Aten CS1798 8-Port USB 2.0 HDMI KVM Switch with Rack Mounting Kit
SKU: ANCS1798 MFR: CS1798
$439.95
$903.00
Save: $463.05 (51%)OR
Key Features
- Manage up to 8 HDMI computers with this Aten KVM switch, saving desk space and money.
- Enjoy superior video resolution up to 1080p with this high-performance HDMI KVM switch.
- Control multiple systems using a single console with this 8-Port USB KVM switch solution.
- Cascade up to 512 computers for large-scale management using this versatile KVM switch.
- Streamline your workspace with the included rack mounting kit for this Aten KVM switch.
- Share USB 2.0 peripherals between computers using the integrated USB KVM switch hub.
Temporarily On Backorder?Request assistance or get notified
Free Shipping
See Options
1
Protect your gear with Adorama Protect.* Learn more
2 Year
$79.99
3 Year
$109.99
4 Year
$129.99
Available to U.S. customers only.
Need help? Ask our experts.
Overview
Compare
Specs
Protection
Q&A
About Aten CS1798
The CS1798 8-port USB HDMI KVM Switch is a multi-purpose appliance that consolidates access and control of up to 8 HDMI computers from a single USB keyboard, USB mouse and monitor console. The CS1798 can be cascaded up to three levels - to control up to 512 computers - all from a single console. In addition the CS1798 features multi-display functionality, which enables the use of standard USB cables to stack up to eight switches in a multi-display installation where each computer is fitted with multiple video cards. It allows you to contrast, analyze and monitor video output in convenient ways, substantially simplifying the working environment.
Furthermore, the CS1798 comes with ATEN's on-screen display (OSD) function, which can access any computer connected to the installation, it also offers OSD configuration backup/restore to save/back up the OSD settings and restore them as needed. The CS1798 provides multimedia keyboard support and is audio enabled. You can listen to the audio output of each computer on two sets of speakers (on a one at- a-time basis).
Aten CS1798 Features
- One USB console controls up to eight HDMI interface computers and two additional USB 2.0 devices
- HDMI compatible
- Cascadable to three levels- control up to 512 computers
- Multi-Display feature - stack up to eight CS1798 units and display video from up to eight monitors(dual display/triple display/quad display/multi-display)
- 2-port USB 2.0 hub built in
- Computer selection via front panel pushbuttons, hotkeys, and multilingual on-screen display (OSD)
- Independent switching of KVM and USB focus
- OSD Backup/Restore feature- enables the administrator to back up the switch's configuration and user profile information
- Firmware upgradable
- Video DynaSync - exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
- Superior video quality- supports up to 1080p / 1920 x 1200 at 60Hz
- Supports widescreen resolutions
- Audio enabled- full bass response provides a rich experience for 2.1 channel surround sound systems
- Console audio ports on front panel for easy access
- Auto Scan Mode for monitoring all computers
- HDCP compatible
- Multiplatform support- Windows, Linux, Mac, Sun
- Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
- Complete keyboard emulation for error-free booting
- Mac/Sun keyboard support and emulation
- Multilingual OSD supports English, German, Japanese, Traditional Chinese, Simplified Chinese, Spanish, Russian, and French
- Multilingual keyboard mapping - supports English (US), English (UK), German (GER.), German (SWISS), French, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish, Traditional Chinese, and Simplified Chinese
Warranty Information
This product has a limited warranty of 36 months.
