Allen & Heath Qu-7D 36-Channel/12-Bus Digital Mixer with 16x16 Dante
SKU: AHQU7D MFR: AH-QU-7D
$4,599.99
$5,799.99
Save: $1200 (21%)OR
Key Features
- Achieve pristine sound quality with 36 channels, perfect for live sound and studio recording.
- Enjoy versatile connectivity with 16x16 Dante, ideal for complex audio setups and installations.
- Effortlessly manage your mix using the intuitive 7-inch capacitive touchscreen and 8 soft keys.
- Record and play back multi-track audio directly via USB connectivity, simplifying your workflow.
- Enhance your sound with 6 built-in FX engines, offering professional-grade effects for any performance.
- Benefit from robust durability and a compact design, making this digital mixer highly portable for gigs.
New Item?
Free Shipping
See Options
1
Protect your gear with Adorama Protect.* Learn more
2 Year
$499.99
3 Year
$649.99
5 Year
$949.99
Available to U.S. customers only.
Need help? Ask our experts.
Overview
Compare
Specs
Protection
Q&A
About Allen & Heath Qu-7D
Compact 38in/24out 96kHz Mixer
Allen & Heath's legendary digital mixer is reborn, supercharged with a 96kHz XCVI core for DEEP Processing capabilities, increased channel count with fully flexible patching across 4 customizable layers, a completely redesigned user interface, significant hardware upgrades, plus extended connectivity and Dante.
All New Hardware.
The new Qu retains the much-loved appearance and form factor of the original Qu series, but with multiple hardware improvements to elevate the sonic performance and mixing experience.
Audio
Updated microphone preamps and high-performance 96kHz AD/DA converters combine to deliver pristine audio to and from the XCVI core, preserving every detail of the source.
Control
Every channel now features a channel display - showing channel name, channel type, or socket number - and a chromatic channel meter for at-a-glance level information, and the new touchscreen accommodates a completely redesigned user interface.
Dante Enabled
The Qu-7D provides a 16x16 Dante interface at 96kHz or 48kHz for integration into larger systems or installs.
UI: Updated Workflow
The original Qu series was well loved for its ease and speed of use, making it the perfect mixer for engineers coming from the analogue world. The new Qu takes this further, maintaining a focus on "walk up and mix" usability while adding 4 fully customizable layers, more assignable SoftKeys for workflow optimization, and flexible routing options in addition to the classic 1:1 Qu routing, all accessible via a newly developed, fast and responsive, user interface.
Capture & Playback: Reliable Recording and Playback. Anywhere.
Every Qu model is packed with versatile recording and playback options, with an integrated 32x32 USB-C audio interface, 32-channel multitrack support via SD card, and simple stereo recording and playback through the USB-A port, whatever your application.
SLink: Everything I/O Compatible
Thanks to its SLink port, Qu can be connected to the Everything I/O family of rack and stage box expanders making it a flexible, mix 'n' match solution for owners of other Allen & Heath digital systems. It can even be connected directly to other Allen & Heath consoles with up to 128x128 channels of 96kHz audio available for patching.
DEEP Processing. Assistive Tools.
Qu is now DEEP Processing ready, bringing acclaimed add-ons from our flagship dLive system to the Qu platform for the first time. In addition, Qu now features the Feedback and Gain Assistants from the CQ series to take the stress out of setup and speed up your soundchecks.
Gain Assistant: Faster Setups
Adjusting the gain for each channel might not be the most thrilling task, and it can take up a lot of your setup time when you have multiple channels to manage.
Qu's Gain Assistant streamlines this process by quickly and precisely setting the ideal gain level for one or more input channels, while continuously monitoring levels during the performance to avoid any unwanted peaks or surprises.
Feedback Assistant: Say Goodbye to Feedback
Qu's easy to use Feedback Assistant automatically identifies and removes problematic frequencies with up to 16 filters per output, allowing you to mix with confidence and put feedback worries behind you.
Add-Ons: Take Your Mix to the Next Level
Proven on countless world-tours with international artists, DEEP Processing and RackExtra FX from our award-winning dLive digital mixing system are now available within your Qu.
AMM: Automatic Mic Mixer
Qu's 32 channel Automatic Mic Mixer (AMM) makes it the perfect choice for mixing conferences, panel talks, and TV shows. It's fully integrated in the mixer, with no extra latency, so you don't need to route the audio to an internal DSP rack or external plugin system.
Allen & Heath Qu-7D Features
- 96kHz XCVI Core variable bit-depth up to 96bit, <0.7ms latency
- 38x Inputs to Mix (32x Mono/Linkable, 3x Stereo)
- Stereo Main LR Output
- 12x Mixes (6x Mono/Linkable Aux/Group, 6x Stereo Aux/Group)
- 4x FX Sends
- 4x Mono/Linkable Matrix Mixes
- 32x XLR/Jack 'Combi' Mic/Line Input Sockets
- 2x Stereo Line Input Sockets (each 2x TRS)
- 1x XLR Talkback Socket
- 12x XLR Output Sockets
- 2x TRS Output Sockets
- 1x AES3 Stereo Digital Output Socket
- 128x128 SLink Port for Everything I/O expansion and system connections
- 16x16 48/96 kHz Dante interface
- Stereo Headphone Output
- 7" (17.78cm) Capacitive Touchscreen
- 33x 100mm Motorized Faders
- 4x Customizable Channel Strip Layers
- 8x SoftKeys
- 12V Lamp Socket
- Configurable single/dual Footswitch Connection
- Configurable Chromatic Channel Meter LED's
- IEC Mains Connection with Worldwide PSU
- RJ45 Network Socket
- USB-A For stereo audio record/playback and data (2 Channels @48/96kHz, 24bit)
- USB-C Audio interface for multichannel record/playback (32x32 @48/96kHz, 16/24bit)
- SD Card Slot for multichannel audio record/playback (16 Channels @96kHz, 32 Channels @48kHz, 24bit)
- Input processing - Trim, HPF, Gate, Parametric EQ, Compressor, Channel Delay
- Mix processing - Graphic EQ, Feedback Assistant, PEQ, Compressor, Channel Delay
- Fully patchable Insert points
- 6x Multi-FX Engines with dedicated Stereo Return Channels and PEQ
- 32 Channel, zero latency, DEEP Automatic Mic Mixer
- 31/61 Band Real Time Analyzer
- Feedback Assistant with 8 simultaneous detectors
- Gain Assistant
- 300 Scene memories per Show
- Channel Safes, Global/Per-Scene Recall Filters
- FX, Processing and Channel Libraries
- User Permissions to restrict operator access
- DAW Control emulation via USB or TCP/IP
- Compatible with ME personal monitoring range
- Remote control via free apps - Windows/MacOS/iOS/Android
Warranty Information
This product has a limited warranty of 12 months.
