AJA FiDO-4T 4-Channel 3G-SDI to Single Mode LC Fiber Transmitter

SKU: AJFIDO4TR MFR: FIDO-4T-R0
Earn VIP Reward Points

Key Features

  • Experience reliable signal conversion, ensuring your video feeds are always pristine.
  • Enjoy broad format compatibility, seamlessly integrating with various video systems.
  • Achieve lag-free performance, perfect for live broadcasts and critical monitoring.
  • Benefit from a durable build, designed for consistent operation in demanding environments.
  • Set up with ease; our video format converter simplifies complex installations.
  • Discover excellent value with this essential tool for professional video workflows.
See More Product Details
Special Order?Estimated to Ship: 07/17/2026
Free Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

AJA FiDO-4T Specifications

  • Video Formats

    150 Mbps - 3 Gbps, format agnostic

  • Video Input Digital

    4-Channel independent 3G-SDI BNC Inputs, SMPTE-259/292/424

  • Video Output Digital

    4-Channel independent Single Mode LC Fiber Outputs, SMPTE-297
    Nominal Wavelength: 1310 nm
    Optical Power: -5dBm (min), 0dBm (max)
    Extinction Ratio: 7.5dB (Typ)

  • Reclocking

    270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select
    All other rates are passed through and not reclocked

  • Power

    5 watts max
    Uses 5-20VDC power

  • Environment

    Safe Operating Temperature: 32 to 104 Degree F (0 to 40 Degree C)
    Safe Storage Temperature (Power OFF): -40 to 140 Degree F (-40 to 60 Degree C)
    Operating Relative Humidity: 10-90% noncondensing
    Operating Altitude: <10,000' (<3,000m)

  • Dimensions (W x D x H)

    4.6 x 4.02 x 0.85" (117 x 102.11 x 21.6mm)

  • Weight

    14.10 oz (400g)

About AJA FiDO-4T

FiDO-4T offers unmatched flexibility and cost efficiency for SDI-Fiber conversion, allowing for long cable runs up to 10 km (32,808 ft) with electrical isolation - useful for eliminating ground loop problems.

FiDO converters use a compact, low-profile enclosure that works well in tight spaces around and behind equipment racks, trucks and on camera.

Universal Power Supply
All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.

Compact and Portable
AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack, or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.

AJA Mini-Matrix
Information on the complete line of AJA Mini-Converters is now available as a mobile app on iOS. The Mini-Converter product line is extensive and this app helps you find the right converter for any situation, wherever you are.

Individual products have links back to the main AJA website for more details and you can email product information directly from the app. The free AJA Mini-Matrix app for iPad and iPhone is available now in the Apple iTunes Store.

AJA FiDO-4T Features

  • 4-Channel 3G-SDI to Single-Mode LC Fiber Transmitter
  • 4 simplex or 2 duplex output connections (LC connector)
  • 4 independent channels of 3G/HD/SD-SDI input
  • 4K/UltraHD-SDI over 4 fiber links
  • Uses 5-20VDC power

Key Features

  • Experience reliable signal conversion, ensuring your video feeds are always pristine.
  • Enjoy broad format compatibility, seamlessly integrating with various video systems.
  • Achieve lag-free performance, perfect for live broadcasts and critical monitoring.
  • Benefit from a durable build, designed for consistent operation in demanding environments.
  • Set up with ease; our video format converter simplifies complex installations.
  • Discover excellent value with this essential tool for professional video workflows.

What's in the box:

  • AJA FiDO-4T 4-Channel 3G-SDI to Single Mode LC Fiber Transmitter
  • Power Supply (DWP-U-R1)
  • AJA 5 Year Limited Warranty
