AJA HDMI Video and Audio to JPEG 2000 Converter
See all AJA items

AJA HDMI Video and Audio to JPEG 2000 Converter

SKU: AJIPT1GHDMI
Be the first to review this item

This item is no longer available.

Recommended Alternatives

undefined undefined: Picture 1 regular
AJA HA5-12G-T HDMI 2.0 to 12G-SDI Mini-Converter with Single Fiber Transmitter
$1,295.00
undefined undefined: Picture 1 regular
AJA FS1-X Frame Synchronizer & Converter with MADI Audio
$4,575.00
undefined undefined: Picture 1 regular
AJA HDMI to SDI with Region of Interest Scaling and HDMI Loop Through
$1,295.00
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

AJA Converter Specifications

  • Video Formats

    2K: 2048 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    HD: 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    HD: 1920 x 1080i 25, 29.97
    HD: 1280 x 720p 50, 59.94, 60
    SD: 625i 25
    SD: 525i 29.97

  • Video Input Digital

    1x HDMI Standard Type A connector
    HDMI v1.4a 24/30 bits per pixel, RGB/YUV

  • Audio Input Digital

    2-Channel HDMI embedded audio, 24-bit per channel, 48 kHz synchronous

  • Audio Input Analog

    2x RCA analog audio (2-Channel)
    Levels at -10 dBu (nominal)

  • Essence Output

    1x RJ-45 (IEC 60603-7) for 10/100/1000 Base-T Ethernet (IEEE 802.3-2012)
    VSF TR-01 and other JPEG 2000 MPEG-2 TS workflows

  • User Controls

    1x RJ-45 (IEC 60603-7) for 10/100/1000 Base-T Ethernet (IEEE 802.3-2012)
    HTTP/1.1 (RFCs 7230, 7231, 7232, 7233, 7234, 7235)
    Web and REST clients supported
    1x USB 2.0 Mini-B (IEC 62680-1) connector
    AJA eMini-Setup of network parameters

  • Environment

    Operating Temperature: 32 to 104 deg. F (0 to 40 deg. C)
    Storage Temperature: -40 to 140 deg. F (-40 to 60 deg. C)
    Humidity: 10-90% RH, non-condensing
    Operating Altitude: < 10000' (3048.04m)

  • Power

    100-240V, 50/60 Hz Universal input
    +5 to 20V DC regulated, 12 watts max

  • Dimensions (WxDxH)

    5.53 x 4.48 x 0.954" (140.46 x 113.79 x 24.23mm)

  • Weight

    0.6 lbs (0.27kg)

About AJA Converter

Bridging from HDMI Video and Audio to TR-01 Compliant JPEG 2000 over IP, the IPT-1G-HDMI is a 3G-SDI to VSF TR-01 (and other JPEG 2000 formats) converter suited for video ingest from HDMI based cameras, routers and digital recorders and players and distribution across an IP network for feeding to IPR-1G-SDI, IPR-G-HDMI or KONA IP receivers. IPT-1G-HDMI provides two key ports for control. The Control LAN Ethernet port enables control of the Mini-Converter from web browsers on any platform and REST clients. The USB 2.0 mini connector facilitates quick and simple firmware updates.

• HTTP/1.1 (RFCs 7230, 7231, 7232, 7233, 7234, 7235)
• Web and REST clients supported
• 1x USB 2.0 Mini-B connector
• AJA eMini-Setup software setup of network parameters

User Control
The IPT-1G-HDMI is a HDMI to VSF TR-01 (and other JPEG 2000 formats) converter suited for video ingest from HDMI based cameras, routers and digital recorders and players and distribution across an IP network for feeding to IPR- 1G-SDI, IPR-G-HDMI or KONA IP receivers.

• Full size HDMI 1.4 video input
• 1x RJ-45 (IEC 60603-7) for 10/100/1000Base-T Ethernet media output
• Essence support: VSF TR-01 and other JPEG 2000 MPEG-2 workflows
• Rugged, fan less, portable design
• Full 10-bit pixel processing pipeline
• Network (LAN) control and status
• Quick network setup with AJA eMini-Setup software

Workflows: Facilities
IPT-1G-HDMI partners with AJA IPR Mini-Converter receivers and KONA IP for use in desktop workstations for reach throughout a facility or organization, local or remote.

Workflows: Creative Suites
IPT-1G-HDMI partners with AJA IPR Mini-Converter receivers and KONA IP for use in desktop workstations and simple expansion to other devices, displays and more over IP.

Universal Power Supply
All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.

Compact and Portable
AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.

AJA Quality - Guaranteed
All AJA Mini-Converters are covered by a 5 year warranty and AJA's advanced replacement policy.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • AJA HDMI Video and Audio to JPEG 2000 Converter
  • DWP-U-R1 Worldwide Power Supply
  • AJA 5 Year Limited Warranty
