American DJ Focus Wash 400 400W RGBACL LED Moving Head Wash Light

SKU: ADJFWASH400 MFR: FOCUS WASH 400
Earn VIP Reward Points

Key Features

  • Unleash vibrant washes with the Focus Wash 400's 400W RGBACL LED for stunning color mixing.
  • Achieve precise lighting with a motorized zoom range from 10 to 41 degrees, perfect for any venue.
  • Enjoy seamless control with multiple DMX channel modes and RDM for remote device management.
  • Create dynamic effects with electronic strobe, linear dimming, and adjustable color temperature.
  • Experience superior sound quality with selectable LED refresh rates up to 25kHz for flicker-free operation.
  • Ensure durability with a robust design, ideal for touring and permanent installations alike.
See More Product Details
Special Order?Estimated to Ship: 08/17/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$179.99

3 Year

$249.99

5 Year

$489.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

American DJ Focus Wash 400 Specifications

Source
  • Source

    400W RGBACL LED
    50,000 Hour Average LED Life

Photometric Data

Jump to...
  • Zoom Range

    10 Degree - 41 Degree

  • Field Angle

    19 Degree - 54 Degree

  • Color Temperature

    10,000K
    4,600 Total Lumen Fixture Output
    Lux @ 10': 10,384 lx (965 foot candles), 1.8' diameter

  • CRI

    90+

  • CRI R9

    87.3

  • TM30 Rf

    90.8

  • TM30 Rg

    99.5

  • Color

    Individual RGBACL (Red, Green, Blue, Amber, Cyan, Lime) Control
    Virtual Color Wheel Control
    Virtual CMY Control

Effects

Jump to...
  • Effects

    RGBACL Color Mixing
    Virtual CMY Color Mixing
    10 Degree - 41 Degree Motorized Zoom
    Electronic Strobe and Dimmer
    Color Temperature Red to Green control via DMX
    Linear Color Temperature control, 2700K to 10,000K
    Preset Color Temperatures (2700K, 3200K, 4000K, 5600K and 6500K)

Control/Connections

Jump to...
  • Control/Connections

    5 DMX Channel Modes: [Basic (17), Standard (22), Extended (24), CMY Standard (18) or CMY Extended (24)]
    Selectable LED Refresh Rates, 900Hz to 25kHz
    Linear Dimming with user selectable Dim Curves, Dim Modes and Dim Speeds
    6-button Control Panel and LCD Menu Display
    USB Firmware Update Port
    RDM (Remote Device Management

  • Control/Connections (Contd.)

    Quiet Fan Mode
    Locking 3-pin and 5-pin XLR Connector In/Out
    IP65 Locking Power Connector In/Out
    With Wired Digital Communication Network

Electrical/Thermal

Jump to...
  • Electrical/Thermal

    Multi-voltage: AC 100-240V/47/63Hz
    460W Power Consumption @ 120V
    430W Power Consumption @ 240V
    Multiple Unit Power Linking
    5 Degree F to 113 Degree F (-15 Degree C to 45 Degree C)

Physical

Jump to...
  • Dimensions

    Length: 10.96" (278.43mm)
    Width: 8.4" (213.33mm)
    Vertical Height: Without Snoot: 19.6" (498.1mm)
    With Snoot: 22.37" (568.1mm)

  • Weight

    23.5 lbs (10.7kg)

  • UPC Code

    818651029130

About American DJ Focus Wash 400

Take your stage lighting to the next level with the Focus Wash 400 400W RGBACL LED Moving Head Wash Light. This dynamic and versatile lighting fixture is powered by a high-quality 400W RGBACL (Red, Green, Blue, Amber, Cyan, and Lime) LED engine, capable of producing bright and colorful light output.

The Focus Wash 400 features a 10 to 41-degree motorized zoom, housed in a 6-inch Fresnel lens, ensuring an even field light output. This makes it an ideal choice for larger events and venues, where a strong and consistent light output is essential.

Designed with the needs of TV and film in mind, this LED moving head wash light offers flicker-free operation and adjustable refresh rates ranging from 900Hz to 25kHz. This ensures smooth and uninterrupted lighting, perfect for live broadcasting and film use.

The Focus Wash 400 also offers linear white color temperature control from 2700K to 6500K, along with preset white color macros (2700K, 3200K, 4000K, 5600K, and 6500K). This allows for precise control over the warmth or coolness of the light, providing more creative freedom for lighting designers.

The RGBACL LED engine enables virtual CMY color mixing, allowing users to select any hue on a color picker. This unique color engine also produces a high CRI of 90+ for bright whites and a CRI R9 of 87.3 to enhance red tones, making them more vibrant.

The Focus Wash 400 is equipped with 16-bit pan/tilt movement, variable dimming modes/curves, and strobe effects, providing a wide range of lighting options. It supports DMX and RDM (remote device management) protocols, allowing for easy integration into existing lighting setups.

This fixture comes standard with locking power In/Out connections, locking 3-pin & 5-pin DMX In/Out sockets, a color LCD menu display with a 6-button control panel, and multiple unit power linking. It also features a multi-voltage universal auto-switching power supply (AC100-240V), a USB port for convenient firmware updates, and omega brackets with two hanging points.

In summary, the Focus Wash 400 400W RGBACL LED Moving Head Wash Light is a high-powered, versatile, and feature-rich lighting solution, designed to meet the demanding needs of stage lighting professionals.

American DJ Focus Wash 400 Features

  • 400W RGBACL LED
  • 10 to 46-degree motorized zoom
  • Flicker free operation for TV and film
  • 16-bit pan/tilt movement
  • RGBACL color mixing
  • Variable dimming modes/curves and strobe effects
  • DMX and RDM protocol support
  • DMX and power in/out connections
  • LCD menu display with 6 button control panel
  • Multiple unit power linking
  • Multi-voltage universal auto switching power supply (AC100-240V)

Warranty Information

This product has a limited warranty of 24 months for parts and 12 months for labor.

Key Features

  • Unleash vibrant washes with the Focus Wash 400's 400W RGBACL LED for stunning color mixing.
  • Achieve precise lighting with a motorized zoom range from 10 to 41 degrees, perfect for any venue.
  • Enjoy seamless control with multiple DMX channel modes and RDM for remote device management.
  • Create dynamic effects with electronic strobe, linear dimming, and adjustable color temperature.
  • Experience superior sound quality with selectable LED refresh rates up to 25kHz for flicker-free operation.
  • Ensure durability with a robust design, ideal for touring and permanent installations alike.

What's in the box:

  • American DJ Focus Wash 400 400W RGBACL LED Moving Head Wash Light
  • Snoot
  • 2x Omega Brackets
  • Linear Lens
  • Twist-Lock Power Cable
  • 4x Screws
  • American DJ 2 Year Limited Warranty
