Audio 2000s AWM6304U Professional UHF Wireless In-Ear Monitoring System with 100 Adjustable Frequencies, Includes Receiver, Body-Pack Transmitter & Earphone

SKU: A2AAWM6304U

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : What is the range of this unit?
Shopper : max distance from transmitter to receiver?ANDREW R : The manufacturer indicates a maximum range of UP TO 100'.
Shopper : Why Did You Choose This?Mark E : Replace existing

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Audio 2000s AWM6304U Specifications

Receiver

Receiver

Jump to...
  • Frequency Band

    571 - 598 MHz

  • Band Width

    25 MHz

  • Oscillation Mode

    PLL Synthesized

  • Frequency Stability

    +/-0.005% (32 to 122 Degree F)

  • Modulation Mode

    FM Stereo Modulation

  • Max. Deviation Range

    +/- 68 KHz

  • Receiving Mode

    Diversity Receiving

  • Receiving Sensitivity

    -107 dBm

  • Squelch Level

    -100 dBm -90 dBm -70 dBm

  • T.H.D.

    1%

  • Max S/N Ratio

    94 dB

  • Frequency Response

    80 - 15,000 Hz ( +/- 3 dB)

  • Stereo Separation

    35 dB

  • Output Jack

    3.5mm Stereo Headphone Jack

  • Output Power (32 Ohms)

    2x 50mW under 1KHz (T.H.D. 3%)

  • Headphone Impedance

    > 16 Ohms

  • Power Supply

    2x AA Battery

  • Current Consumption

    150 mA

  • Dimensions

    4.2 x 2.6 x 1.1" (10.7 x 6.6 x 2.8cm)

Transmitter

Jump to...
  • Frequency Band

    571 - 598 MHz

  • Band Width

    25 MHz

  • Oscillation Mode

    PLL Synthesized

  • Frequency Stability

    +/-0.005% (32 to 122 Degree F)

  • Modulation Mode

    FM Stereo Modulation

  • Output Power

    <10mW

  • Spurious Rejection

    -60 dBc

  • Max. Deviation Range

    75 KHz

  • Frequency Response

    50 - 15,000 Hz

  • T.H.D.

    <0.5% (@Max. Deviation Range @ 1 KHz)

  • Audio Output

    Line Level X2, XLR

  • Audio Input

    2x 1/4" Phone Jacks

  • Headphone Output

    1/4" Stereo Phone Jack with Adjustable Volume

  • Headphone Output Impedance

    > 16 Ohms

  • Antenna Connector

    TNT (50 Ohms)

  • Dimensions

    9.4 x 5.4 x 2.0" (23.88 x 13.72 x 5.08cm)

  • UPC Code

    844565000293

About Audio 2000s AWM6304U

The reasons why the AWM6304U is suitable for your sound monitoring needs.

•It Provides Flexibility: A number of receivers (up to the number that will fit in the wireless transmission range) can be added as needed.

•It Is A Versatile Sound Tool: This AWM6304U wireless monitoring system can be utilized wirelessly in various sound-monitoring events such as on a stage, in a studio, in an exhibit, in a lecture, or in a speech. With 100 selectable frequencies, more than one AWM6304U unit can be used at the same time to transmit multiple languages.

•It Provides The Freedom Of Movement- This AWM6304U system allows you a reliable consistent sound wherever you move in the attended sound event.

•It Is Compact And Wireless- The precision-built system is compact and provides a long wireless range of transparent sound quality.

•It Is Simple To Set Up And Operate- Plug N' Play.

•It Provides Quality Sound And Excellent Value- This AWM6304U system not only provides quality sound but also allows you to choose the sound that you are monitoring in stereo or mono.

•It Is Affordable For Your Immediate Needs- With a long wireless range, transparent sound, and versatile features, you will be surprised by how much value this AWM6304U system can deliver to you.

Audio 2000s AWM6304U Features

  • UHF-Band Frequencies
  • Frequency Agile over a 25 MHz Bandwidth, with 100 preprogrammed Frequencies Available
  • Built-in Limiter Circuitry Eliminating Distortion under Excessive Input Levels
  • Front Panel 1/4" Stereo Monitoring Headphone Jack
  • Mono Mode or Stereo Mode
  • LCD Display
  • Low-Battery Indicator on the Receiver
  • Two Balanced Combo Audio Inputs and Two Balanced Audio Outputs on the Transmitter
  • One Audio Level Adjustment Knob
  • Microcontroller (CPU) Controlled
  • 13 - 15VDC Power Supply

Warranty Information

This product has a limited warranty of 12 months for parts and 12 months for labor.

Product Documents

User Manual

Key Features

  • Experience superior sound quality with these professional in-ear monitors for crystal-clear audio.
  • Enjoy a comfortable fit with these in-ear monitors, designed for extended use during performances.
  • Achieve excellent noise isolation, blocking distractions for focused monitoring on stage or in studio.
  • Benefit from low latency wireless in-ear system, ensuring real-time audio without any delays.
  • UHF wireless system offers 100 adjustable frequencies, minimizing interference for reliable performance.
  • Get great value with this complete in-ear monitoring set, including receiver, transmitter, and earphones.

What's in the box:

  • AWR6305U5 Receiver
  • AWX6304U Wireless Transmitter
  • Earphone
  • Antenna
  • 2x 1/4 " to 1/4 " Audio Cable
  • AC/DC Adapter for AWX6304U
  • 2x 1.5V AA Battery
  • Owner's Manual
  • Audio 2000s 1 Year Limited Warranty
