ACTi INR-320 64-Channel 6-Bay RAID Tower Standalone NVR

ACTi INR-320 64-Ch 6-Bay RAID Tower Standalone NVR with Seagate 500GB 3.5" SATA HDD

SKU: ACTINR320
Be the first to review this item

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

Can the INR-320 64-Ch 6-Bay RAID Tower Standalone NVR support non-ACTi cameras?

Yes, the INR-320 can support non-ACTi cameras via a licensed Camera Device Pack.

What is the storage capacity of the INR-320 64-Ch 6-Bay RAID Tower Standalone NVR?

The INR-320 comes with a Seagate 500GB 3.5" SATA HDD, providing ample storage for your video data.

How many cameras or video encoders can the INR-320 manage?

The INR-320 can manage up to 64 cameras or video encoders, making it suitable for comprehensive surveillance systems.

What formats can the INR-320 export video in?

The INR-320 can export video in both RAW and AVI formats, offering flexibility in how you store and share your video data.

Does the INR-320 offer remote access?

Yes, the INR-320 supports live view and synchronized playback remotely for up to 64 channels.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

ACTi INR-320 Specifications

  • Maximum Number of Clients

    1 local, 3 remote

  • Maximum Number of Cameras

    64

  • Free License

    32 Channels

  • Compression

    H.264, MPEG-4, MJPEG

  • Maximum local display resolution

    1920 x1200

  • Display Layout Mode

    Local: 1, 4, 5, 6, 8, 9, 10, 12, 16
    Remote: 1, 4, 5, 6, 8, 9, 10, 12, 16, 18, 24, 25, 35, 36, 48, 49, 64

  • Live View: Manager

    An interface to define display layouts and the pre-set cameras within layout in the public or private view

  • Live View: Patrol

    Automatic switch between different views or devices

  • Live View: Panel

    Contains the list of pre-defined views for quick launch

  • Live View: Digital Zoom

    Zoom in/out digitally by PiP (Picture-in-Picture)

  • Live View: Camera Tree

    Drag and drop video source from camera tree into display layout; display camera status on the tree

  • Live View: Manual Recording / Snapshot

    Instant recording upon mouse click / Instant snapshot upon mouse click or hot key

  • Live View: Event Panel

    Display event status upon alarm or upon connection loss or recovery

  • Live View: Two-way Audio

    Audio sound from and to all the audio supported devices; audio broadcast to multiple devices at the same time

  • Live View: Dual Stream Management

    Live view of stream 1 or stream 2 of dual stream devices

  • Live View: Instant Playback

    Instant playback in live view window

  • e-Map: Layout

    Area maps with camera icons, small live view windows; hyperlinked

  • e-Map: Map Switch and Tour

    Manual switch and auto tour modes selectable

  • e-Map: Setup

    e-Map image upload
    camera positioning
    map linking

  • PTZ Mode

    Mouse PTZ mode to control e-Map video streams

  • PTZ: Control

    Pan, tilt and zoom controls
    Speed control
    Both buttons and mouse controls

  • PTZ: Preset Points and Tours

    Create preset points
    create auto tours between preset points

  • PTZ: Number of Preset Points

    32

  • PTZ: Joystick

    USB based joystick supported

  • PTZ: Default Protocol

    Auto-detect camera's PTZ protocol
    Available protocols: ACTi, Pelco-P, Pelco-D, Dynacolor, Visca

  • Recording Throughput

    Maximum total bitrate 300Mbps

  • Scheduled Recording

    Record video with user defined schedule

  • Event Recording

    Record video when the alarm event is triggered, including the pre-event buffered video clip

  • Speed Up

    Different recording frame rate settings for non-event and triggered event

  • Manual Recording

    Instant recording upon mouse click

  • Recording Dual Stream Management

    Recording of stream 1 or stream 2 of dual stream devices

  • Recording Frame Rate

    Max 6000 fps total
    Max 30 fps per camera

  • Interface

    Serial ATA

  • Bundled System HDD

    Seagate 500GB 3.5" SATA HDD

  • HDD Bay

    6 (1 bay is occupied by system HDD)

  • RAID Level

    Hardware RAID 0, 1, 5, 10

  • External Storage Support

    eSATA, iSCSi, USB mass storage (USB 2.0)

  • Time Based Video Search

    Search video recordings by time or channel

  • Event Based Video Search

    Search alarm triggered video recordings

  • Playback Control

    Continuous forward and backward playback with speeds 1x/2x/4x/8x or frame-by-frame
    Pause
    Stop

  • Synchronized Playback

    Up to 9 channels for local display
    up to 64 channels for remote client

  • Manual Snapshot

    Instant snapshot from playback upon mouse click

  • Digital Zoom

    Zoom in/out digitally by PiP (Picture-in-Picture)

  • Video Cropping

    Crop a short video clip from long recording file and save it as an independent file

  • Video Export

    Export video clips in AVI or RAW format
    Text overlay supported

  • Event Trigger

    Video motion detection
    Passive IR sensor
    External device through digital input
    Video loss and recovery
    Network loss and recovery
    Server loss and recovery
    Disk full
    Disk not found

