Alibi NVRH1604-0 Specifications

Video/Audio Input

Video/Audio Input

Jump to...
  • IP Video Input

    16 channels

  • Two-way Audio Input

    1 channel, RCA

Network

Jump to...
  • Incoming Bandwidth

    160Mbps

  • Outgoing Bandwidth

    64 Mbps

  • Remote Users

    128

  • Protocols

    P2P, UPnP, NTP, DHCP, PPPoE

Video/Audio Output

Jump to...
  • HDMI/VGA Output

    HDMI: 4K (3840 x 2160 @ 30 fps), 1920 x 1080 @ 60 fps, 1920 x 1080 @ 50 fps, 1600 x 1200 @ 60 fps, 1280 x 1024 @ 60 fps, 1280 x 720 @ 60 fps, 1024 X 768 @ 60 fps
    VGA: 1920 x 1080 @ 60 fps, 1920 x 1080 @ 50 fps, 1280 x 1024 @ 60 fps, 1280 x 720 @ 60 fps, 1024 x 768 @ 60 fps

  • Recording Resolution

    8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF

  • Audio Output

    1-ch, RCA

  • Synchronous Playback

    16-ch

  • Corridor Mode Screen

    3 / 4 / 5 / 7 / 9 / 10 / 12 / 16

Decoding

Jump to...
  • Decoding format

    Ultra 265 / H.265 / H.264

  • Live view/Playback

    8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / 2CIF / CIF

  • Capability

    2 x 4K @ 30 fps, 4 x 4MP @ 30 fps, 5 x 3MP @ 30 fps, 8 x 1080P @ 30 fps, 16 x 720P @ 30 fps

Hard Disk

Jump to...
  • SATA

    4 SATA interfaces

  • Capacity

    Up to 14TB for each disk

External Interface

Jump to...
  • Network Interface

    1 RJ-45 10M / 100M / 1000M self-adaptive Ethernet interface

  • USB Interface

    Front panel: 1 x USB2.0, Rear panel: 1 x USB3.0

  • Serial Interface

    1 x RS485

  • Alarm In

    16-ch

  • Alarm Out

    4-ch

  • Interface

    16 independent 100Mbps PoE network interfaces

  • Max Power

    Max 30 W for single port
    Max 240 W in total

  • Supported Standard

    IEEE 802.3af / at

General

Jump to...
  • Power Supply

    100 - 240 Vac
    Power Consumption: <= 15 W (without HDD)

  • Working Environment

    +14 Degree F - +131 Degree F (-10 Degree C - +55 Degree C)
    Relative humidity <= 90% (noncondensing)

  • Dimensions (W x D x H)

    15.7 x 14.2 x 2.9" (400 x 362 x 74mm)

  • Weight

    <= 5.29 lbs (5kg) (without HDD)

  • UPC Code

    810094730086

About Alibi NVRH1604-0

A professional IP recording solution for home or small business applications featuring plug-and-play 8.0 megapixel resolution support for up to 16 IP cameras.

Protect your home or business with the Supercircuits 16-channel NVR-ideal for small to mid-size business applications. It supports up to 16 IP cameras and offers four hard drive bays up to 14TB each, and a recording resolution of up to 8.0 megapixels for ultra-sharp, high-resolution surveillance. It also offers easy plug-and-play installation, smart analytic detection, and high-resolution security monitoring.

The free Guard Viewer mobile app enables you to view your live and recorded video remotely-from anywhere, from your Android or iOS mobile device.

Plug-and-play setup
Utilizes power-over-ethernet (PoE) technology for an easy and flexible installation process. With PoE technology, each camera only needs a single cable run to connect it to the NVR. Install your cameras where you need them without the need for a nearby power outlet.

Lower Bandwidth and Storage Usage
Supports Ultra H.265, H.265, and H.264 codecs that help reduce file size, maximize recording time and save hard drive space.

ANR Technology
To enhance storage reliability when the network is disconnected.

Smart analytics
This versatile recorder allows multiple selectable recording modes: intrusion, cross line, defocus, and scene change detection, along with VCA search and alert features include event search, event log, and email notification.

Easy management
An intuitive interface along with access to the free Guard Viewer mobile app and Guard Station CMS make management more straightforward.

Alibi NVRH1604-0 Features

  • Up to 16 IP cameras
  • 160 Mbps recording capability
  • Ultra H.265/H.265/H.264 codec support
  • 4 hard drive bay @ 14TB
  • Integrated 16-port PoE switch
  • ANR Network Storage
  • One-click Cloud firmware updating

Key Features

  • Up to 16 IP cameras
  • 160 Mbps recording capability
  • Ultra H.265/H.265/H.264 codec support
  • 4 hard drive bay @ 14TB
  • Integrated 16-port PoE switch
  • ANR Network Storage

What's in the box:

  • Alibi NVRH1604-0 16-Channel Ultra H.265 Network Video Recorder
  • USB Mouse
  • Remote Control
  • Power Cable
  • 4x HDD SATA Cable
  • 4x HDD Power Cable
  • 4x HDD Bracket
  • Rack Mounting Bracket
  • 24x Screws
  • Phoenix Terminal
  • User Documentation
  • Alibi 3 Year Limited Warranty
