Monitor Type |
Wide Viewing Angle TFT-LCD |
| Monitor Angle of View |
170-degree wide-viewing angle |
| Monitor Adjustments |
Brightness, 5 levels
Brightness control using ambient brightness sensor |
| Virtual Horizon Camera Indicator |
Yes |
| Playback Functions |
Auto Image Rotation
Full-Frame and Thumbnail (4, 9, or 72 images or calendar)
Highlights
Histogram Display
Image Comment
Movie Playback
Movie Slideshow
Playback with Zoom
Slideshow |
| In-Camera Image Editing |
Color Balance
Color Outline
Color Sketch
D-Lighting Distortion Control
Edit Movie
Filter Effects
Fisheye
Image Overlay
Miniature Effect
Monochrome
NEF (RAW) Processing
Perspective Control
Quick Retouch
Red-Eye Correction
Resize
Selective Color
Side-by-Side Comparison
Straighten
Trim |
| Image Comment |
Yes |
| Interface |
Accessory Terminal: Remote Cord: MC-DC2 (available separately); GPS
unit: GP-1 (available separately)
HDMI output: Type C mini-pin HDMI connector
Headphone Connector
Hi-speed USB
Stereo Microphone Input |
| Wi-Fi Functionality |
Eye-Fi Compatible
WU-1b Wireless Mobile Adapter |
| GPS |
GP-1 GPS unit
GP-1A GPS unit |
| Save/Load Camera settings |
Yes |
| Total custom Settings |
50 |
| My Menu |
Yes with customization |
| Recent Settings |
Yes |
| Supported Languages |
Arabic
Brazilian Portuguese
Chinese (Simplified and Traditional)
Czech
Danish
Dutch
English
Finnish
French
German
Greek
Hindi
Hungarian
Indonesian
Italian
Japanese
Korean
Norweigan
Polish
Portuguese
Romanian
Russian
Spanish
Swedish
Thai
Turkish
Ukrainian
|
| Date, Time and Daylight Savings Time |
Yes |
| World Time Setting |
Yes |
| Battery / Batteries |
EN-EL15 Lithium-ion Battery |
| Battery Life (shots per charge) |
900 shots per charge (Battery Life) (CIPA) |
| AC Adapter |
EH-5b AC Adapter
Requires EP-5B Power Supply Connector |
| Battery Charger |
MH-25 Quick Charger |
| Tripod Socket |
1/4 in. |
| Approx. Dimensions |
Width: 5.6 in. (141mm)
Height: 4.4 in. (113mm)
Depth: 3.2 in. (82mm) |
| Approx. Weight |
26.8oz. (760g) - camera body only |
| Operating Environment |
0-40 °C (+32 104 °F) |
| Warranty |
Nikon U.S.A. |
