Acetek PTZ-SH20X HD SDI/HDMI Broadcast and Conference 20x PTZ Camera, Open Box
See all Acetek items

Acetek PTZ-SH20X HD SDI/HDMI Broadcast and Conference 20x PTZ Camera, Open Box

SKU: ACEPTZSH20XO
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Acetek PTZ-SH20X: Picture 1 regular
Acetek PTZ-SH20X HD SDI/HDMI Broadcast and Conference 20x PTZ Camera
$1,456.00$1,126.00
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Acetek PTZ-SH20X Open Box Specifications

Camera Parameter

Camera Parameter

Jump to...

  • Optical Zoom

    f=5.2 - 98mm

  • View Angle

    3.3 Degree (tele)
    54.7 Degree (wide)

  • Iris

    F1.6 - F3.5

  • Sensor

    1/2.8" high quality HD CMOS sensor

  • Effective Pixels

    16:9, 2.07 Megapixel

  • Digital Zoom

    10x

  • Min. Illumination

    0.5Lux (F1.8, AGC ON)

  • DNR

    2D & 3D DNR

  • White Balance

    Auto / Manual/ One Push/ 3000K/ 4000K/ 5000K/ 6500K

  • Iris/Electronic Shutter

    Auto/Manual

  • Focus

    Auto / Manual / One Push

  • BLC

    On/Off

  • WDR

    Off/ Dynamic level adjustment

  • Video Adjustment

    Brightness, Color, Saturation, Contrast, Sharpness, BW Mode, Gamma, Curave

  • SNR

    >55dB

Input / Output Interface

Jump to...

  • Video Interface

    SDI, HDMI, LAN, RS232 (in & out), RS485, A-IN

  • Video Compression

    H.264, H.265, Dual stream output

  • Control Protocol

    VISCA/Peclo-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps

  • Audio Input Interface

    Double track 3.5mm linear input

  • Audio Compression

    AAC/MP3/PCM Audio Compression

  • LAN Port

    100M IP Port (100BASE-TX); Support VISCA protocol control through IP port

  • Network Protocol

    RTSP, RTMP, ONVIF, GB/T28181

  • Power Interface

    HEC3800 Outlet (DC 12V)

General

Jump to...

  • Video Format

    HDMI/SDI/HD BaseT video format: 1080P60/50/30/59.94/29.97
    10801080P60/50/59.94
    720P60/50/30/59.94/29.97

  • USB 3.0 Interface video format

    USB 3.0: 1920 x 1080P60/50/30/25
    1280 x 720P30/25/15/10
    960 x 540P30
    640 x 360P30

    USB 3.0 compatible with USB 2.0: 960 x 540P30
    640 x 360P30
    1280 x 720P10/15
    720 x 576P30/720 x 480P30

  • USB 2.0 Interface video format

    176 x 144, 320 x 240, 320 x 180, 352 x 288, 640 x 480, 720 x 480, 720 x 576, 640 x 360, 800 x 600
    960 x 540, 1024 x 576, 1024 x 768, 1280 x 720, 1920 x 1080 P30/25/20/15/10/5

PTZ & Other Parameter

Jump to...

  • Pan / Tilt Rotation

    170 Degree, 30 Degree - +90 Degree

  • Pan Control Speed

    0.1 - 60 Degree/sec

  • Tilt Control Speed

    0.1 - 30 Degree/sec

  • Preset Speed

    Pan: 60 Degree/sec, Tilt: 30 Degree/sec

  • Preset Number

    255 presets (10 presets by remote controller)

  • Power Adapter

    AC 110V-AC220V to DC 12V/1.5A

  • Remote Operation (IP)

    Remote Upgrade, Reboot and Reset

  • Dimensions

    5.90 x 5.90 x 6.59" (150 x 150 x 167.5mm)

  • Weight

    3.08 lb (1.4kg)

About Acetek PTZ-SH20X Open Box

With Acetek PTZ-SH20X HD Video Conference Camera experience a new level of visual immersion with lifelike and crystal-clear image effects, boasting a strong sense of depth that pulls you into the scene. This high-resolution display delivers stunning visuals, enhanced by fantastic color rendition that brings your content to life.

Enjoy a full HD image enriched by multiple optical zoom lenses, while a range of rich video interfaces ensures seamless connectivity. Powered by advanced ISP technology and algorithms, this system guarantees stability, reliability, and perfect compatibility with your devices. With convenient installation and maintenance.

Acetek PTZ-SH20X Open Box Features

  • Lifelike and Crystal Clear Image Effect & Strong Sense of Depth. High Resolution
  • Fantastic Color Rendition
  • Full HD Image
  • Multiple Optical Zoom Lens
  • Rich Video Interfaces
  • Advanced ISP Technology and Algorithm Stable and Reliable, Perfect Compatibility Convenient Installation and Maintenance

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Capture every detail with 20x optical zoom, perfect for large conference rooms or lecture halls.
  • Enjoy crystal-clear 1080p resolution, ensuring professional-quality video for all your broadcasts.
  • Benefit from versatile connectivity options, including SDI and HDMI for seamless integration.
  • Experience smooth and precise pan/tilt control for dynamic camera movements during live events.
  • Achieve excellent low-light performance with a 1/2.8" HD CMOS sensor, ideal for various lighting conditions.
  • Utilize 255 preset recall positions to quickly switch between different camera angles effortlessly.

What's in the box:

  • Acetek PTZ-SH20X HD SDI/HDMI Broadcast and Conference 20x PTZ Camera
  • Acetek 1 Year Limited Warranty