  • Event Response

    Record video
    Pop-up window with live video
    Switch to hotspot window
    Play beep sound
    Activate external device through digital output
    Upload snapshot to FTP server
    Execute system command to activate other programs
    E-mail notification with snapshots
    Command a PTZ device to go to a preset point

  • Manual Event

    Manually activate external devices through digital output via live view monitor

  • Scheduler

    Define the schedule of event manager

  • Permission Control

    Multi-group/users, liveview/playback/setup/remote level permission

  • Operating System

    Win 7 Std. Embedded

  • Language

    Multi-language support

  • PC Client Program

    User interface program (Workstation) with live view
    PTZ
    Playback
    e-Map
    Event management
    Setup

  • PC Web Browser

    Microsoft Internet Explorer 8.0, 9.0 or 10.0 with live view
    PTZ
    Playback
    Event management
    Setup

  • Mobile Client Program

    Mobile device application (Active Mobile Client) supports live view
    PTZ control
    Event or time based search and playback Supported devices: iPhone, iPad, iTouch and Android device

  • Remote Client PC System Requirement

    1-16 channels: Intel Core 2 Quad 2.4GHz, 4GB RAM
    17-64 channels: Intel Core i7-920 2.67GHz, 4GB RAM

  • CPU Intel

    Processor

  • RAM

    8GB

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Operating Humidity

    10% to 85% RH

  • Power Source

    110V to 220V AC 50/60Hz

  • Approvals

    CE (EN 55022 Class B, EN 55024), FCC (Part15 Subpart B Class B)

  • USB

    USB 2.0, 4 ports

  • Ethernet Port

    2, Gigabit Ethernet ports (1000 Base-T), RJ-45 connector

  • Audio Port

    MIC
    Line-in
    Line-out

  • eSATA Port

    2

  • Display port

    1 VGA

  • Unified Solution

    Fully compatible with ACTi cameras, encoders and CMS 2.0

  • Open Platform Solution

    Support ONVIF compliant devices

  • Dimensions (W x H x D)

    3.5 x 17.2 x 21" / 88.9 x 436.88 x 533.4mm

  • Weight

    TBC

About ACTi INR-320

Be empowered with the INR-320 64-Ch 6-Bay RAID Tower Standalone NVR, a high-performance, reliable, and advanced solution for your surveillance and security needs. This sophisticated device is equipped with a Seagate 500GB 3.5" SATA HDD, offering ample storage space for your video data.

Designed for durability and efficiency, this standalone NVR can manage up to 64 cameras or video encoders, making it an ideal choice for comprehensive surveillance systems. It supports live view locally for up to 16 channels and remotely for up to 64 channels, ensuring you have complete visibility over your monitored areas.

The INR-320 also offers synchronized playback, allowing local access to up to 9 channels and remote access to up to 64 channels. This feature ensures you never miss a moment of your recorded footage.

With the ability to export video in both RAW and AVI formats, this device provides flexibility in how you store and share your video data. It also features event trigger, response, and notification capabilities, keeping you informed of any significant events captured by your surveillance system.

The INR-320 comes with a mobile client, web client, and workstation, providing multiple access points for your convenience. It also features location-based management with eMap, allowing for easy navigation and control of your surveillance system.

This device comes with a 32-channel free license included and supports non-ACTi cameras via a licensed Camera Device Pack. With its RAID 0, 1, 5, and 10 capabilities, the INR-320 ensures your data is secure and performance is optimized.

Experience the power and flexibility of the INR-320 64-Ch 6-Bay RAID Tower Standalone NVR, your advanced solution for comprehensive and reliable surveillance.

ACTi INR-320 Features

  • High-performance 6-Bay RAID Tower Standalone NVR with 500GB storage capacity
  • Supports up to 64 cameras or video encoders for comprehensive surveillance
  • Features live view and synchronized playback for local and remote access
  • Offers video export in RAW and AVI formats for flexible data storage
  • Includes event trigger, response, and notification capabilities for enhanced security
  • Comes with mobile client, web client, and workstation for convenient access
  • Provides location-based management with eMap for easy navigation and control
  • Includes a 32-channel free license and supports non-ACTi cameras via licensed Camera Device Pack
  • Features RAID 0, 1, 5, and 10 capabilities for data security and performance optimization

Warranty Information

This product has a limited warranty of 36 months.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Manage up to 64 channels with this network video recorder for comprehensive surveillance.
  • Enjoy seamless remote access to your security video recorder for monitoring on the go.
  • Utilize motion detection to record only when needed, saving valuable storage capacity.
  • Benefit from the easy setup of this NVR, getting your security system running quickly.
  • Store video on the included 500GB HDD, expandable for increased recording throughput.
  • Enhance night vision with compatible cameras for clear surveillance in low-light conditions.

What's in the box:

  • ACTi INR-320 64-Channel 6-Bay RAID Tower Standalone NVR with Seagate 500GB 3.5 " SATA HDD
  • 32-Channel Free License
  • ACTi 3 Year Limited Warranty
